Parameter Description
Priority
Users can change priority value to identify the root bridge. The
bridge with the lowest value has the highest priority and is selected
as the root.
Range: 1~65535.
Max Age
Users can change Max Age value, the number of seconds a bridge
waits without receiving. Spanning-Tree Protocol configuration
messages before attempting a reconfiguration.
Range: 6~40.
Hello Time
Users can change Hello Time value, the number of seconds
between transmissions of Spanning-Tree Protocol configuration
messages.
Range: 1~10.
Forward
Delay Time
Users can change forward delay time, The number of seconds a port
waits before changing from its Spanning-Tree Protocol learning and
listening states to the forwarding state.
Range: 4 ~30.
4. The following parameter can be configured on each port and click
<Apply> button to modify.
29
