Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Fault Possible cause and solution
"Too much ground
coffee"
There is too much ground coffee in the ground coffee chute.
If more than one level scoop is put into the ground coffee
chute the brew unit cannot process it. The ground coffee will
be directed into the waste container, and a fault will appear
in the display.
^
Turn off the coffee machine using the On/Off button K .
^
Remove the brew unit and clean it (see "Cleaning and care
– Brew unit").
^
Remove the ground coffee from inside the coffee machine,
for example by using a vacuum cleaner.
^
Use the coffee scoop supplied to measure out the ground
coffee. Please scoop only one serving of ground coffee
into the ground coffee chute.
"Check water
intake"
The plumbed water intake is faulty.
^ Check for kinks in the water intake hose and open the
water supply all the way.
^ Remove the water tank and empty it.
^ Push the water tank back into the unit until it clicks into
place.
"Push the water
container in until it
engages"
The water tank is not sitting properly in the unit.
^
Take the water tank out, then place it back in the unit.
If the water tank was not correctly filled and inserted during
descaling, this fault message will appear.
^
Fill it to the descaling mark F and restart the descaling
process.
If the fault message still appears on the display, contact
Miele Technical Service.
Frequently asked questions
62
