Foreword
Congratulations on your purchase of a MIMAKI "UJF-706" model of UV printer.
UV printer UJF-706 uses ultraviolet ray curing ink (UV ink).
Read this Operation Manual carefully and make the most effective use of your printer.
Before starting to operate the printer, be sure to read this Operation Manual carefully .
On this operation manual
• This Operation Manual describes the operation and maintenance of Model UJF-706 UV printer (hereinafter
referred to as the device).
• Please read and fully understand this Operation Manual before putting the machine into service. It is also
necessary to keep this Operation Manual on hand.
• Make arrangements to deliver this Operation Manual to the person in charge of the operation of this device.
• This Operation Manual has been carefully prepared for your easy understanding, however, please do not hesitate
to contact a distributor in your district or our office if you have any inquiry.
• Description contained in this Operation Manual are subject to change without notice for improvement.
• In the case where this Operation Manual should be illegible due to destruction or lost by fire or breakage,
purchase another copy of the Operation Manual from our office.
• You can also download the latest operation manual from our website.
Reproduction of this manual is strictly prohibited.
All Rights Reserved. Copyright
© 2012 MIMAKI ENGINEERING CO., LTD.
