Director EC Office Publisher with

OptiEC Printer Installation Guide

Document Revision: 11/4/04

DIRECTOR EC OFFICE PUBLISHER INSTALLATION GUIDE

Minimum System Requirements for Director EC Office Publisher

• Minimum Pentium® 4 or compatible personal computer @ 2 GHz or faster

• Windows 2000 Professional (service pack 4.0 or higher) or Windows XP Professional

(service pack 1.0a or higher)

• 1 GB RAM

• 1 Hard Disk Controller Adaptec Brand Ultra 26160

• 1 18 GB SCSI 15,000 rpm Ultra 160 SCSI Hard Drive (formatted NTFS) as follows:

• 1 Basic Partition for System (C:) & 2 5GB NTFS Partitions (D:)(E:) – Temp folder in root on

each partition

• 2 Free PCI Slots

• 1 Free USB Internal Connection

• 1 Firewire B 1394 Card (Supplied by MD Digital)

• 1 Software Identifier Card (Supplied by MD Digital) Computer needs 3.5” power connector.

• 1 external Com port (COM1 or COM 2) – 2 ports needed if using Prism Plus or Spectrum 2

• Network 100/10Mbs on Board

• Video 1024 X 768

• One Parallel Port

•

* A USB to Serial Converter can be used if no COM port is available.

THE DIRECTOR EC LOADER MUST BE INSTALLED ON COM PORT 2

THE DIRECTOR EC SOFTWARE MUST BE INSTALLED ON C:\ DRIVE

MF DIGITAL

121 Carolyn Blvd.

Farmingdale, NY 11735

001 631 249 9393

www.mfdigital.com

Summary of content (14 pages)

PAGE 1
Director EC Office Publisher with Document Revision: 11/4/04 OptiEC Printer Installation Guide DIRECTOR EC OFFICE PUBLISHER INSTALLATION GUIDE Minimum System Requirements for Director EC Office Publisher • • • • • • • • • • • • • • • Minimum Pentium® 4 or compatible personal computer @ 2 GHz or faster Windows 2000 Professional (service pack 4.0 or higher) or Windows XP Professional (service pack 1.
PAGE 2
Installing the Firewire Adapter & Software Identifier Cards You should never attempt to service a unit without ensuring proper anti-static protection. The Note: use of a grounding strap, or other such grounding device, is advised. In addition, the internal configuration of your computer may be different from the computer pictured below. Installing the Firewire Card The DirectorEC Office Publisher requires one IEEE-1394 card. 1. 2. 3. 4. 5. 6. Shut down the PC. Turn the PC’s power off. Unplug the PC.
PAGE 3
Making the Connection PC Connection Page 3
PAGE 4
Installing the Director EC Office Publisher Software [1] Note: When installing the Director EC software on Windows XP you MUST install ODBC FoxPRo drivers. See step #2 bellow. (fig. 1) 1. Insert the Director EC Publisher software CD. 2. From the CD ROM drive of the computer, click Director 3.0 3. Click Next (fig. 1). 4. You MUST accept default folder and click Next (fig. 2). 5. Confirm Installation and click Next (fig. 3). 6. Installation completed click Close (fig. 4). (fig. 2) (fig. 3) (fig.
PAGE 5
Installing the Director EC Office Publisher Software [2] Note: Windows XP MUST install ODBC FoxPRo drivers before running Director 3.0 1. After installation of the Director EC software go to “c:\cdDirector\ODBC FoxPro Driver” folder. (fig. 1) (fig. 1) 2. Double click the VFPODBC file. (fig.2) 3. Congratulations you have successfully installed Director EC Office Publisher software. (fig.
PAGE 6
Selecting system drives for Director EC System Setup tab 1. Open Director EC software. 1. Director EC software might prompt a message “System Drives Missing” click OK. 2. Go to “System Setup” tab and select system drives “D and E” (fig. 1) (fig.
PAGE 7
Turning OFF Auto RUN on CD-ROM. 3. Go to “Start”. 4. Go to “Run” 5. Type in “regedit” then click OK (fig.1) 6. Navigate to “Autorun” registry following the path “My Computer\HKEY_LOCAL _MACHINE\SYSTEM\Cu rentControlset\Services\Cd rom” (fig. 2) 7. Set value in “Autorun” registry to zero if different. (fig. 1) Value in Autorun is set to zero. (fig.
PAGE 8
Installing the Director EC Publisher Alignment Utility for aligning the Drive Tower and Printer 1. Insert the Director EC Office Publisher CD into the CD-ROM drive of your PC. 2. Click on setup.exe of the alignment utility and Click OK (fig. 1). (fig. 1) 3. Click Next button to install complete version (fig. 2). 4. Click Install to start installation (fig. 3) (fig. 2) (fig.
PAGE 9
Installing the Director EC Publisher Alignment Utility for aligning the Drive Tower and printer (cont.) 5. A progress bar will appear (fig. 4). (fig. 4) 6. Click Finish to finish installation. (fig. 5) (fig.
PAGE 10
Installing the OptiEC Printer Driver 1. 2. 3. 4. 5. 6. Click Start-> Settings-> Printers Click Add New Printer The “Welcome to the Add Printer Wizard” window will appear (fig 1). Click Next. In the “Local or Network Printer” window, uncheck the “Automatically detect installed printer” option , leaving the “Local printer attached to computer” option (fig 2) and click Next.. In the “Select a Printer Port” window, leave the default as LPT1 (fig 3) and click Next.
PAGE 11
Installing the MF Digital OptiEC Printer Driver (cont.) 7. After specifying the driver for the MF Digital OptiEC printer, the printer “MF Digital OptiEC” will appear in the “Add Printer Window” (fig 7). Click Next to continue. 8. In the “Name your Printer” window, leave the printer as the default name, and select the printer to be the default printer (fig 8) and click Next. fig 7 9. In the “Printer Sharing” window, select “Do Not Share the Printer” (fig 9) and click Next. 10.
PAGE 12
Adjusting the MF Digital OptiEC Printer Driver Settings Printer Spooling It is important to disable printer spooling on the MF Digital OptiEC printer. To do so, please follow the steps below: 1. 2. 3. 4. 5. 6.
PAGE 13
Aligning the Drive Tower 1. 2. From your Start Menu Open the EC Alignment Utility (fig. 1). It will be located in the folder designated when you installed the alignment utility. Choose COM Port 2, which the Director EC Loader is installed. Select all other printer types and drive bay. Click on Perform Test. Follow the instructions by opening the top CD/DVD drive tray, and Clicking Yes (fig. 2).
PAGE 14
Aligning the MF Digital OptiEC Printer Alert: Before starting the Alignment Utility, position the front end of the printer on the dotted line on the top of the drive bay. (fig 1) 1. From your Start Menu Open the EC Alignment Utility (fig. 1). It will be located in the folder designated when you installed the alignment utility. Select OptiEC printer type. Click on Start Test. (fig 2) 2. Follow the instructions by opening the OptiEC printer tray, and Clicking Yes (fig. 2).
