USER'S MANUAL Copyright 1997 MINOLTA CO., LTD Printed in Japan The information contained in this manual is subject to change without notice to incorporate improvements made on the product or products the manual covers. Minolta CO., LTD. Image Information Products Marketing Headquarters, 3-13, 2-chome, Azuchi-machi, Chuo-ku, Osaka. 541, Japan 1997.
Energy.frm 1 ページ ２００３年１１月１８日 火曜日 午前９時４７分 For U.S.A./Canadian Users As an ENERGY STAR Partner, Minolta Co., Ltd has determined that this printer meets the ENERGY STAR Guidelines for energy efficiency. For Other Country Users This printer meets the *EPA’s ENERGY STAR Guidelines for energy efficiency. *The U.S. Environmental Protection Agency What is an Energy Star Printer? Energy Star Printers have a feature that allows them to automatically “go to sleep” after a period of inactivity.
Foreword.frm i ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword Safety Information Laser Safety This printer is a page printer which operates by means of a laser. There is no possibility of danger from the laser, provided the printer is operated according to the instructions in this manual provided. Since radiation emitted by the laser is completely confined within protective housing, the laser beam cannot escape from the machine during any phase of user operation.
Foreword.frm ii ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword For other Countries Users WARNING: Use of controls, adjustments or performance of procedures other than those specified in this manual may result in hazardous radiation exposure. This is a semiconductor laser. The maximum power of the laser diode is 8.8 x 10-4W and the wavelength is 770-810 nm. For Denmark Users ADVARSEL: Usynlig laserstråling ved åbning, når sikkerhedsafbrydere er ude af funktion. Undgå udsttelse for stråling.
Foreword.frm iii ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword For Norway Users ADVARSEL: Dersum apparatet brukes på annen måte enn spesifisert i denne bruksanvisning, kan brukeren utsettes for unsynlig laserstråling som overskrider grensen for laser klasse 1. Dette er en halvleder laser. Maksimal effeckt til laserdiode er 8.8 x 10-4W og bolgelengde er 770-810 nm.
Foreword.frm iv ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword FCC/ICES (1/2) NOTE: Without Minolta Network option. FCC: Declaration of Conformity Product Type Laser Beam Printer Product Name PageWorks 20 Options Accessories Third Tray Unit, Duplex Unit SIMM (max 64MB), DIMM, Hard Disk (1080MB) This device complies with Part 15 of the FCC Rules.
Foreword.frm v ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword • Re-orient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. • Any changes or modifications not expressly approved by Minolta could void the user’s authority to operate this equipment.
Foreword.frm vi ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword FCC/ICES (2/2) NOTE: Installed Minolta Network options. When the Network cable is attached to either of the IEEE 802.3 connectors, the printer meets the requirements of FCC/ICES Class A. USER INSTRUCTIONS (FOR U.S.A. Users) FCC PART 15-RADIO FREQUENCY DEVICE WARNING This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Foreword.frm vii ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword OZONE RELEASE (For all Users) During printer operation, a small quantity of ozone is released. This amount is not large enough to harm a person adversely. However, be sure the room where the machine is being used has adequate ventilation, especially if you are printing a high volume of materials, or if the machine is being used continuously over a long period.
Foreword.frm viii ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword Welcome Thank you for selecting a Minolta PageWorks 20 Printer! This User’s manual explains the functions of the printer and how it operates. It also provides you with troubleshooting tips as well as general precautions you should observe when operating the printer. To ensure top performance and effective use of your printer, read this manual carefully from cover to cover, and keep it on hand for later reference.
Foreword.frm ix ページ ２００３年１１月１８日 火曜日 午前９時４７分 Foreword U.S.A. Technical Support If you continue to experience technical difficulty with the operation of your printer product, please contact your support representative: Toll free at 1-800-459-3250 or via our website at http://www.minoltappd.com. Hours of operation and toll free nature of our support program is subject to change without prior notice.
Foreword.frm x ページ ２００３年１１月１８日 火曜日 午前９時４７分 Contents Chapter 1 Introduction 1. Printer Features.............................................1-1 2. Printer Parts and Accessories .....................1-2 3. Control Panel .................................................1-6 Layout for Control Panel ..................................1-6 Indicator Function ............................................1-7 LCD Function ..................................................1-7 Key Functions .......................
Foreword.frm xi ページ ２００３年１１月１８日 火曜日 午前９時４７分 Contents 7. Connecting the Interface Cable ...................2-16 Interface Port ...................................................2-16 8. Moving the Printer .........................................2-17 Chapter 3 Using the Printer 1. Using the Control Panel................................3-1 Basic Menu Setting Method ............................3-1 Tray 1 Paper Size Setting Method ...................3-2 Job Separation ..................................
Foreword.frm xii ページ ２００３年１１月１８日 火曜日 午前９時４７分 Contents Printing on Thick paper ...................................3-26 Printing on Transparencies ..............................3-26 Printing on Custom Paper ...............................3-26 Duplex Printing ................................................3-27 Paper Type ....................................................3-28 Paper Size.....................................................3-28 Loading Paper in Tray 1...................................
Foreword.frm xiii ページ ２００３年１１月１８日 火曜日 午前９時４７分 Contents Paper Misfeed in Tray 2 or Tray 3 ....................5-3 Paper Misfeed inside the Printer .....................5-5 Paper Misfeed in the Duplex Unit ....................5-6 2. Printing Problems.......................................... 5-8 3. Print Quality Problems.................................. 5-9 4. Understanding Printer Messages ................5-12 (1) Status Messages .......................................5-13 (2) Warning Messages .......
Foreword.frm xiv ページ ２００３年１１月１８日 火曜日 午前９時４７分 Contents 4. SIMM ...............................................................7-9 5. Interface Connector and Cable ....................7-10 Appendix A Character Sets ...................................................A-1 Appendix B Font Lists ...........................................................B-1 Index Index ...................................................................
２００３年１１月１８日 火曜日 午前９時５０分 Chapter 1 -1 ページ Introduction Intro1.
0 ページ Introduction Chapter 1 Intro1.
２００３年１１月１８日 火曜日 午前９時５０分 1. Printer Features • Outstanding performance with an engine speed of 20ppm and High Speed RISC Processor NR4645/100MHz. • Image Quality comparable to 1200dpi with Minolta’s Super Fine Micro-ToningTM system realizes clear and smooth text data. • High Quality graphics and photographic images with RealTone 2400 (256 gray levels). • Paper handling versatility comes with A3 Full-Bleed printing, Duplexing, and GUI Driver supporting N-up Printing, etc.
2 ページ ２００３年１１月１８日 火曜日 午前９時５０分 2. Printer Parts and Accessories 1. Upper Cover Lock Release Button Introduction Chapter 1 Intro1.frm 2. Control Panel 3. Tray 2 4. Paper Exit Tray 5. Paper Guide Plates 6. Tray 1 (multipurpose) 7.
