When the waste ink tray is full
4-15
4
How to care
7
Take the wiper tank out, and dispose
of the waste ink.
• Turn the tank holding the tank cover, take out
the tank, and then dispose of the ink in the
tank.
• Dispose of the waste ink pursuant to the
regulations of your district.
8
Set the wiper tank.
• Turn the tank holding the tank cover, and close the tank cover.
• Fit the waste ink box cover.
9
Press the key.
10
Press the key to finish.
CHANGE WI P TANK
COMP L E T ED : e n t
ENTER
END
