Series HMI Connection Manual

Mitsubishi A Series/J71UC24 Computer Link

HMI Factory Setting:

Baud rate: 9600, 8, ODD, 1

Controller Station Number: 0 (

Note 1)

Control Area / Status Area: D0/D10

Connection

a. RS-232 (DOP-A/AE/AS, DOP-B Series)

108 V1.02 Revision November, 2011

DOP Series

9 pin D-sub male (RS-232)

Controller

RXD (2) (3) TXD

TXD (3) (2) RXD

GND (5) (5) SG

(1) CD

b. RS-422 (DOP-A/AE Series)

DOP Series

9 pin D-sub male (RS-422)

Controller

RXD- (1)

SDB

RXD+ (2)

SDA

TXD+ (3)

RDA

(4) DSR[DR]

(6) DTR[ER]

(7) CTS

Summary of content (5 pages)

PAGE 1
Series HMI Connection Manual Mitsubishi A Series/J71UC24 Computer Link HMI Factory Setting: Baud rate: 9600, 8, ODD, 1 Controller Station Number: 0 (Note 1) Control Area / Status Area: D0/D10 Connection a. RS-232 (DOP-A/AE/AS, DOP-B Series) DOP Series Controller 9 pin D-sub male (RS-232) RXD (2) (3) TXD TXD (3) (2) RXD GND (5) (5) SG (1) CD (4) DSR[DR] (6) DTR[ER] (7) CTS b.
PAGE 2
Series HMI Connection Manual c. RS-422 (DOP-AS35/AS38/AS57 Series) DOP Series Controller 9 pin D-sub male (RS-422) R- SDB R+ SDA T+ RDA d. RS-422 (DOP-B Series) DOP Series Controller 9 pin D-sub male (RS-422) RXD- (9) SDB RXD+ (4) SDA TXD+ (1) RDA e. RS-485 (DOP-A/AE Series) DOP Series Controller 9 pin D-sub male (RS-485) V1.
PAGE 3
Series HMI Connection Manual f. RS-485 (DOP-AS57 Series) DOP Series Controller 9 pin D-sub male (RS-485) RDA R+ SDA RDB RSDB g. RS-485 (DOP-AS35/AS38 Series) DOP Series Controller 9 pin D-sub male (RS-485) R+ RDA T+ SDA R- SDB h. RS-485 (DOP-B Series) DOP Series Controller 9 pin D-sub male (RS-485) RDA D+ (1) SDA RDB D- (6) SDB 110 V1.
PAGE 4
Series HMI Connection Manual Definition of PLC Read/Write Address a. Registers Type Format Word No.
PAGE 5
Series HMI Connection Manual b. The mode switch setting of AJ71UC24-R4 communication is 8 (Form 4), station number can be determined by switch setting X1/X10. After PLC communication mode switch is set, please re-activate the PLC. The protocol is CheckSum and PLC Mode is Form 4. For switch setting of other communication parameter, please refers to Mitsubishi user manual. 2) Parameter is set by the programming software GX Developer, please refers to PLC user manual for set up instruction.