２００３年１１月１８日 火曜日 午前９時５０分 2. Printer Parts and Accessories 1. Upper Cover Lock Release Button: Press this button to open the upper cover. 2. Control Panel: The control panel allows you to set the printing options and displays the current printer status. 3. Tray 2: Holds up to 500 sheets of Letter size paper. 4. Paper Exit Tray: The printed paper is fed out face down on this tray. 500 sheet capacity for printed paper. 5.
4 ページ ２００３年１１月１８日 火曜日 午前９時５０分 2. Printer Parts and Accessories 8. Upper Cover Unit Introduction Chapter 1 Intro1.frm 9. Power Cord Socket 10. Parallel Interface Connector 11. Network Cover 12. Fusing Section 13. Imaging Cartridge 14.
２００３年１１月１８日 火曜日 午前９時５０分 2. Printer Parts and Accessories 8. Upper Cover Unit: Open for replacing the imaging cartridge or removing jammed paper. 9. Power Cord Socket: Connect the power cord to this socket. 10. Parallel Interface Connector: Provides a parallel interface connection for the host computer. 11. Network Cover: Remove this cover for installing the optional network card. 12. Fusing Section: Fixes the toner image to the paper. 13. Imaging Cartridge: It is important for forming an image. 14.
Chapter 1 Intro1.frm 6 ページ ２００３年１１月１８日 火曜日 午前９時５０分 3. Control Panel The control panel is comprised of 1 LCD (16 characters by 2 lines), 3 LEDs and 8 keys. 3 READY • Data 2 4 PCL 1 • Message • On Line Proceed Tray1 Paper Shift 8 Menu Item Select ▼ ▼ ▼ Introduction Layout for Control Panel ▼ ▼ ▼ 9 5 10 1. LCD 2. Data LED 3. Message LED 4. On Line LED 5. On Line key 6. Proceed key 1-6 6 11 Enter ∗ Reset 7 7. Tray1 Paper key 8. Shift key 9. Menu key 10. Item key 11.
２００３年１１月１８日 火曜日 午前９時５０分 3. Control Panel Chapter 1 7 ページ Indicator Function Indicator On Off Introduction Intro1.frm Blinking ONLINE The printer is ready The printer cannot Going off-line. receive data. to receive data. DATA Data is stored in the No data is stored in The printer is printer memory. the printer memory. receiving data and processing data. No error. MESSAGE Engine error. The printer requires service. Recoverable error such as paper empty, paper misfeed, etc.
Chapter 1 Intro1.frm 8 ページ ２００３年１１月１８日 火曜日 午前９時５０分 3. Control Panel Introduction Key Functions On Line key Press the On Line key to switch between on-line and off-line. The printer should be on-line to receive data. Proceed key Press the Proceed key to resume printing after an interruption. This key is pressed: - when a paper size error (LOAD message) occurs. See “Operator Call Message” page 5-17. - when the Paper Size Error occurs. See “Operator Call Message” page 5-18.
２００３年１１月１８日 火曜日 午前９時５０分 3. Control Panel When the Select key is pressed continuously, the numerical value increases at high speed. Enter/Reset key Press the Enter/Reset key to save the settings of the user selections. While holding down the Shift key when off-line, press the Enter/ Reset key. The job data is canceled. Returns the printer on-line automatically after canceling the job data. NOTE To reset the job data, you must take the printer off-line by pressing the On Line key while printing.
10 ページ ２００３年１１月１８日 Memo Introduction Chapter 1 Intro1.
２００３年１１月１８日 火曜日 午前９時５２分 Chapter 2 -1 ページ Setting Up Setting2.
0 ページ Setting Up Chapter 2 Setting2.
1 ページ ２００３年１１月１８日 火曜日 午前９時５２分 Selecting a Location for the Printer A proper location helps to ensure that your printer provides you with the long service life for which it is designed. Double check to make sure that the location you select has the following characteristics. • Choose a location that is well-ventilated. • Make sure there is no chance of ammonia or other organic gasses being generated in the area. • The power outlet you plan to connect to for power should be nearby and unobstructed.
Setting2.frm 2 ページ ２００３年１１月１８日 火曜日 午前９時５２分 Setting Up Chapter 2 1. Installation Precaution NOTES • Use a power source with minimal voltage and frequency fluctuation. • Only use an outlet that is rated for the voltage capacity specified for this printer. • Be sure to plug the power cord all the way into the outlet. The outlet should be located near the printer and easily accessible so you can unplug the power cord immediately should any problem occur.
3 ページ ２００３年１１月１８日 火曜日 午前９時５２分 Space Requirements Setting Up To make printer operation, supply replacement and service maintenance easier, the minimum installation space below is necessary. Locate the printer in an installation site with adequate space. 17.3 (440) 30.5 (774) Without options 21.5 (545) 23.7 (603) 3.5 (90) 0.6 (15) 0.6 (15) Unit: inch (mm) Installed with full options 21.3 (541) 29.6 (753) 0.6 (15) Chapter 2 1. Installation Precaution 34.6 (880) Setting2.frm 21.5 (545) 3.
Setting2.frm 4 ページ ２００３年１１月１８日 火曜日 午前９時５２分 Setting Up Chapter 2 2. Operational Precaution Operating Environment The following describes the operating environment required when using the printer. Temperature: 50°F to 95°F (10°C to 35°C) with a fluctuation of 50°F (10°C) per hour. Humidity: 15% to 85% RH with a fluctuation of 20% per hour.
5 ページ ２００３年１１月１８日 火曜日 午前９時５２分 • Never try to remove any panel or cover that is secured. The interior of the printer contains high-voltage circuitry which creates the danger of electric shock when exposed. • Never try to modify the printer. Doing so creates the danger of fire or electric shock. • Never place any heavy objects on the power cord, or pull on it or bend it. Doing so creates the danger of fire or electric shock.
Setting2.frm 6 ページ ２００３年１１月１８日 火曜日 午前９時５２分 Setting Up Chapter 2 2. Operational Precaution Printer Supplies Note the following precautions when handling the printer supplies such as the imaging cartridge and paper. • Avoid storing the supplies in the following locations. Areas subjected to direct sunlight. Keep the imaging cartridge away from fluorescent light as well. Areas exposed to open flame. Areas subjected to high humidity. Areas subjected to large amounts of dust.
7 ページ ２００３年１１月１８日 火曜日 午前９時５２分 3. Setting Up Your Printer NOTES - Keep all the boxes and packing materials that the printer comes in for later use when transporting the printer. - Since the printer weighs approximately 55.1 lbs (25 kg), two people are required to lift it. 1. Place the printer in the location you have chosen. Upper Cover Upper Cover Lock Release Button 2. Pressing the upper cover lock release button, open the upper cover. 3. Take the imaging cartridge out of the box.
