Operating and Installation Instructions Electric Barbecue CS 1312 CS 1322 To prevent accidents and machine damage, read these instructions before installation or use. en - US M.-Nr.
Contents IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Guide to the Electric Barbecue. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 CS 1312 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 CS 1322 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Before using for the first use . . . . . . .
IMPORTANT SAFETY INSTRUCTIONS Children WARNING- When using your appliance follow basic precautions, including the following: Read all instructions before installation or use to prevent injury and appliance damage. This appliance conforms to all uniform safety codes and regulations. Keep these operating instructions in a safe place and pass them on to any future user. SAVE THESE INSTRUCTIONS Correct usage ~ Only use this appliance for residential cooking, and for the purposes described in this manual.
IMPORTANT SAFETY INSTRUCTIONS Technical Safety ~ Installation, repair and maintenance work should only be performed by a Miele authorized service technician. Work by unqualified persons could be dangerous and may void the warranty. ~ Be sure your appliance is properly installed and grounded by a qualified technician. ~ Before installing the appliance, check for externally visible damage. Do not operate a damaged appliance.
IMPORTANT SAFETY INSTRUCTIONS Safety ~ DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS Surface units may be hot even though they are dark in color. Areas near surface units may become hot enough to cause burns. During and after use, do not touch, or let clothing or other flammable materials contact surface units or areas near units until they have had sufficient time to cool. ~ Protect your hands with oven mitts or potholders when using the appliance. Use only dry, heat resistant potholders.
IMPORTANT SAFETY INSTRUCTIONS ~ To prevent burns and breathing difficulty, allow the appliance to cool before cleaning. Some cleaners may produce toxic fumes if applied to a hot surface. ~ When wiping spills on a hot appliance with a wet sponge or cloth, be careful to avoid steam burns. ~ Do not let flammable materials, i.e. cooking grease, accumulate on the appliance. ~ Do not use a steam cleaner to clean this appliance. Steam could penetrate electrical components and cause a short circuit.
Guide to the Electric Barbecue CS 1312 a Grate Control knobs: b Heating element, front h front c Heating element, rear i rear d Lava rock container e Drain valve Indicators f Cooking zone indicators g Display j On/Off indicator 7
Guide to the Electric Barbecue CS 1322 a Grates Control knobs: b Heating element, front h front c Heating element, rear i rear d Lava rock container e Drain valve f Cooking area indicators Indicators g Display j On/Off indicator 8
Before using for the first use Clean the appliance Heat the appliance ^ Clean the water trough and grates with a mild solution of warm water and liquid dish liquid, then dry with a soft cloth (see "Cleaning and care"). Metal components of the appliance have a protective coating which may give off a slight odor the first time the appliance is heated. ^ Wipe the other surfaces down with a damp cloth and dry.
Use Prepare the appliance Turning On/Off You can use the electric barbecue with or without the lava rocks. Without the lava rocks: food will stay more moist, from the rising steam. With the lava rocks: the food will have a more pronounced grilled aroma and flavor. The electric barbecue is divided into two heating areas, which can be used and adjusted separately. For large quantities, you can use the entire surface for cooking.
Use Grilling While grilling, watch the level of water in the trough. If necessary, add more water. Do not use aluminum dishes, pans, pots or foil on the electric barbecue. Never cover the grate with aluminum foil. Aluminum will cause overheating and may damage the grate. ^ Turn one or both operating knobs to power level "12". Pre-heat the electric barbecue with the rack(s) in place for approx. 10 minutes. Make sure the operating knob(s) are set precisely to power level 12.
Use Grilling times Food item Grilling time in minutes Meat and sausage Food item Grilling time in minutes Vegetables Boneless steak 8 - 10 Corn (parboiled) 5-8 Chicken breasts 16 - 18 Eggplant 6-8 Cutlets 8 - 12 10 - 20 Filet steak 4 - 10 Potatoes in foil (parboiled) Hamburgers 12 - 16 Tomato halves 2-4 Kebabs 14 - 18 Onions 14 - 16 Lamb chop 4-8 Pepper strips 2-3 Sausages 6-8 Vegetable kebabs 5-6 Spare Ribs 15 - 20 Fruit T-Bone Steak 10 - 20 Apple slices 2-3 Turke
Safety Feature Overheat protection Safety cut-out feature If there is not enough water in the water trough, the overheat protection automatically switches the appliance off. The safety cut-off ensures that the heating element will only work if it is lowered. ^ Pour in cold water. Once the appliance has cooled down and the heating element switches back on, you can continue grilling as normal.
