4-47
4
Daily Maintenance
Prevent the nozzle clogging of spot color
To prevent the head nozzle clog, this unit performs refresh while printer is turned on. However the
characteristic of white ink is different from other inks, therefore nozzle out occurs even performing the
refresh.
Change the head refresh operation, where white ink is installed, so as to suitable for the white ink. This will
prevent the nozzle out.
1
When <LOCAL> is displayed, press the
key.
2
Select the [MAINTENANCE] with the
key, and press the
key.
3
Select the [SPECIAL REFRESH] with
the key, and press the
key.
4
Select either of with or without special
refresh for each head and press the
key.
(1) Select the head with the key.
(2) Press the key to select either of with or without special refresh.
5
Press the key to finish.
<LOCAL>
FUNCTION
FUNCT I ON
MA I NT ENANCE < ENT >
ENTER
MA I NT ENANCE
SPEC I AL REFRESH<e n t >
ENTER
SPEC I AL REFRESH
CLOR :--------WW--
ENTER
END
