4.2 DLNA STREAMING
Perform the following steps for the DLNA streaming:
1. Set up the CE2 board, see 2.1 “Connecting CY920 Module, CE2 Board, and
Interconnect Card”.
2. Configure the CY920 module network using Ethernet or Wi-Fi mode, see Chap-
ter 3. “Network Configuration”.
3. Connect the computer and the CY920 module to the same network.
4. Connect the speaker to an audio out pin of the CE2 board, see Figure 1-4.
5. To enable the audio decoders, configure the CnE values “
cne\cneGroup” to “1”
as shown in Example 4-1.
EXAMPLE 4-1: ENABLING AUDIO DECODER VALUES
6. Reboot the CY920 module.
7. Run Microsoft
®
Windows Media Player 12 (WMP 12) on the computer and
perform the WMP 12 “Play To” setup procedure provided in the Microsoft web
site: http://windows.microsoft.com/en-IN/windows7/using-the-play-to-feature-to-
stream-media.
cd cne\cneGroup
set IsflacEnabled 1
set IsaacEnabled 1
set IsoggEnabled 1
set Ismp3Enabled 1
set IsaiffEnabled 1
set IswmaEnabled 1
set IsUPnPEnabled 1
set IsalacEnabled 1
set Ismp4Enabled 1
set IsDSDEnabled 1
