Water filter
37
To a capacity of 739.68 gallons (2800 liters).
* Based on the use of Cryptosporium parvum oocysts
Performance Data Sheet For Filter Model 07134220
System tested and certified by NSF International in Model 07134220
against NSF/ANSI Standard 53 for the reduction of Cysts and
Turbidity and against Standard 42 for the reduction of Chlorine Taste
and Odor; Nominal Particulate Class I.
This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances
listed below. The concentration of the indicated substances in water entering the system was reduced to a
concentration less than or equal to the permissible limit for water leaving the system, as specified in
NSF/ANSI 42 and 53.
For estimated costs of replacement
elements please visit your local appliance
dealer or parts distributor.
IMPORTANT: Must be installed and operated
in accordance with application guidelines.
Failure to do so may void warranty.
Change filter at least every 6 months.
Flush new cartridge for 3 minutes.
Substance Average Influent Challenge Product Average Maximum Permissible Max. Min. % NSF
Influent Concentration Water % Product Water Effluent Reduction Test
Concentration mg/L Concentration Reduction Concentration
Cysts* 166500 Minimum 50,000/L 1 99.99 99.95 1 99.99 516458-05
Turbidity 10.7 11 + 1 NTU 0.31 97.09 0.5 NTU 0.49 95.42 516456-05
Particulate
Class I Particle size: At least 10,000
> 0.5 to < 1 um 5700000 particles/ml 30583 99.52 > 85% 69000 98.9 511079-03
Chlorine taste
and odor 1.9 2.0 mg/L ± 10% 0.05 97.3 > 50% 0.06 96.84 511081-03
Note that while the testing was
performed under standard
laboratory conditions, actual
performance may vary.
WARNING: Do not use with water that is
microbiologically unsafe or of unknown quality
without adequate disinfection before or after the
system. Systems certified for cyst reduction may be
used on disinfected waters that may contain filterable
cysts.
CAUTION: To avoid property damage due to water
leakage, you MUST read and follow these operating
instructions before installation and use of this
product.
Using Replacement Cartridge 07134220
Application Guidelines/Water Supply Parameters
Water pressure 30- 120 psi (207 - 827 kPa)
Water temperature* 33°F - 100°F (0.6°C - 38°C)
Service flow 0.75 gpm (2.83 lpm)
NSF is a registered trademark of NSF International.
CUNO is a trademark of 3M Company used under license.
© 2007 3M Company. All rights reserved.
