MELSOFT

1. OVERVIEW

This manual describes the functions and operating procedures of GX Configurator-QP.

GX Configurator-QP is a software package that performs various functions such as

data settings, monitoring, and tests for the MELSEC-Q/L series positioning modules.

GX Configurator-QP offers the following functions.

• Setting of positioning data and parameters

• Simulation using positioning data

• Read/write of data from/to positioning module

• Monitoring of positioning control status

• Test operation of positioning control

• Auto refresh setting between QCPU or LCPU devices and positioning module buffer

memory

GX Configurator-QP can be used with any of the following positioning modules.

Model

Positioning module type

MELSEC-Q series MELSEC-L series

Open collector output type QD75P1, QD75P2, QD75P4 LD75P4

Differential driver output type QD75D1, QD75D2, QD75D4 LD75D4

SSCNET connection type QD75M1, QD75M2, QD75M4 -

SSCNET connection type QD75MH1, QD75MH2, QD75MH4 LD77MH4

GX Configurator-QP can access the QD75 via any of the following modules.

Module type Model

QCPU

Q00JCPU, Q00UJCPU, Q00CPU, Q00UCPU, Q01CPU,

Q01UCPU, Q02CPU, Q02HCPU, Q02PHCPU,

Q02UCPU, Q03UDCPU, Q03UDECPU, Q04UDHCPU,

Q04UDEHCPU, Q06HCPU, Q06PHCPU, Q06UDHCPU,

Q06UDEHCPU, Q10UDHCPU, Q10UDEHCPU,

Q12HCPU, Q12PHCPU, Q13UDHCPU, Q13UDEHCPU,

Q20UDHCPU, Q20UDEHCPU, Q25HCPU, Q25PHCPU,

Q26UDHCPU, and Q26UDEHCPU

Q corresponding serial

communication module

QJ71C24(N), QJ71C24(N)-R2

Q corresponding MELSECNET/H

network remote I/O module

QJ72LP25-25, QJ72BR15, QJ72LP25G, QJ72LP25GE

C Controller module Q12DCCPU-V

: Only when connecting to the remote I/O module directly.
