Installation Instructions
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Accessories 12
- Operation 13
- First steps to use 17
- Filling the water tank 20
- Filling the coffee bean container 21
- Turning the coffee machine on and off 22
- Dispenser adjustment 23
- Preparing beverages 24
- Espresso, Coffee or Lungo coffee 24
- Preparing two portions 24
- Canceling preparation 25
- Preparing multiple cups of coffee, one directly after another ( Coffee pot ² ) 25
- Preparing coffee drinks from ground coffee 25
- Beverages with milk 27
- Preparing hot water 28
- Preparing drinks using a profile 28
- After preparing drinks 28
- Customizing your coffee 29
- Setting the serving size 32
- Resetting drinks 34
- Profiles 35
- MyMiele 38
- Settings 39
- Accessing the "Settings" menu 39
- Changing and saving settings 39
- Overview of the Setting options 40
- Language 42
- Time 42
- Clock type 42
- Time of day 42
- Date 42
- Timers 43
- Eco mode 44
- Lighting 45
- Starting screen 45
- Info (displaying information) 45
- Locking the coffee system ( System lock 0 ) 45
- Water hardness 46
- Brightness 46
- Volume 46
- Adjusting the dispensers 46
- Factory default settings 46
- Showroom program (demo mode) 46
- Descaling 62
- Frequently asked questions 64
- Cleaning clogged milk pipework 73
- After sales service 76
- Installation instructions 77
- Caring for the environment 78
- Electrical connection 79
- Installation 80
- RemoteVision (optional accessory) 85
- Copyright and licenses 86
- Contact details 87
The main dispenser cannot be
adjusted manually.
The coffee system senses the height of
the cup or glass being used. When a
drink has been selected, the main
dispenser automatically moves to the
optimum height before dispensing the
drink.
Make sure that there is not a spoon
or stirrer in the cup. This would
prevent the coffee system from
sensing the cup height correctly.
You can turn off the automatic
dispenser adjustment. The main
dispenser will then remain in the upper
position until the coffee system is
turned off. When a maintenance
program is being performed, the main
dispenser moves to the height of the
cleaning containers or into a
maintenance position.
When the coffee system is turned off,
the main dispenser moves to a middle
position.
Turning the dispenser adjustment on
or off
^
Touch "Main menu" or the Back
sensor.
^
Touch "Settings" %.
^
Swipe the display until "Dispenser
adjustment" appears, and then touch
it.
^
Touch the setting you want in order to
turn the dispenser adjustment on or
off.
^
Touch "OK".
The setting is now saved.
Dispenser adjustment
23