Setting2.frm 8 ページ ２００３年１１月１８日 火曜日 午前９時５２分 3. Setting Up Your Printer Setting Up Chapter 2 4. Pull the tab outward slowly until the sealing tape is completely removed. 5. Shake the imaging cartridge 4 or 5 times in the direction of the arrows to distribute the toner evenly. 6. Install the imaging cartridge securely into the printer by sliding the pins on each side of the cartridge along the grooves of the cartridge guide. 7. Close the upper cover.
9 ページ ２００３年１１月１８日 火曜日 午前９時５２分 4. Connecting the Power Cord 1. Make sure that the power switch of the printer is placed in the ❍ (OFF) position. Chapter 2 Connect the power cord according to the following procedure. Setting Up Setting2.frm 2. Plug one end of the power cord into the printer’s power cord socket and plug the other end of the power cord into the power outlet.
Setting2.frm 10 ページ ２００３年１１月１８日 火曜日 午前９時５２分 Chapter 2 5. Turning the Printer ON and OFF Turning the Printer ON Press the power switch to the (ON) position. Setting Up NOTE This printer will automatically go into power save mode a given period of time after the last activity. See “System Menu” page 3-12. When you turn the printer on, the following takes place. 1. All the LED’s light up and then go out. 2. Asterisks appears on the display from left to right. 3.
11 ページ ２００３年１１月１８日 火曜日 午前９時５２分 To make sure the printer works correctly before connecting the printer to the computer, print a configuration page according to the following procedure. 1. Load Letter paper into tray 1. →See “Loading Paper in Tray 1” page 3-29. 2. Using the control panel, select TEST PRINT from the menu mode. Select CONFIG PRINT from the item mode. Press the Enter key to start printing. →See “Test Print” page 3-19. 3.
Setting2.frm 12 ページ ２００３年１１月１８日 Config Print Setting Up Chapter 2 6.
13 ページ ２００３年１１月１８日 火曜日 午前９時５２分 6. Printing a Test Page Chapter 2 PCL Font List Setting Up Setting2.
Setting2.frm 14 ページ ２００３年１１月１８日 Setting Up Chapter 2 6.
15 ページ ２００３年１１月１８日 火曜日 午前９時５２分 6. Printing a Test Page Chapter 2 PCL Demo Print Setting Up Setting2.
Setting2.frm 16 ページ ２００３年１１月１８日 火曜日 午前９時５２分 Setting Up Chapter 2 7. Connecting the Interface Cable You can connect the printer to your computer using the printer’s parallel ports. For more information, see “Specifications” page 7-10. IMPORTANT You must purchase an IEEE 1284 type-B cable. If you try to use any other cable, you may damage the printer’s port. NOTE Always use a shielded interface cable. Use of an unshielded cable can result in radio interference with data.
17 ページ ２００３年１１月１８日 火曜日 午前９時５２分 8. Moving the Printer NOTES - Since the printer weighs approximately 55.1 lbs (25 kg), two people are required to lift it. - When transporting the printer, remove the imaging cartridge first. - Whenever you remove the imaging cartridge from the printer, immediately cover it with a cloth to prevent light from striking it. - When an option is installed, remove the option from the printer and carry the printer separately.
Setting2.
２００３年１１月１８日 火曜日 午前９時５１分 Chapter 3 -1 ページ Using Your Printer OperatW3.
0 ページ Using Your Printer Chapter 3 OperatW3.
1 ページ ２００３年１１月１８日 火曜日 午前９時５１分 1. Using the Control Panel Use the control panel when: • Your software does not allow you to make the user selection. • You are making printer configuration changes which software cannot control. • You need to identify the fonts available in the printer’s memory. • You need to print a test print. • You need to switch between on-line and off-line. Basic Menu Setting Method 1. Press the On Line key to take the printer off-line. 2.
OperatW3.frm 2 ページ ２００３年１１月１８日 火曜日 午前９時５１分 1. Using the Control Panel Tray 1 Paper Size Setting Method Chapter 3 1. Press the On Line key to take the printer off-line. Using Your Printer You can enter the tray1 paper size setting mode only from off-line. 4. Press the Enter key to save your selection. An asterisk (*) appears at the right of the setting. The printer returns on-line automatically. 2. Press the Tray1 Paper key to enter the tray 1 paper size setting mode. 3.
3 ページ ２００３年１１月１８日 火曜日 午前９時５１分 1. Using the Control Panel Job Separation 1. Load the separator sheets in tray 1. You don’t need to specify the paper size and the direction of the loaded separator sheet. 2. Press the Tray1 Paper key to enter the tray 1 paper size setting mode. 3. Press the Select key as many times as necessary to select JOB SEPARATION. 4. Press the Enter key to save your selection. An asterisk (*) appears at the right of the setting. The printer returns on-line automatically.
OperatW3.frm 4 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2.
OperatW3.frm 5 ページ ２００３年１１月１８日 火曜日 午前９時５１分 Using Your Printer Chapter 3 2.
OperatW3.frm 6 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus Using Your Printer Chapter 3 Printer Menus The printer has six standard menus and two optional menus that allow you to configure the printer. Some of the items or values are displayed only when a specific option is installed. Other items or values may only be effective for a particular printer language.
7 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2.
OperatW3.frm 8 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus COPIES Specifies the number of copies you want to print. Using Your Printer Chapter 3 PAPER SIZE Specifies the paper size you want to use for printing. ORIENTATION Selects the direction of the print on the page. Portrait orientation means the page is taller than it is wide when you view the printed text upright. Landscape orientation means the page is wider than it is tall when you view the printed text upright.
9 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus TONER DENSITY Selects the density of the toner applied to the page. This setting can be fine-adjusted in 7 different steps. PAGE PROTECTION Page Protection allows you to make sure the entire page is processed before it is printed. Set the setting to ON only when the JOB TOO COMPLEX error occurs. If Page Protection is set to ON, printing speed may be slowed.
OperatW3.frm 10 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus (2) PCL Menu FONT NUMBER PITCH POINT SIZE SYMBOL SET Using Your Printer Chapter 3 ITEM FACTORY DEFAULT 0 10.00 12.00 ROMAN-8 USER SELECTION 0 to 50 0.44 to 99.99 4.00 to 999.
11 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus (3) PS Menu ITEM JAM RECOVER FACTORY DEFAULT RANGE OF USER SELECTION ON ON OFF JAM RECOVER When Jam Recover is set to OFF, the printer does not reprint a page that has misfed. When the Jam Recover is set to ON, the printer keeps the image for a printed page until the printer signals that the page has successfully exited the printer. Then the printer reprints all misfed pages. However, printing speed may be slowed.
OperatW3.frm 12 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2.
13 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus Recoverable errors: MEMORY OVERFLOW JOB TOO COMPLEX SPECIAL PAPER Specifies the paper source which the special paper is loaded in. See “Special Paper Tray Setting” page 3-37. TRAY 1 MEDIA Specifies the media type that is loaded in tray 1 to get the best possible result on the paper.