Cleaning and care ,Under no circumstances should you use a steam cleaner to clean this appliance. Pressurized steam could cause permanent damage to the surface and to components. Never use strong cleaners e.g. oven sprays, stain or rust removers. Scouring pads and abrasive cleaning agents should only be used on the heating element. Do not use any sharp pointed objects which could damage the seal between the ceramic surface and the surrounding frame, and between the frame and the countertop.
Cleaning and care Lava rocks Water trough Clean the lava rocks on a regular basis. ^ Let the water cool to a safe temperature to prevent burns. To do so, put the rocks in a container with mild solution of warm water and liquid dish soap. Let them soak briefly, stirring occasionally. Drain water and rinse rocks. Repeat this process 2 to 3 times with fresh water. Lay the rocks on a large kitchen towel to dry. ^ Place a container (large enough to hold all water in the trough) under the drain valve.
Frequently asked questions ,Repairs should only be carried out by an authorized technician in accordance with local and national safety regulations. Unauthorized repairs could cause injury or appliance damage. What if the appliance does not heat up after it is turned on? Possible fault Solution The overheat protection was triggered. See "Overheat protection" The fuse or breaker was tripped. Contact a qualified electrician or Miele Technical Service for assistance.
Technical Service In the event of a fault which you cannot easily fix yourself, please contact the Miele Technical Service Department at the address on the back of this booklet. When contacting Technical Service please quote the serial number and model of the appliance. Adhere rating label sticker supplied with the appliance below.
Technical Service MieleCare (USA only) MieleCare, our Extended Service Contract program; gives you the assurance of knowing that your appliance investment is covered by 5 years of worry free ownership. MieleCare is the only Extended Service Contract in the industry that guarantees repairs by a Miele Authorized Service Provider using genuine Miele parts. Only genuine Miele parts installed by factory trained professionals can guarantee the safety, reliability and longevity of your Miele appliance.
Additional Accessories Miele offers a variety of additional accessories for its appliances. All accessories can be ordered from Miele. Stainless steel and ceramic surface cleaners Help to remove soiling, lime spots, mild staining, fingerprints, etc. while maintaining the appearance of the appliance between cleanings. Lava rocks Lava rocks come standard with the electric barbecue, they can also be reordered as necessary.
Installation Instructions IMPORTANT: SAVE FOR THE LOCAL ELECTRICAL INSPECTOR'S USE Information is subject to change. Please refer to our website to obtain the most current product specification, technical & warranty information. To prevent accidents and appliance damage read these instructions before installation or use.
IMPORTANT INSTALLATION SAFETY INSTRUCTIONS Note to the installer: Please leave this instruction book with the consumer for the local electrical inspector’s use. The minimum distances given in these Installation Instructions must be observed in order to ensure safe operation. Failure to do so increases the risk of fire. The cabinetry and venting hood should be installed first to prevent damage to the appliance.
IMPORTANT INSTALLATION SAFETY INSTRUCTIONS Safety distances above the appliance The minimum safety distance given by the hood manufacturer must be maintained between the electric barbecue and the hood above it. See the installation instructions of the hood for these safety measurements. If the hood manufacturers instructions are not available or if flammable objects are installed over the electric barbecue (e.g. cabinets, utensil rail, etc.), a minimum safety distance of 30" (760 mm) must be maintained.
IMPORTANT INSTALLATION SAFETY INSTRUCTIONS Safety distances to the sides of the appliance The appliance should only be installed as shown in the illustrations while maintaining the required safety distances shown. Do not install the appliance between two tall cabinets, this is a fire hazard. A distance of at least 2" (50 mm) must be kept between the countertop cut-out and the rear wall because of the high temperatures radiated.
Installation Safety distance from the wall covering If a wall covering is installed, a minimum safety distance must be maintained between the countertop cut-out and the covering, since high temperatures can damage these materials. If the covering is made of a combustible material (such as wood), the distance between the countertop cut-out and the wall covering must be a minimum of 2" (50 mm).
