MITSUBISHI ELECTRIC MELSEC ST Series Programmable Logic Controllers User's Manual Profibus/DP Head Module Art. no.
SAFETY PRECAUTIONS (Read these precautions before using.) When using Mitsubishi equipment, thoroughly read this manual and the associated manuals introduced in this manual. Also pay careful attention to safety and handle the module properly. The precautions given in this manual are concerned with this product. Refer to the user's manual of the network system to use for a description of the network system safety precautions.
[DESIGN PRECAUTIONS] ! CAUTION Make sure to initialize the network system after changing parameters of the MELSEC-ST system or the network system. If unchanged data remain in the network system, this may cause malfunctions. Do not install the control wires or communication cables together with the main circuit or power wires. Keep a distance of 100 mm (3.94 inch) or more between them. Not doing so could result in malfunctions due to noise.
[INSTALLATION PRECAUTIONS] ! CAUTION Make sure to securely connect each cable connector. Failure to do so may cause malfunctions due to poor contact. DIN rail must be conductive; make sure to ground it prior to use. Failure to do so may cause electric shocks or malfunctions. Undertightening can cause a drop, short circuit or malfunction. Overtightening can cause a drop, short circuit or malfunction due to damage to the screw or module.
[STARTUP AND MAINTENANCE PRECAUTIONS] ! DANGER Do not touch the terminals while power is on. Doing so could cause shock or erroneous operation. Make sure to shut off all phases of the external power supply for the system before cleaning the module or tightening screws. Not doing so can cause the module to fail or malfunction. [STARTUP AND MAINTENANCE PRECAUTIONS] ! CAUTION Do not disassemble or modify the modules. Doing so could cause failure, erroneous operation, injury, or fire.
REVISIONS The manual number is given on the bottom left of the back cover. Print Date Dec., 2003 Manual Number SH(NA)-080436ENG-A First edition Revision Japanese Manual Version SH-080435-A This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.
INTRODUCTION Thank you for choosing the ST1H-PB MELSEC-ST PROFIBUS-DP head module. Before using the module, please read this manual carefully to fully understand the functions and performance of the ST1H-PB MELSEC-ST PROFIBUS-DP head module and use it correctly. CONTENTS SAFETY PRECAUTIONS..............................................................................................................................A- 1 REVISIONS .................................................................................
4.4 Online module change ............................................................................................................................. 4-22 4.4.1 Precautions for the online module change....................................................................................... 4-22 4.4.2 Procedures for online module change.............................................................................................. 4-24 4.4.3 Online module change using head module buttons........................
TROUBLESHOOTING 9- 1 to 9-16 9.1 When I/O data cannot be communicated................................................................................................ 9- 2 9.1.1 When RUN LED is off ....................................................................................................................... 9- 4 9.1.2 When BF LED is on........................................................................................................................... 9- 5 9.1.
About Manuals The following manuals are related to this product. Referring to this list, please request the necessary manuals. Relevant Manuals Manual Name MELSEC-ST System User's Manual Explains the system configuration of the MELSEC-ST system and the performance specifications, functions, handling, wiring and troubleshooting of the power distribution modules, base modules and I/O modules.
How to Read Manual This manual explains each area for input data and output data using the following symbols. (1) Data symbol Cr. 0 (7-0) Range In the case of 1-word (16 bit) data, this shows the corresponding range. (0) : Shows 0 bit position (7-0): Shows 0-7 bit range Detail data No. Abbreviated data symbol For details of detail data No. and abbreviated data symbol, refer to (2) and (3) (2) Input data Br Data symbol Br.00 to Br.FF Er Er.00 to Er.
(3) Output data Bw Data symbol Bw.00 to Bw.FF Ew Ew.00 to Ew.FF Sw Sw.0 to Sw.7 Cw Ww 1 Ww.00 to Ww.33 Area Bit Output Area Unit 1 bit/1 signal Detail data No. notation Hexadecimal Error Clear Area 1 bit/1 signal Hexadecimal System Area 1 word/1 signal Decimal Command Execution Area 1 word/1 signal Decimal Word Output Area 1 word/1 signal Hexadecimal 1: Following shows the data symbols and the corresponding detail areas within the command execution area. Data symbol Cw.
