3.3 CONFIGURING FOR MEASUREMENT
Start Dirac Live Calibration Tool For miniDSP.
Ensure that no other programs are running that may attempt to communicate with the DDRC-88A,
such as the DDRC-88A Utility program, as this may result in communication conflicts and errors.
Logo and status progress bar
This area shows a progress bar with current status when the program is performing calculations. If the
program seems unresponsive at any time, check the status here.
Screen selection tabs
Each tab selects the information shown in the main display area. These are generally worked through in
order, from top to bottom. This section covers the first four tabs; the final two are covered in Filter
Design.
Load and save a project
A set of measurements can be saved to a file and reloaded at a later time. See Saving and loading projects.
Back to previous / proceed to next
Use these two buttons to advance to the next tab when each is complete, or to go back to the previous
tab to make alterations. The tabs at the left can also be clicked on directly.
Help open/close
Click on the small Help divider at the right of the screen to open a pane with help on the currently
selected tab. Click on the divider again to close the help pane.