OperatW3.frm 14 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus (5) Parallel Menu FACTORY DEFAULT USER SELECTION IO BUFFER SIZE AUTO HIGH SPEED ON BI-DIRECTION ON TIMING A-B-A ADOBE PROTOCOL STANDARD TIME OUT 60 16K, 64K, 256K, 1M AUTO OFF ON OFF ON A-B-A A-B B-A STANDARD BINARY TBCP 5 to 300 Using Your Printer Chapter 3 ITEM IO BUFFER SIZE Selects the receiving buffer size.
15 ページ ２００３年１１月１８日 火曜日 午前９時５１分 TIMING Sets the timing of “Busy to Ack” in the communication format between the printer and PC. Basically, you don’t need to change the setting. However, depending on the PC you are using, it may not be able to support a proper communication between the printer and PC. In such a case, change the setting after verifying the PC specification. A-B: Ack in Busy. A-B-A: Ack while Busy. B-A: Ack after Busy. ADOBE PROTOCOL This item appears only when PostScript is installed.
OperatW3.frm 16 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus (6) Maintenance Menu Using Your Printer Chapter 3 ITEM FACTORY DEFAULT USER SELECTION DISPLAY LANGUAGE ENGLISH FACTORY DEFAULT SERVICE MESSAGE ON ENGLISH DEUTSCH FRANCAIS ITALIANO NEDERLANDS DANSK ESPAÑOL CESKY ON OFF DISPLAY LANGUAGE The Display Language setting determines the language of the text that appears on the control panel. The setting becomes effective by restarting the printer after making changes.
17 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus This item appears only when the optional network card is installed. Using the software utility available with the optional network card enables making of the settings in detail. For details, see the manual for the network card.
OperatW3.frm 18 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus Using Your Printer Chapter 3 NOTE Any setting changes you make in the network menu becomes effective by pressing the On Line key. CAUTION Pressing the On Line key after making the network settings will restart the network card immediately. The printer continues displaying “READY” on the control panel while the network card is being restarted.
19 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus (8) Test Print Chapter 3 A test print is printed out with the paper size and paper tray settings you made in the print menu. For details, see “Print Menu” page 3-6. ITEM CONFIG PRINT PCL FONT LIST PCL DEMO PRINT PS CONFIG PRINT PS FONT LIST NETWORK CONFIG PRINT 1. Press the On Line key to take the printer off-line. 2. Press the Menu key as many times as necessary to select the test print menu. 3.
OperatW3.frm 20 ページ ２００３年１１月１８日 火曜日 午前９時５１分 2. Understanding the Printer Menus Using Your Printer Chapter 3 PS CONFIG PRINT Prints various information for PS, RAM capacity and so on. PS config print is printed out in the display language you selected. PS FONT LIST Prints a font sample that shows all the fonts available in PS. NETWORK CONFIG PRINT Prints the contents of the setting or the status of the network.
21 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Supported Media Chapter 3 Use only supported sizes or weights of paper. Do not use other media which may not meet the media specifications for this printer. Paper Type • Plain paper: 60 to 90 g/m2 (16 to 24 lb) Recycled paper: 60 to 90 g/m2 (16 to 24 lb) • Special paper (Tray 1 only): transparencies, labels, envelopes, letterhead, thick paper: 91 to 157 g/m2 (24 to 41 lb) Using Your Printer OperatW3.
OperatW3.frm 22 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3.
23 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Printable Area Margins of 5 mm (0.2 inch) along the four edges of the document. Chapter 3 One-sided printing 5 mm (0.2 inch) 5 mm (0.2 inch) Using Your Printer OperatW3.frm Printable area 5 mm (0.2 inch) 5 mm (0.2 inch) Double-sided printing Margins of 7.5 mm (0.3 inch) along the four edges of the document. 7.5 mm (0.3 inch) 7.5 mm (0.3 inch) Printable area 7.5 mm (0.3 inch) 7.5 mm (0.
OperatW3.frm 24 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Printing Orientation Paper loaded crosswise: (A4, JIS B5, Letter) The direction of paper loading A A Printing at portrait orientation Printing at landscape orientation Paper loaded lengthwise: (A3, Super B, B4, Ledger, Legal, Executive, Envelopes, Universal) The direction of the paper loading 3-24 A A Using Your Printer Chapter 3 For all paper sizes, the printer prints on the paper face up from any tray.
25 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper - Tray 1 only. - The following lists the envelope sizes you can specify from the control panel or printer driver. ISO B5 (176mm x 250mm) COM10 (Commercial-10) (4.125” x 9.5”) C5 (162mm x 229mm) DL (110mm x 220mm) Monarch (3.875” x 7.5”) - Select the envelope size you want to print in the tray1 paper size setting mode. See “Tray 1 Paper Size Setting Method” page 3-2. - Load envelopes face up.
OperatW3.frm 26 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Chapter 3 Printing on Labels - Tray 1 only. - Load labels face up. - Use only labels designed for laser printers or plain paper copiers. - Do not specify duplex printing. Using Your Printer Printing on Thick Paper - Tray 1 only. - Load thick paper face up. - Do not specify duplex printing. Printing on Transparencies Be careful when you handle transparencies. Fingerprints on the surface of the transparency can cause poor print quality.
27 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Enables printing on both sides of the paper only when the printer is equipped with the duplex unit. If you attempt duplex printing, you can choose either Bind Long Edge or Bind Short Edge. (1) Bind Long Edge A A A A Portrait Landscape (2) Bind Short Edge A A A Chapter 3 Duplex Printing Using Your Printer OperatW3.frm A Landscape Portrait NOTE To attempt duplex printing, you may need to add more memory (an additional 8MB recommended).
OperatW3.frm 28 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper The supported paper types and sizes for duplex printing are as follows. Using Your Printer Chapter 3 Paper Type - Plain paper: 60 to 90 g/m2 (16 to 24 lb) - Recycled paper: 60 to 90 g/m2 (16 to 24 lb) NOTE Do not use special paper (transparencies, labels, envelopes, letterhead and thick paper) for duplex printing. Paper Size A3, Super B, A4, B4, JIS B5, Letter, Legal, Ledger, Executive, Custom*.
29 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Loading Paper in Tray 1 Chapter 3 1. Open tray 1. Using Your Printer OperatW3.frm 2. Fan the paper thoroughly and align the edges. 3. Adjust the paper guide plates to fit the paper size and load paper face up in the tray. Load A4, JIS B5 and LTR with the long edge toward the back of the tray. Load A3, A3+, B4, LGL, LGR, EXEC, envelopes and Custom with the short edge toward the back of the tray. NOTE Do not stack paper higher than the ▼mark.
OperatW3.frm 30 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper 4. Specify the tray 1 paper size. →See “Tray 1 Paper Size Setting Chapter 3 Method” page 3-2. 5. Specify the tray 1 media type. Using Your Printer →See “System Menu” page 3-12. →See “Basic Menu Setting Method” page 3-1.
