6.3 Running Telnet
6-42
TCP/IP Configuration
Chapter 6
1. To access the LPD Printers menu, type 2 and press . For a unit
at factory default, the menu shown below appears.
2. To change the set of emulations, type
1 and press . The
options shown below appears.
3. To delete an emulation, select the number opposite the language
listed. For example, type
1 and press to delete PCL. Typing 1
again will again selects PCL.
4. From the LPD Printers menu, press
2 to toggle Banners between
Enabled/Disabled.
Print Server Setup Job Detected to be Action
PCL ASCII
<CR> changed to
<CR><LF>
not PostScript PostScript Job discarded
PostScript ASCII
PostScript header
added, <CR> changed
to <CR><LF>
PCL, PS, ASCII any no action
LPD Printers
1. Printer 1 PCL PS OTHER
2. Banners DISABLED
Printer 1 PCL PS OTHER
1. PCL
2. PS
3. ASCII
4. OTHER
Enter
Enter
Enter