About the Generic Terms and Abbreviations Unless otherwise specified, this manual uses the following generic terms and abbreviations to explain the head module. Description Generic Term/Abbreviation Head module ST1H-PB, MELSEC-ST PROFIBUS-DP compatible head module. PROFIBUS-DP PROFIBUS-DP network. Bus refreshing module Module that distributes the external SYS. power supply and external AUX. power supply among the head module and slice modules.
Term definition The following explains the meanings and definitions of the terms used in this manual. Term Definition Master station Class 1 master station that communicates I/O data with slave stations. Slave station Device that communicates I/O data with the master station. Repeater Device that connects PROFIBUS-DP segments. Bus terminator Terminator that is connected to both ends of each PROFIBUS-DP segment FDL address Address assigned to the master station/slave station.
Packing List The following gives the packing list of the head module.
1 OVERVIEW MELSEC-ST 1 OVERVIEW This manual explains the specifications, functions, pre-operation procedures and troubleshooting of the ST1H-PB MELSEC-ST PROFIBUS-DP head module (hereafter referred to as the head module). The head module is used to connect a MELSEC-ST system to a PROFIBUS-DP network. (The head module operates as a slave station of a PROFIBUS-DP network.
1 OVERVIEW MELSEC-ST 1.1 Features 1 The head module has the following features. (1) MELSEC-ST system can be connected to PROFIBUS-DP network By mounting this module as the head module of a MELSEC-ST system, the MELSEC-ST system can be connected to the PROFIBUS-DP network. The head module complies with EN50170 Volume 2 (Part 1, 2, 3, 4, 8) and communicates with the master station as a PROFIBUS-DP slave station. Class 1 master station Slave station No. 1 Slave station No. 2 MELSEC-ST Slave station No.
1 OVERVIEW MELSEC-ST (2) Controlling the MELSEC-ST system The head module receives data output from the master station, stores the data into the output receiving area, and uses them to control each slice module. Also, the head module gathers various information such as the input status data from each slice module into the input sending area, and sends them to the master station as input data.
1 OVERVIEW MELSEC-ST (4) Controlling various slice modules The head module can control various MELSEC-ST slice modules in the same system. (a) Up to 63 slice modules can be mounted The head module accepts up to 63 slice modules (up to 26 intelligent function modules). (b) Error status and mounting status of each slice module can be checked In each of input data area in the head module, the error status, mounting status, etc. of each slice module can be checked.
1 OVERVIEW MELSEC-ST (6) Online module change The I/O modules and intelligent function modules can be replaced without stopping the MELSEC-ST system. (Refer to Section 4.4.
2 SYSTEM CONFIGURATION MELSEC-ST 2 SYSTEM CONFIGURATION This chapter explains the system configuration in which the head module is used. Class 1 master station 2 MELSEC-ST Slave station No. 1 Slave station No. 2 Slave station No. 30 Repeater Slave station No. 31 MELSEC-ST Slave station No. 60 Slave station No. 32 MELSEC-ST system 1 ST1PSD ST1H-PB RUN SYS AUX.
2 SYSTEM CONFIGURATION MELSEC-ST MEMO 2 2-2 2-2
3 SPECIFICATIONS MELSEC-ST 3 SPECIFICATIONS This chapter explains the performance specifications of the head module. For the general specifications of the head module, refer to the MELSEC-ST System User's Manual. 3.1 Performance Specifications This section explains the performance specifications of the head module.
3 SPECIFICATIONS MELSEC-ST (1) I/O data sizes The following table indicates the data sizes for maximum input/output points. Refer to Section 3.2.1 and Section 3.2.2 for the I/O data offset addresses. Maximum input/output points 32-point mode 64-point mode 128-point mode 256-point mode Input Output Input Output Input Output Input Output 32 bits 32 bits 64 bits 64 bits 128 bits 128 bits 256 bits 256 bits Max. 52 Max. 52 Max. 52 Max. 52 Max. 52 Max. 52 Max. 32 Max.
3 SPECIFICATIONS MELSEC-ST 3.2 Communication between Master Station and MELSEC-ST System For communication between the master station and MELSEC-ST system, use input data sent from the head module to the master station and output data sent from the master station to the head module.