31 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Loading Paper in Tray 2 2. Press down the paper lifting plate until it locks. 3. Fan the paper thoroughly and align the edges. 4. Load paper face up, placing it under the two clips in the tray. Letter size only. Max. Level Indicator Chapter 3 1. When the paper tray is in the printer, pull it out and remove it. Using Your Printer OperatW3.frm NOTES Do not load paper beyond the Max. Level Indicator.
OperatW3.frm 32 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper 5. Slide the tray securely into position. Chapter 3 6. Specify the tray 2 media type. →See “System Menu” page 3-12. →See “Basic Menu Setting Using Your Printer Method” page 3-1. USEFUL TIP Tray 2 and tray 3 can be used interchangeably.
33 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Loading Paper in Tray 3 Chapter 3 1. When the paper tray is in the tray unit, pull it out and remove it. 2. Open the paper cover. 3. Press down the paper lifting plate until it locks. 4. Fan the paper thoroughly and align the edges. 5. Load paper face up, placing it under the two clips in the tray. Adjust the paper guide plates to fit the paper size. Load A4, JIS B5 and LTR with the long edge toward the back of the tray.
OperatW3.frm 34 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Using Your Printer Chapter 3 Load A3, B4, LGL, LGR and EXEC with the short edge toward the back of the tray. Max. Level Indicator NOTES Do not load paper beyond the Max. Level Indicator. Do not add more paper until all sheets have been used up. 6. Close the paper cover. Slide the tray securely into position. 7. Specify the tray 3 media type. →See “System Menu” page 3-12. →See “Basic Menu Setting Method” page 3-1.
35 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper If you select AUTOMATIC or Auto for the paper source from the control panel or printer driver, the printer will automatically search all paper trays for the required paper size. At this time, the paper source is selected in the priority order of tray 2, tray 3 and tray 1. For more information, see the Printer Driver User’s Manual.
OperatW3.frm 36 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper Using Your Printer Chapter 3 Using Manual Feed Using manual feed is useful when you temporarily want to print on paper that is not loaded in any tray. The manual feed feature allows you to print on custom sizes of paper, envelopes, labels and transparencies. 1. Select Manual Feed as the paper source from the control panel or printer driver. See “Understanding the Printer Menus” page 3-7. See the Printer Driver User’s Manual. 2.
37 ページ ２００３年１１月１８日 火曜日 午前９時５１分 3. Loading Paper When you load special paper in the tray, it can be specified as the special paper tray so that the other users will not use the special paper by mistake. 1. Press the On Line key to take the printer off-line. 2. Press the Menu key as many times as necessary to select the System menu. 3. Press the Item key as many times as necessary to select SPECIAL PAPER. 4. Press the Select key to select the tray you are loading special paper in. 5.
OperatW3.frm 38 ページ ２００３年１１月１８日 火曜日 午前９時５１分 4. Printing There are three sources to print from: tray 1, tray 2 and tray 3. Select the printing source according to your needs. Using Your Printer Chapter 3 1. Open tray 1. 2. Load paper in tray 1, tray 2 or tray 3. →See “Loading Paper in Tray 1” page 3-29. →See “Loading Paper in Tray 2” page 3-31. →See “Loading Paper in Tray 3” page 3-33. NOTE If special paper is loaded, the printer is unable to make multiple prints. 3.
２００３年１１月１８日 火曜日 午前９時５１分 4. Printing 4. Send a print command from the computer. The printed paper is fed out face down on the paper exit tray. NOTES The paper exit tray can hold a maximum of 500 sheets of paper. Use care not to exceed this limit when making multiple prints. 3-39 Chapter 3 39 ページ Using Your Printer OperatW3.
OperatW3.frm 40 ページ ２００３年１１月１８日 火曜日 午前９時５１分 5. Understanding Fonts Using Your Printer Chapter 3 Font A font is a specific group of characters that have common style and size characteristics. Your printer can store a variety of different fonts in its memory for printing. Since these fonts reside in printer memory, they are called resident fonts. The PageWorks 20 uses two types of resident fonts: scalable fonts and bitmap fonts.
２００３年１１月１８日 火曜日 午前９時５０分 Chapter 4 -1 ページ Chapter 4 Maintaining Your Printer Mainte4.
0 ページ Maintaining Your Printer Chapter 4 Mainte4.
1 ページ ２００３年１１月１８日 火曜日 午前９時５０分 1. Supplies for Maintenance The following table lists the approximate replacement interval for each supplies. Imaging Cartridge Page Count * 10,000 pages Replacement by User * Approximate A4-size page count based on 5% coverage of toner.
Mainte4.frm 2 ページ ２００３年１１月１８日 火曜日 午前９時５０分 2. Replacing the Imaging Cartridge If the TONER IS LOW message appears on the control panel, the toner level in the imaging cartridge is getting low and print quality will degrade. You need to get ready to replace the imaging cartridge. To use as much of the remaining toner as possible, remove the imaging cartridge, shake it 2 or 3 times and reinstall it in the printer.
２００３年１１月１８日 火曜日 午前９時５０分 2. Replacing the imaging cartridge 3. Pressing the upper cover lock release button, open the upper cover. 4. Remove the old imaging cartridge from the printer. Chapter 4 3 ページ 5. Take a new imaging cartridge out of the box. Holding it with both hands, shake it well in the direction of the arrows. 6. Pull the tab outward slowly until the sealing tape is completely removed. 4-3 Maintaining Your Printer Mainte4.
Mainte4.frm 4 ページ ２００３年１１月１８日 火曜日 午前９時５０分 2. Replacing the imaging cartridge 7. Shake the imaging cartridge 4 or 5 times in the direction of the arrows to distribute the toner evenly. Maintaining Your Printer Chapter 4 8. Install the imaging cartridge securely into the printer by sliding the pins on each side of the cartridge along the grooves of the cartridge guide. 9. Close the upper cover.
5 ページ ２００３年１１月１８日 火曜日 午前９時５０分 3. Cleaning Your Printer Accumulated dust and lint on the inside and outside of the printer impairs printer performance and print quality. Clean the printer at regular intervals. CAUTION The fusing section has become quite hot during operation. Do not touch the area as it may cause a burn. Fusing Section External Cleaning Wipe off dirt and stains around the printer with a soft cloth dampened with a mild detergent.
Mainte4.frm 6 ページ ２００３年１１月１８日 火曜日 午前９時５０分 3. Cleaning Your Printer Internal Cleaning Chapter 4 1. Open the upper cover. 2. Remove the imaging cartridge. Maintaining Your Printer NOTE Whenever you remove the imaging cartridge from the printer, immediately cover it with a cloth to prevent light from striking it. 3. Clean the window glass of the print head unit using a dry soft cloth.
２００３年１１月１８日 火曜日 午前９時５３分 Chapter 5 Chapter 5 -1 ページ Solving Printer Problems Solving Printer Problems Trouble5.
0 ページ Solving Printer Problems Chapter 5 Trouble5.
