Parameter Description
Username
This field provides the users to enter the desired username.
Default: admin
Assign/Change
Password
Allow users to enter the desired password.
Default: 123
Reconfirm Password
Re-enter the password in this section for verification.
5.15 TFTP Update Firmware
The following menu options provide some system control functions to allow a
user to update firmware and remote boot SP3508A’s system
1. Install TFTP Turbo98 and execution.
2. Copy firmware update version image.bin to TFTP Turbo98 directory.
3. In web management select <TFTP> on the left menu to update
firmware.
4. Download new image.bin file then in web management press
<update firmware>.