3 SPECIFICATIONS MELSEC-ST [Processing outline of MELSEC-ST system Master station] 1) The status data of the external device are imported to the input status area of the slice module. 2) The input status data of each slice module is stored into the input sending area of the head module. 3) The input data in the input sending area is sent to the corresponding input image area in the master station.
3 SPECIFICATIONS MELSEC-ST 3.2.1 Input data specifications This section explains the data sizes of input data and the details of each area. POINT In this manual, input data addresses (input image addresses on the master station side) are indicated as offset addresses (word unit). [Offset address] Denotes a data position in word units, relative to the first address of the input image assigned for the MELSEC-ST system on the master station side.
3 SPECIFICATIONS MELSEC-ST (b) 64-point mode Offset address (Decimal) Application Data size +0 Br.00 to Br.3F Br Bit input area 4 words Refer to (2) in this section. to Er.00 to Er.3F Er Error information area 4 words Refer to (3) in this section. +7 +8 +9 +10 Mr.0 to Mr.31 Mr Module status area 2 words Refer to (4) in this section. to Cr.0 to Cr.3 Cr Command result area 4 words Refer to (5) in this section. Wr.00 to Wr.
3 SPECIFICATIONS MELSEC-ST (d) 256-point mode Offset address (Decimal) Application Data size +0 to Br.00 to Br.FF Br Bit input area 16 words Refer to (2) in this section. Er.00 to Er.FF Er Error information area 16 words Refer to (3) in this section. Mr.0 to Mr.127 Mr Module status area 8 words Refer to (4) in this section. Cr.0 to Cr.3 Cr Command result area 4 words Refer to (5) in this section. Wr.00 to Wr.
3 SPECIFICATIONS MELSEC-ST (2) Br Bit input area The Br Bit input area stores the ON/OFF information of the Br.n bit inputs entered from the head module and slice modules. Each of the head module and slice modules occupies 2 bits per slice. The construction of the Br Bit input area is shown below. Maximum input/output points 2561286432point point point point mode mode mode mode Slice No. Br Bit input area b15 b0 Br.0F Used area Used area Br.0E Br.0D Br.1E Br.1D Br.2E Br.2D Br.3E Br.3D Br.
3 SPECIFICATIONS MELSEC-ST (3) Er Error information area The Er Error information area stores the statuses (error information) of the head module and slice modules. Each of the head module and slice modules occupies 2 bits per slice. The construction of the Er Error information area is shown below. Maximum input/output points 2561286432point point point point mode mode mode mode Slice No. Er Error information area b15 b0 Er.0F Used area Used area Er.0E Er.0D Er.1E Er.1D Er.2E Er.2D Er.3E Er.
3 SPECIFICATIONS MELSEC-ST (4) Mr Module Status area The Mr Module Status area stores the information of the slice modules recognized by the head module. Each of the head module and slice modules occupies 1 bit per slice. The construction of the Mr Module Status area is shown below. Maximum input/output points 2561286432point point point point mode mode mode mode Used area Used area Used area Used area Slice No. Mr Module status b15 Mr.15 b0 Mr.14 Mr.13 Mr.12 Mr.11 Mr.10 Mr.9 Mr.8 Mr.7 Mr.
3 SPECIFICATIONS (5) MELSEC-ST Cr Command result area The Cr Command result area stores the results of executing a command to the head module or each slice module. The values stored in the Cr Command execution area all turn to 0 when the Bw.03 Command execution request is turned off. Refer to Chapter 8 for details of the commands. (a) Construction of Cr Command result area The construction of the Cr Command result area is shown below.
3 SPECIFICATIONS (6) MELSEC-ST Wr Word input area The Wr Word input area stores Wr.n Word input values received from the intelligent function modules in order of the mounted position. (a) Construction of Wr Word input area The construction of the Wr Word input area is shown below. Maximum input/output points 2561286432point point point point mode mode mode mode b0 b15 Wr.00 Intelligent function module word input data 1 Wr.
3 SPECIFICATIONS MELSEC-ST 2) When intelligent function modules are used Reserve the Wr Word input area for as many as the Wr.n Word input points used by the intelligent function modules. The Wr Word input area is assigned in order of mounting the intelligent function modules. < Wr Word input area assignment example> 1) System example Mounted module Start slice No. 2) Module type Wr.