1 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Clearing a Paper Misfeed When a paper misfeed occurs in the printer, remove the misfed paper according to the following procedures. CAUTION Chapter 5 The fusing section has become quite hot during operation. Do not touch the area as it may cause a burn. Fusing Unit Paper Misfeed in Tray 1 1. Pressing the upper cover lock release button, open the upper cover. NOTE If you have pulled out the paper exit tray, push it into the printer before opening the upper cover. 2.
Trouble5.frm 2 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Clearing a Paper Misfeed 3. Pull out the misfed paper in tray 1. Chapter 5 4. Check that no misfed paper remains in the printer. Reinstall the imaging cartridge. Solving Printer Problems 5. Close the upper cover.
3 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Clearing a Paper Misfeed Paper Misfeed in Tray 2 or Tray 3 1. Pressing the upper cover lock release button, open the upper cover. NOTE If you have pulled out the paper exit tray, push it into the printer before opening the upper cover. NOTE Whenever you remove the imaging cartridge from the printer, immediately cover it with a cloth to prevent light from striking it. Chapter 5 2. Remove the imaging cartridge. Solving Printer Problems Trouble5.frm 3.
Trouble5.frm 4 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Clearing a Paper Misfeed 4. Check that no misfed paper remains in the printer. Reinstall the imaging cartridge. Solving Printer Problems Chapter 5 5. Close the upper cover.
5 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Clearing a Paper Misfeed Paper Misfeed Inside the Printer 1. Pressing the upper cover lock release button, open the upper cover. NOTE If you have pulled out the paper exit tray, push it into the printer before opening the upper cover. NOTE Whenever you remove the imaging cartridge from the printer, immediately cover it with a cloth to prevent light from striking it. 3.
Trouble5.frm 6 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Clearing a Paper Misfeed NOTES The image which was transferred to the paper is not fixed.Be careful or your hands will become dirty. Do not pull out the paper in the direction (the exit side of the fusing unit) of the arrow. Solving Printer Problems Chapter 5 5. Reinstall the imaging cartridge and close the upper cover.
7 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Clearing a Paper Misfeed Paper Misfeed in the Duplex Unit 1. Open the duplex upper cover and pull out the misfed paper. Duplex Upper Cover Chapter 5 2. Open the duplex lower cover and remove the misfed paper. Duplex Lower Cover Solving Printer Problems Trouble5.
Trouble5.frm 8 ページ ２００３年１１月１８日 火曜日 午前９時５３分 2. Printing Problems The following provides information on most printing problems you might encounter. If the advice provided here does not solve your problem, contact your Technical Representative. Cause No Printing The printer is off-line. Press the On Line key to take the printer online. The interface cable is not securely connected to the printer and computer or defective. Reconnect the interface cable or replace the interface cable.
9 ページ ２００３年１１月１８日 火曜日 午前９時５３分 3. Print Quality Problems The following provides information on most print quality problems you might encounter. If the advice provided here does not solve your problem, contact your Technical Representative. Blank pages Cause Action The toner sealing tape has not been pulled out. Remove the imaging cartridge and pull out the toner sealing tape. The imaging cartridge may be defective. Replace the imaging cartridge if necessary.
Trouble5.frm 10 ページ ２００３年１１月１８日 火曜日 午前９時５３分 3. Printing Problems Symptom Cause Action The toner density setting made with the Device Option dialog box may be too dark. Change the setting. The imaging cartridge may be defective. Replace the imaging cartridge if necessary. Blurred background The imaging cartridge may be defective. Replace the imaging cartridge if necessary. Uneven print density The toner may be unevenly distributed inside the imaging cartridge.
11 ページ ２００３年１１月１８日 火曜日 午前９時５３分 Symptom Cause Action Irregularities The paper may have absorbed some moisture due to high humidity. Replace the paper you are using with dry paper. White or black lines The imaging cartridge may be defective. Replace the imaging cartridge if necessary. Toner smudges The paper you are using is improper. Use only supported sizes or weights of paper. The imaging cartridge may be defective. Replace the imaging cartridge if necessary. 5-11 Chapter 5 3.
Trouble5.frm 12 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages Solving Printer Problems Chapter 5 If a message appears on the control panel, refer to the following sections for the description of each message and the action to take. (1) Status messages Display the current printer status. (2) Warning messages Display a warning message. (3) Caution messages The message LED blinks and a caution message is displayed. Requests you to perform a necessary task before resuming printing.
13 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages (1) Status Messages MESSAGE READY OFFLINE DESCRIPTION (emulation) The printer is ready to print. The printer is off-line. PROCESSING (emulation) The printer is processing data. (user name) (emulation) The printer is printing. (user name) The printer is resetting. Returns the RESET printer on-line automatically after resetting. TRAY1 PAPER SIZE The printer is in the tray 1 paper (paper) size setting mode.
Trouble5.frm 14 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages The following table lists the warning messages which are displayed in the second line on the control panel when the printer is READY or OFFLINE. MESSAGE MAINTENANCE REQ Solving Printer Problems Chapter 5 TRAY2 IS EMPTY DESCRIPTION & ACTION The printer is approaching the maintenance interval. You can clear this message by changing the service message setting to OFF. See “Maintaining Your Printer” page 4-1.
15 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages (2) Warning Messages If one of the following warning messages appears, the printer continues printing without stopping. By pressing any key after completing printing, the printer returns to the ready condition. When receiving the next job, the message is automatically cleared. MESSAGE DESCRIPTION The printer performed compression IMAGE ADAPT (user name) of an image data. Chapter 5 user name: the user name (up to 8 characters).
Trouble5.frm 16 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages (3) Caution Messages If Auto Continue is ON, the printer returns on-line automatically after waiting for the time specified and then resumes processing, but some data may be lost. If Auto Continue is OFF, the printer returns on-line after you press the Proceed key and then resumes processing, but some data may be lost.
17 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages (4) Operator Call Messages MESSAGE DESCRIPTION AND ACTION LOAD (tray xx) (paper) (user name) *Printing The correct paper has not been loaded in tray xx. Load the specified paper in tray xx. If tray xx is tray 1, you need to make the paper size setting changes in the tray 1 paper size setting mode according to your needs, after loading the specified paper. See page 3-2.
Trouble5.frm 18 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages MESSAGE DESCRIPTION AND ACTION The printer has detected a paper misfeed PAPER JAM1 INPUT (user name) in the input area. Remove the misfed paper and close the upper cover. See page 5-1 or 5-3. Solving Printer Problems Chapter 5 PAPER JAM2 DRUM (user name) The printer has detected a paper misfeed in the drum area. Remove the misfed paper and close the upper cover. See page 5-5.
