User's Manual

Wireless
Mini PCI Adapter
RouterBOARD R2n
Quick Install Guide
Federal Communications Commission Notice (FCC ID
TV7-R2N)
This device uses, generates, and radiates radio frequency energy. The
radio frequency energy produced by this device is well below the
maximum exposure allowed by the Federal Communications
Commission (FCC).
Operation is subject to the following conditions:
• This device may not cause harmful interference.
• This device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
of a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a residential
environment.
List of authorized antennas to use with this device:
Type Gain Model
Omni 2 dBi
RF exposure information: The antenna(s) used for this transmitter
must be installed to provide a separation distance of at least 20 cm
from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
Warning! Installation must be performed by qualified service
personnel only. Read and follow all warning notices and instructions
marked on the product or included in the documentation. Before
installing the product, read the rest of this document.
Caution! Any modification to this device can void your authority to
operate the device.
Warning! Wear an anti-static wrist strap or take other suitable
measures to prevent electrostatic discharge when handling this
equipment.
Introduction
The RouterBOARD R2n miniPCI network adapter provides leading
802.11b/g/n performance, supporting up to 300Mbps physical data
rates and up to 200Mbps of actual user throughput on both the uplink
and downlink. Adding Wireless N to your Wireless device, it
provides higher efficiency for everyday activities such as local
network file transfers, Internet browsing, and media streaming.
Package Content
RouterBOARD R2n package contains the following items:
• 1 x RouterBOARD R2n Wireless Mini PCI adapter
Application of Mini PCI
1. Align the R2n adapter to the Mini PCI socket.
2. Adjust and push down the R5H adapter gently until the metal-
locking levers aside from the Mini PCI socket is fastened.
R2n adapter can only fit in one direction due to the
keyed notch. Wrong orientation will cause improper
installation and may damage the Mini PCI socket !
3. Connect antennas to R2n adapter.
RouterBOARD
