4.2 Open RFID Tracer
Step 1: Start RFID Tracer by double clicking on the RFID Tracer.exe. icon
Step 2: When start RFID Tracer with RU-859 module at first time, you might need to install USB2.0
driver for communication. You could find the USB driver zipped at folder “Software\Drivers
and SDK\Linux\”, or “Software\Drivers and SDK\Windows\”, depend on your operation
system.
4.3 Select Antenna Port
Step 1: Select the Configure Reader menu item or click on the wrench icon on the tool bar, as shown
in Figure 6.
Figure 6 Reader Configuration Dialog
