Installation and Operation
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Controls and display elements 12
- Accessories 13
- First steps to use 14
- Operation 17
- Filling the water tank 18
- Filling the coffee bean container 19
- Turning the coffee machine on and off 20
- Adjusting the coffee dispensers to the cup height 21
- Preparing beverages 22
- Preparing espresso, coffee or lungo (large) coffee 22
- Preparing double portions 22
- Cancel preparation 23
- Preparing multiple cups of coffee, one directly after another (coffee pot) 23
- Preparing coffee beverages from ground coffee 23
- Beverages with milk 25
- Preparing hot water 26
- Preparing beverages from a profile 26
- After use 26
- Customizing your coffee 27
- Setting the serving size 30
- Settings 36
- Accessing the "Settings" menu 36
- Change and save settings 36
- Overview of possible settings 37
- Language 39
- Time of day 39
- Date 39
- Timer 39
- Eco mode 41
- Lighting 41
- Info (displaying information) 42
- Locking the coffee system ( System lock 0 ) 42
- Water hardness 42
- Display brightness 42
- Volume 42
- Activating and deactivating the plumbed water connection 42
- Factory default settings 43
- Showroom program ( demo mode ) 43
- Descaling 58
- Frequently asked questions 60
- Cleaning clogged milk pipework 69
- After sales service 72
- Installation instructions 73
- Caring for the environment 74
- Plumbing 75
- Lead free certificate 77
- Electrical connection 78
- Installation 79
- Adresses 87
Problem Possible cause and solution
The milk lines are
being rinsed but
no rinse water
comes out of the
main dispenser.
The display shows
the message "Fill
and insert water
container".
The milk pipework or the air intake hose is clogged.
^
Follow the instructions in "Cleaning clogged milk
pipework".
No milk or milk
froth is coming out
of the main
dispenser.
The milk pipework or the air intake hose is clogged.
^
Follow the instructions in chapter "Cleaning clogged milk
pipework".
The display shows
the message "Fill
and insert milk
container"
although the milk
container is full
and in place.
The milk container lid may be contaminated, causing the
sensors to malfunction.
^ Thoroughly clean the lid and milk container (see "Cleaning
clogged milk pipework").
"Empty drip tray"
appears on the
display even
though the drip
tray is empty.
The drip tray is not inserted correctly.
^
Slide the drip tray all the way into the unit.
The drip tray's sensors are not working properly.
^
Turn off the coffee machine using the On/Off button K.
The metal contacts are dirty.
^
Clean and dry the contacts thoroughly (see "Cleaning and
care – Drip tray").
The door cannot
be closed.
The containers are not fully inserted.
^
Check the containers.
The door cannot
be closed.
The door hinges are not aligned correctly.
^
Adjust the door hinges (see "Installation – Adjusting the
door hinges").
Frequently asked questions
65
