Installation guide

Regulatory Compliance24
English
Consumables
 Consumable life is expressed in simplex letter/A4 pages. A duplex page is equivalent to two
simplex pages.
Regulatory Compliance
Media Tray, 500 Sheet Purchasing extra trays may be convenient when
changing media formats and/or media qualities vary.
Printer Stand/Cabinet Various models are available.
Crown Conversion Kit Converts a magicolor 2200 DeskLaser to a
magicolor 2200 Crown printer model.
Description Remark(s)
Fuser oil roller
FUSER OIL LOW, FUSER OIL EMPTY,
or
REPLACE OIL ROLLER
dis-
plays in the message window (after up to 21,000 single-sided continuous
monochrome or 7,500 continuous color pages, or 7,000 intermittent
[one-page jobs] monochrome or 5,000 intermittent [one-page jobs] color
pages). Heavy coverage, intermittent printing, and different media types
can use oil at an accelerated rate, reducing fuser and oil roller life.
Fuser unit/transfer roller kit
REPLACE FUSER
displays in the message window (after 100,000 sin-
gle-sided pages maximum at an equal mix of black and 4-color pages, all
with 5% coverage of each color; however, fuser unit life is media dependent).
Toner cartridge: Cyan,
Magenta, Yellow,
and Black
<
COLOR > TONER EMPTY
displays in the message window (after approxi-
mately 6,000 single-sided pages per cartridge—black, yellow, magenta,
cyan at 5% coverage of each color).
OPC drum kit
(OPC drum cartridge, laser lens
cover, and waste toner pack)
REPLACE DRUM, CHECK WASTE TONER, WASTE TONER NEAR FULL,
or
REPLACE WASTE TONER
displays in the message window (up to
30,000 continuous monochrome* or 7,500 continuous four-color pages, or
10,000 intermittent monochrome or 5,000 intermittent color pages). Other
factors also affect cartridge life.
Transfer belt
REPLACE TRANSFER BELT
displays in the message window (after
107,000 pages continuous monochrome or 33,000 continuous color pages,
or 44,000 intermittent monochrome or 23,000 intermittent color pages).
CE Marking and
Immunity
Requirements
(EU)
International (EU)
EN 55024
EN 50081-1
EN 61000-3-2
EN 61000-3-3
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
Immunity Characteristics
Generic Emission Standard
Harmonic Current Emissions
Voltage Fluctuations and Flicker
ESD
Radiated Susceptibility
Fast Transients
Surge Immunity
Immunity to Conducted Disturbance
Magnetic Field Immunity
Voltage Dips and Variations
cTick Mark ACA (Australia)
AS/NZS 4251
AS/NZS 3458
Generic Emissions Standard
ITE
Description Remark(s)
