User guide
Table Of Contents
- About MimioProjector
- Getting Started
- Changing the Projector Settings
- Caring for MimioProjector
- Getting Help
- General Troubleshooting
- Image Troubleshooting
- No image is displayed
- A partial, scrolling, or incorrect image is displayed
- The notebook computer display is not displaying an image
- Image is unstable or flickering
- Image has vertical flickering bar
- Image is out of focus
- Image is stretched when displaying 16:9 DVD image
- Image is too small or too large
- Image is displayed with slanted sides
- Image is reversed
- 3D Troubleshooting
- Sound Troubleshooting
- Remote Control Troubleshooting
- Contacting Mimio
- Compatibility Modes
- Technical and Environmental Information
About MimioProjector
About the Control Panel
The following figure shows the components of the MimioProjector control panel.
MENU
POWER TEMP LAMP
RESYNC
SOURCE
1
MENU
2
4
6
9
8
7
5
3
1 Navigation keys Navigate through menus and make selections.
2 Power button Turn the projector on and off.
3 Power status light Indicates the power status of the projector.
4 Lamp status light Indicates the projector lamp status.
5 Temperature status light Indicates the projector temperature status.
6 Source button Select an input signal.
7 Resync button
Automatically synchronize the PC analog timing
to the optimized condition.
8 Menu/Exit button Open the menu screen or exit a menu.
9 IR receiver
