Installation guide

About the Control Panel
13
English
Control Panel Indicators
Control Panel Keys
Indicator Off On
The printer is off line and not ready to accept
data.
The printer is on line and ready to accept
data.
The printer is not receiving data. The printer is receiving data from one or
more of its interfaces.
No problem. The printer requires operator attention (usu-
ally accompanied by a status message in
the message window).
Key Function PressOn
line
First?
This key has no function on the magicolor 2200 DeskLaser but is used to set
the mutipurpose tray media size on magicolor 2200 Crown printers. Media
sizes are controlled through the printer driver on magicolor 2200 DeskLaser
printers.
N/A
Accesses the configuration menu. When you’re changing the printer configura-
tion, press this key to cancel a change (before pressing the Select key), to
return to the previous selection or option for the current menu and to return to
the previous choice when changing character information.
Yes
The
Select
key selects a menu or a displayed menu option. Yes
Use this key to advance to the next selection for the current menu or to
advance to the next choice when changing character information.
The
Online
key switches the printer between online and offline status. Press
the key once to take the printer off line when it is on line, and press the key
once to return the printer to on line when it is off line.
N/A
The
Cancel
key allows you to cancel a print job. No
Previous/Next
navigation keys allow you go backward or forward through the
menu choices.
Yes
MP SIZE