19 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages MESSAGE DESCRIPTION AND ACTION FATAL ERROR 1 ROM ROM is faulty. Turn the printer off, then back on. If it happens again, call your Technical Representative. FATAL ERROR 2 PS ROM PS ROM is faulty. Remove the faulty PS ROM and try another one. FATAL ERROR 3 RAM RAM is faulty. Turn the printer off, then back on. If it happens again, call your Technical Representative. FATAL ERROR 4 SIMM RAM (number) SIMM RAM is faulty.
Trouble5.frm 20 ページ ２００３年１１月１８日 火曜日 午前９時５３分 4. Understanding Printer Messages MESSAGE DESCRIPTION AND ACTION FATAL ERROR 22 HSYNC A laser diode error. Turn the printer off and call your Technical Representative. FATAL ERROR 23 POLYGON A polygon motor error. Turn the printer off and call your Technical Representative. A main motor error.
２００３年１１月１８日 火曜日 午前９時５２分 Chapter 6 Installing Options Chapter 6 -1 ページ Installing Options Options6.
0 ページ Installing Options Chapter 6 Options6.
1 ページ ２００３年１１月１８日 火曜日 午前９時５２分 1. Installing the Third Tray Unit - Take the tray unit out of the shipping box. - Remove the plastic bag and all shipping materials. - Turn the printer off and then disconnect the power cord and interface cable from the printer. 1. Place the tray unit in the location you have chosen. Pull out the paper tray beforehand. NOTE Since the printer weighs approximately 55.1 lbs (25 kg), two people are required to lift it. Chapter 6 2.
Options6.frm 2 ページ ２００３年１１月１８日 火曜日 午前９時５２分 1. Installing the Third Tray Unit 5. Connect the power cord to the printer and then turn the printer on. →See “Connecting the power Cord” page 2-9. →See “Turning the Printer ON and OFF” page 2-10. 6. Print a config print and verify the Third Tray Unit setting in the Installed Options. Chapter 6 →See “Test Print” page 3-19.
3 ページ ２００３年１１月１８日 火曜日 午前９時５２分 2. Installing the Duplex Unit When you want to print on both sides of the paper, the duplex unit is necessary. NOTE You may need to add more memory (an additional 8MB recommended) to print on both sides of the paper. - Take the duplex unit out of the shipping box. - Remove the plastic bag and all shipping materials. - Turn the printer off and then disconnect the power cord and interface cable from the printer. 2.
Options6.frm 4 ページ ２００３年１１月１８日 火曜日 午前９時５２分 2. Installing the Duplex Unit 4. Connect the power cord to the printer and then turn the printer on. →See “Connecting the power Cord” page 2-9. →See “Turning the Printer ON and OFF” page 2-10. 5. Print a config print and verify the Duplex Unit setting in the Installed Options. Chapter 6 →See “Test Print” page 3-19.
5 ページ ２００３年１１月１８日 火曜日 午前９時５２分 3. Installing the Network Card Installing the network card enables you to connect the printer to a local area network (LAN) using an Ethernet network. WARNING The network card is easily damaged by static electricity. Touch something metal before you touch the network card. - Take the network card out of the shipping box. - Turn the printer off and then disconnect the power cord and interface cable from the printer. 2.
Options6.frm 6 ページ ２００３年１１月１８日 火曜日 午前９時５２分 3. Installing the Network Card 3. Connect the power cord to the printer and then turn the printer on. →See “Connecting the power Cord” page 2-9. →See “Turning the Printer ON and OFF” page 2-10. 4. Print a config print and verify the Network Card setting in the Installed Options. Chapter 6 →See “Test Print” page 3-19.
7 ページ ２００３年１１月１８日 火曜日 午前９時５２分 4. Installing the Adobe PostScript ROM-DIMM and Hard Disk This printer provides a socket for the installation of an Adobe PostScript ROM-DIMM. When installing the ROM-DIMM, the printer can function as a PostScript printer. The Hard Disk that is installed with the Adobe PostScript ROM-DIMM is used for downloading available PostScript fonts. WARNING The Adobe PostScript ROM-DIMM is easily damaged by static electricity. Touch something metal before you touch the ROM-DIMM.
Options6.frm 8 ページ ２００３年１１月１８日 火曜日 午前９時５２分 4. Installing the Adobe Postscript DIMM and Hard Disk 3. Remove the right side cover. 4. Remove the four screws. (Use a plus screwdriver.) Installing Options Chapter 6 5. Open the metal cover. 6. Insert the DIMM all the way into the DIMM socket at a 90 degree angle, and push the DIMM until it snaps into place.
２００３年１１月１８日 火曜日 午前９時５２分 4. Installing the Adobe Postscript DIMM and Hard Disk 7. Install the Hard Disk and tighten the four screws. (Use a plus screwdriver.) 8. Connect the Hard Disk cable to the Hard Disk connector on the controller board. NOTE The Hard Disk can be installed only when the Adobe PostScript ROM-DIMM is installed. 9. Close the metal cover and tighten the four screws. Attach the right side cover. Chapter 6 9 ページ 10. Close the upper cover. 11.
Options6.frm 10 ページ ２００３年１１月１８日 火曜日 午前９時５２分 4. Installing the Adobe Postscript DIMM and Hard Disk 12. Print a config print and verify the PostScript ROM and Hard Disk settings in the Installed Options. →See “Test Print” page 3-19.
11 ページ ２００３年１１月１８日 火曜日 午前９時５２分 5. Installing the SIMM You can expand printer memory by adding single in-line memory (SIMM). Your printer provides 4MB as standard memory and has two memory connectors into which you can install SIMMs to expand the total memory available up to the maximum 68MB. SIMMs with 4MB, 8MB, 16MB, or 32MB of memory are available from a computer shop. WARNING The SIMM is easily damaged by static electricity. Touch something metal before you touch the SIMM. 1.
Options6.frm 12 ページ ２００３年１１月１８日 火曜日 午前９時５２分 5. Installing the SIMM 3. Remove the right side cover. 4. Remove the four screws. Installing Options Chapter 6 5. Open the metal cover. 6. Insert the SIMM all the way into the upper memory connector at a 45 degree angle, and push the SIMM up until it snaps into place. NOTES When you install two SIMMs, the first one must be inserted into the upper memory connector (slot 1).
２００３年１１月１８日 火曜日 午前９時５２分 5. Installing the SIMM 7. Make sure both metal clips on the connector are pushed through the holes on the SIMM. 8. If installing a second SIMM, repeat steps 6 to 7. 9. Close the metal cover and tighten the four screws. Attach the right side cover. 10. Close the upper cover. 11. Connect the power cord to the printer and then turn the printer on. Chapter 6 13 ページ Installing Options Options6.frm →See “Connecting the power Cord” page 2-9.
Options6.frm 14 ページ ２００３年１１月１８日 火曜日 午前９時５２分 5. Installing the SIMM 12. Print a config print and check the Add SIMM Memory in the Installed Options. →See “Test Print” page 3-19.
２００３年１１月１８日 火曜日 午前９時５３分 Chapter 7 Chapter 7 Specifications Specifications Spec7.
