6.3 Running Telnet
6-39
TCP/IP Configuration
Chapter 6
6.3 Running Telnet
The Telnet utility uses the standard remote terminal protocol to
configure the IP address, lpd printers, and other parameters on your
system. Use the following guidelines to run Telnet. You have the same
functionality with the HTML pages accessed by MAP or a Web
Browser, as described in Chapter 3.
• Most often, you make selections from menus by toggling between
one choice or another, by selecting/deselecting or enabling/dis-
abling an item.
• Press , when not selecting an item. This will return you to a
previous menu.
• If you do not make a menu selection for 2 minutes, you get a “Two
Minute Warning” that within 2 more minutes your Telnet session
will end. This ensures that one user does not leave a session idle
for too long.
6.3.1 Making Connection and Main Menu
1. At the prompt, type:
#telnet <NIC IP address>
2. When login: appears, type
guest
if you are only interested in
browsing the menus or
sysadm
if you want to change the configu-
ration. Press . When password: appears, again type
guest
or
sysadm
and press .
3. The main menu is displayed. This utility lets you change the IP
Parameters, lpd printers, protocols, restore to factory defaults, and
change password. Press the number for the parameter you wish to
check or change and press .
Enter
Enter
Enter
Enter
