4.5 Using the Novell PCONSOLE Utility
4-26
NetWare Configuration
Chapter 4
5. Select Notify List for Printer from the menu.
6. Select the printer from the
Defined Printers menu.
7. Press at the
File Server/Notify Name/Notify Type/First/
Next
screen. The Notify Candidates screen appears.
8. Select the user or user group from the
Notify Candidates screen.
The
Notify Intervals screen displays.
9. Set the
First and Next intervals for notifying users about printer
problems. The First interval is the number of seconds the network
waits before it notifies users about a print job problem. The Next
interval specifies how often in seconds users are notified. Enter a
number for each interval and press .
10. Press and save all changes.
11. Press until you see the prompt to exit PCONSOLE. Select
Yes and then press .
Esc
Enter
Esc
Esc
Enter
