Chapter 8: The "Density" Application
76
8.5.3 Using the density statistics
Statistics are maintained for the density determinations. They store the last 10 results of density determinations you made and
accepted into the statistics. Note: The statistics do not differentiate between the methods used for the density determinations, but
simply store the last 10 results made and accepted.
To use the density statistics, the two function keys “Result” and “CL Sum” must be
activated (Section 8.3.4).
You can call up the statistics with the “Result” function key.
Note: If the statistics do not contain any values, the key is shown gray and cannot be
operated.
The statistics displayed are the values you have activated in the “Result” submenu of
the report settings (Section 8.3.6). The individual items of information in the density
statistics have the following meanings:
“n”: Number of samples
“x”: Mean density of all samples
“s”: Absolute standard deviation
“s.rel”: Relative standard deviation in %
“Min”: Lowest density determined
“Max”: Highest density determined
“Diff”: Difference between highest and lowest densities
The statistics can be printed out if required.
If you wish to close a measuring series, touch the “CL Sum” function keyy to clear
(delete) the statistics.