Specifications Chapter 7 Spec7.
Spec7.frm 1 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Printer PageWorks 20 Type Desktop laser beam printer Printing system Minolta Super Fine Micro-ToningTM system Exposure system Laser diode + Polygon mirror scanning Resolution 600 dots per inch Printing speed First print One sided: within 16.0 sec. (A4C or LetterC) Double sided: within 26.0 sec. (A4C or LetterC) Multiple Print One sided: 20.0 pages/min (A4C or LetterC) Double sided: 12.
Spec7.frm 2 ページ ２００３年１１月１８日 火曜日 午前９時５３分 Specifications Chapter 7 1. Printer Paper input Tray 1: - Plain paper: Up to 150 sheets - Recycled paper: Up to 150 sheets - Special paper Transparencies: Up to 5 sheets Letter head, Labels, Envelopes, Thick paper: Up to 10 sheets Tray 2: - Plain paper: Up to 500 sheets - Recycled paper: Up to 500 sheets Paper exit system Face down exit system Paper output 500 prints maximum Warm-up time Within 70sec.
Spec7.frm 3 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Printer 360,000 prints or 5 years Imaging cartridge life 10,000 prints or more (black-to-white ratio of 5% or less) Dimensions 21.5 (W) x 15.1 (D) x 15.9 (H) inches (545 x 383 x 403 mm) Weight Printer: approximately 55.1 lbs (25 kg) Imaging Cartridge: approximately 4.2 lbs (1.
Spec7.frm 4 ページ ２００３年１１月１８日 火曜日 午前９時５３分 1. Printer Specifications Chapter 7 Options 7-4 250-Sheet Universal Third Tray Unit 500-Sheet Third Tray Unit (Letter) 500-Sheet Third Tray Unit (A4) Paper Tray - Universal Tray - A4 Tray - Letter Tray Duplex Unit Network Card SIMM (4MB/8MB/16MB/32MB) Adobe Postscript Level 2 DIMM 2.
Spec7.frm 5 ページ ２００３年１１月１８日 火曜日 午前９時５３分 250-Sheet Universal Third Tray Unit Paper feeding system 1-way system Paper type Plain paper: 60 to 90 g/m2 (16 to 24 lb) Recycled paper: 60 to 90g/m2 (16 to 24 lb) Paper size A3, A4, B4, JIS B5, Ledger, Legal, Letter, Executive Capacity Plain paper: Up to 250 sheets Recycled paper: Up to 250 sheets Operating environment Temperature 50°F to 95°F (10°C to 35°C) with a fluctuation of 50°F (10°C) per hour.
Spec7.frm 6 ページ ２００３年１１月１８日 火曜日 午前９時５３分 Name 500-Sheet Third Tray Unit (Letter) Paper feeding system 1-way system Paper type Plain paper: 60 to 90 g/m2 (16 to 24 lb) Recycled paper: 60 to 90g/m2 (16 to 24 lb) Paper size Letter Capacity Plain paper: Up to 500 sheets Recycled paper: Up to 500 sheets Operating environment Temperature 50°F to 95°F (10°C to 35°C) with a fluctuation of 50°F (10°C) per hour. Humidity 15% RH to 85% RH with a fluctuation of 20% RH per hour.
Spec7.frm 7 ページ ２００３年１１月１８日 火曜日 午前９時５３分 500-Sheet Third Tray Unit (A4) Paper feeding system 1-way system Paper type Plain paper: 60 to 90 g/m2 (16 to 24 lb) Recycled paper: 60 to 90g/m2 (16 to 24 lb) Paper size A4 Capacity Plain paper: Up to 500 sheets Recycled paper: Up to 500 sheets Operating environment Temperature 50°F to 95°F (10°C to 35°C) with a fluctuation of 50°F (10°C) per hour. Humidity 15% RH to 85% RH with a fluctuation of 20% RH per hour.
Spec7.frm 8 ページ ２００３年１１月１８日 火曜日 午前９時５３分 3. Duplex Unit (optional) Duplex Unit Paper feeding system 1-way system Paper type Plain paper: 60 to 90 g/m2 (16 to 24 lb) Recycled paper: 60 to 90 g/m2 (16 to 24 lb) Paper size A3, Super B, A4, B4, JIS B5, Ledger, Legal, Letter, Executive Operating environment Temperature 50°F to 95°F (10°C to 35°C) with a fluctuation of 50°F (10°C) per hour. Humidity 15% RH to 85% RH with a fluctuation of 20% RH per hour.
Spec7.frm 9 ページ ２００３年１１月１８日 火曜日 午前９時５３分 SIMM (single in-line memory module) Capacity 4, 8, 16, 32MB Parity Non-parity Access speed 70 nsec. or faster Number of pins 72 Specifications Name Chapter 7 4.
Spec7.frm 10 ページ ２００３年１１月１８日 火曜日 午前９時５３分 5. Interface Connector and Cable Be sure to use only a parallel interface cable that meets the specifications described below. Length: Less than 5 feet (1.5 meters) Connectors: Printer: Centronics 36-pin connector Computer: EIA 25-pin connector Cable type: Shielded type. Each signal and ground pair should be twisted. Specifications Chapter 7 IEEE 1284 type-B connector pin assignments NOTE Minolta does not warrant the use of any particular cable.
Spec7.frm 11 ページ ２００３年１１月１８日 火曜日 午前９時５３分 5.
Spec7.frm 12 ページ ２００３年１１月１８日 火曜日 午前９時５３分 5.
２００３年１１月１８日 火曜日 午前９時４６分 Appendix A Character Sets Appendix-A -1 ページ Character Sets Append-A.
0 ページ Character Sets Appendix-A Append-A.
1 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 7J Desktop Character Sets Append-A.
Append-A.frm 2 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A.
3 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 0U ISO 6: ASCII Character Sets Append-A.
Append-A.frm 4 ページ ２００３年１１月１８日 火曜日 A.
5 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 0I ISO 15: Italian Character Sets Append-A.
Append-A.frm 6 ページ ２００３年１１月１８日 火曜日 A.
7 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 1G ISO 21: German Character Sets Append-A.
Append-A.frm 8 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A.
9 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 1F ISO 69: French Character Sets Append-A.
Append-A.frm 10 ページ ２００３年１１月１８日 火曜日 A.
11 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 2N ISO 8859/2 Latin 2 Character Sets Append-A.
Append-A.frm 12 ページ ２００３年１１月１８日 火曜日 A.
13 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 1U Legal Character Sets Append-A.
Append-A.frm 14 ページ ２００３年１１月１８日 A.
15 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 8M Math-8 Character Sets Append-A.
Append-A.frm 16 ページ ２００３年１１月１８日 火曜日 A.
17 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A. Character Sets Appendix-A 10U PC-8 (Cord Page 437) Character Sets Append-A.
Append-A.frm 18 ページ ２００３年１１月１８日 火曜日 午前９時４６分 A.