Installation Installation dimensions CS 1312 a Spring clips b Appliance front c Installation height d Power supply box with connection cable, L = 78 3/4" (2000 mm) e Drain valve f Rating label 26
Installation Installation dimensions CS 1322 a Spring clips b Appliance front c Installation height d Power supply box with connection cable, L = 78 3/4" (2000 mm) e Drain valve f Rating label 27
Installation Cut out ^ Make the countertop cut-out for the desired number of appliances. Remember to maintain a minimum safety distance from the back wall, as well as from any tall unit or side wall to the left or right of the combiset. See also the "IMPORTANT INSTALLATION SAFETY INSTRUCTIONS". ^ Seal the cut surfaces with a suitable sealant to avoid swelling caused by moisture. The materials used must be heat resistant.
Installation Installation of multiple appliances When installing more than one combiset appliance, a support bar b must be installed between the appliances. Countertop cut-out two appliances Countertop cut-out three appliances For the installation of two appliances the width of the countertop cut-out D is the sum of A and C. For the installation of three appliances the width of the countertop cut-out D is the sum of A and B and C.
Installation Sample calculations for a countertop cut-out for three appliances A appliance width minus 5/16" (8 mm) B appliance width C appliance width minus 5/16" (8 mm) D Countertop cut-out 11" (280 mm) 11 5/16" (288 mm) 11" (280 mm) 33 3/8" (848 mm) 11" (280 mm) 15" (380 mm) 14 5/8" (372 mm) 40 5/8" (1032 mm) 11" (280 mm) 22 11/16" (576 mm) 22 3/8" (568 mm) 56 1/16" (1424 mm) 11" (280 mm) 37" (940 mm) 14 5/8" (372 mm) 44 1/4" (1124 mm) 14 5/8" (372 mm) 22 11/16" (576 mm) 22 3/8' (568
Installation a Spring clips b Support bars c Space between support bar and countertop d Sealing strip The illustration represents the attachment of spring clips a and support bars b for 3 appliances. An additional support bar is required for each additional appliance. The position for attachment of an additional support bar depends on the width of appliance B.
Installation Attach the spring clips and support bars Wood or solid surface countertops ^ Place the supplied spring clips a and the support bars b at the marked positions as shown above, by laying them on the upper edge of the cut-out and then securing them with the 1/8" x 1" (3.5 x 25 mm) screws (supplied).
Installation Granite countertop The screws are not needed for granite countertops. ^ Coat the edges of the spring clips a, ^ and the space e between the support bars b and the countertop with silicone (supplied). ^ Position and attach the spring clips a and support bars b with strong, double-sided tape c.
Installation Installing the appliance(s) ^ Feed the power cord down through the cut-out. ^ Place the front edge of the appliance into the cut-out. ^ With a hand on each side of the appliance press down evenly on the edges until it clicks into position. When doing so make sure that the appliance seal sits tightly on the countertop to ensure it is sealed correctly. This is important to ensure an effective seal. Do not permanently seal into the countertop.
Installation After the appliance has been built in, the splash guard and protection plate(s) should be fitted. The protection plate(s) is only required if the barbecue grill is installed on its own, i.e. detached from a multiple combiset configuration or another appliance. ^ Place the bracket a on the countertop against the back of the appliance. ^ Align it so that it sits in the middle, and screw it to the countertop. ^ Remove the paper from the adhesive tape underneath the protection plate(s) bc.
Installation Sealing Tiled surfaces The appliance must not be permanently sealed into the countertop when installed. The sealing strip under the edge of the appliance provides a sufficient seal for the countertop. The grouting a and shaded area under the appliance frame must be flat and even so that the frame will lie evenly and the sealing strip under the edge of the upper part of the appliance can provide an adequate seal against the countertop.
Electrical connection ,CAUTION: Before installation or servicing, disconnect the power supply by either removing the fuse, shutting off the main power or manually "tripping" the circuit breaker. Installation work and repairs should only be performed by a qualified technician in accordance with all applicable codes and standards. Repairs and service by unqualified persons could be dangerous.
Help protect our environment Disposal of packing materials Disposal of an old appliance The cardboard box and packing materials are biodegradable and recyclable. Please recycle. Old appliances contain materials that can be recycled. Please contact your local recycling authority about the possibility of recycling these materials. Ensure that any plastic wrappings, bags, etc. are disposed of safely and kept out of the reach of children.
Alteration rights reserved / 4110 M.-Nr. 07 346 950 / 02 INFORMATION IS SUBJECT TO CHANGE. PLEASE REFER TO OUR WEBSITE TO OBTAIN THE MOST CURRENT PRODUCT SPECIFICATIONS, TECHNICAL & WARRANTY INFORMATION.
