Installation Instructions
Table Of Contents
- Contents
- IMPORTANT SAFETY INSTRUCTIONS 5
- Guide to the coffee system 10
- Accessories 12
- Operation 13
- First steps to use 17
- Filling the water tank 20
- Filling the coffee bean container 21
- Turning the coffee machine on and off 22
- Dispenser adjustment 23
- Preparing beverages 24
- Espresso, Coffee or Lungo coffee 24
- Preparing two portions 24
- Canceling preparation 25
- Preparing multiple cups of coffee, one directly after another ( Coffee pot ² ) 25
- Preparing coffee drinks from ground coffee 25
- Beverages with milk 27
- Preparing hot water 28
- Preparing drinks using a profile 28
- After preparing drinks 28
- Customizing your coffee 29
- Setting the serving size 32
- Resetting drinks 34
- Profiles 35
- MyMiele 38
- Settings 39
- Accessing the "Settings" menu 39
- Changing and saving settings 39
- Overview of the Setting options 40
- Language 42
- Time 42
- Clock type 42
- Time of day 42
- Date 42
- Timers 43
- Eco mode 44
- Lighting 45
- Starting screen 45
- Info (displaying information) 45
- Locking the coffee system ( System lock 0 ) 45
- Water hardness 46
- Brightness 46
- Volume 46
- Adjusting the dispensers 46
- Factory default settings 46
- Showroom program (demo mode) 46
- Descaling 62
- Frequently asked questions 64
- Cleaning clogged milk pipework 73
- After sales service 76
- Installation instructions 77
- Caring for the environment 78
- Electrical connection 79
- Installation 80
- RemoteVision (optional accessory) 85
- Copyright and licenses 86
- Contact details 87
Cleaning the milk valve
You should clean the milk valve once a
week to ensure good quality milk froth.
^
Touch "Main menu" or the # sensor.
^
Touch "Maintenance" y.
^
Touch "Clean the main dispenser".
The main dispenser and the milk valve
move into the maintenance position.
Important! Before you confirm
"Leave maintenance position" with
"OK", you must remove the cleaning
brush. Otherwise, the coffee system
will be damaged.
^
Insert the brush into the milk valve.
Move the brush back and forth.
^
Touch "OK".
The milk valve will move into the stan
-
dard position and the milk pipework is
rinsed.
Sensor cover
The sensor cover for the cup protection
shut-off is located under the main
dispenser. If the automatic dispenser
adjustment sensors do not clearly
recognize a container, the cup
protection shut-off stops the main
dispenser.
Clean the sensor cover by hand only
as necessary using warm water and
liquid dish soap.
^ To remove, press and hold the
sensor cover between the dispenser
nozzles a. Then press the main
dispenser in from the sides at the
back b.
This releases the sensor cover.
^
To replace, insert both hooks at the
back and press the sensor cover
upwards.
Cleaning and care
54