3 SPECIFICATIONS MELSEC-ST 3.2.2 Output data specifications This section explains the data sizes of output data and the details of each area. POINT In this manual, output data addresses (output image addresses on the master station side) are indicated as offset addresses (word unit). [Offset address] Denotes a data position in word units, relative to the first address of the output image assigned for the MELSEC-ST system on the master station side.
3 SPECIFICATIONS MELSEC-ST (b) 64-point mode Offset address (Decimal) Application Data size +0 to Bw.00 to Bw.3F Bw Bit output area 4 words Refer to (2) in this section. Ew.00 to Ew.3F Ew Error clear area 4 words Refer to (3) in this section. Sw System Area 2 words +3 +4 to +7 +8 Sw.0 to Sw.1 +9 +10 to Cw.0 to Cw.3 Cw Command execution area 4 words Ww.00 to Ww.33 Ww Word output area Refer to (4) in this section. Refer to (5) in this section.
3 SPECIFICATIONS MELSEC-ST (d) 256-point mode Offset address (Decimal) Application Data size +0 to Bw.00 to Bw.FF Bw Bit output area 16 words Refer to (2) in this section. Ew.00 to Ew.FF Ew Error clear area 16 words Refer to (3) in this section. Sw.0 to Sw.7 Sw System Area 8 words Cw.0 to Cw.3 Cw Command execution area 4 words Ww.00 to Ww.1F Ww Word output area +15 +16 to +31 +32 to Refer to (4) in this section. +39 +40 to Refer to (5) in this section.
3 SPECIFICATIONS MELSEC-ST (2) Bw Bit output area The Bw Bit output area stores the ON/OFF information of the Bw.n Bit outputs provided to the head module and slice modules. Each of the head module and slice modules occupies 2 bits per slice. The construction of the Bw Bit output area is shown below. Maximum input/output points 2561286432point point point point mode mode mode mode Slice No. Bw Bit output area b15 b0 Bw.0F Bw.0E Bw.0D Bw.0C Bw.0B Bw.0A Bw.
3 SPECIFICATIONS MELSEC-ST (3) Ew Error clear area The Ew Error clear area stores the error information clear requests of the head module and slice modules. This area is used to clear the corresponding error information (turn off the bit) of the head module or slice module after the error is remedied. Each of the head module and slice modules occupies 2 bits per slice. The construction of the Ew Error clear area is shown below.
3 SPECIFICATIONS MELSEC-ST (4) Sw System area The Sw System area is used by the head module system. Store 0 (fixed) into the Sw System area. The construction of the Sw System area is shown below. Maximum input/output points 2561286432point point point point mode mode mode mode Used area Used area Used area b15 b0 Sw.0 System Area 1 Sw.1 System Area 2 Sw.2 System Area 3 Sw.3 System Area 4 Used area Sw.4 System Area 5 Sw.5 System Area 6 Sw.6 System Area 7 Sw.
3 SPECIFICATIONS MELSEC-ST (5) Cw Command execution area The Cw Command execution area stores the information of the command to be executed for the head module or each slice module. Refer to Chapter 8 for details of the commands. (a) Construction of Cw Command execution area The construction of the Cw Command execution area is shown below. Maximum input/output points 256point mode 128point mode 64point mode 32point mode b15 b0 Cw.0 Start slice No.
3 SPECIFICATIONS MELSEC-ST (6) Ww Word output area Stores the Ww.n Word output values of the intelligent function modules in order of the mounted position. (a) Construction of Ww Word output area The construction of the Ww Word output area is shown below. Maximum input/output points 256point mode 128point mode 64point mode 32point mode b0 b15 Ww.00 Intelligent function module word input data 1 Ww.01 Intelligent function module word input data 2 Used area Used area Used area Used area Ww.
3 SPECIFICATIONS MELSEC-ST 2) When intelligent function modules are used Reserve the Ww Word output area for as many as the Ww.n Word output points used by the intelligent function modules. The Ww Word output area is assigned in order of mounting the intelligent function modules. < Ww Word output area assignment example> 1) System example Mounted module Start slice No. Module type 2) Number of Occupied Slices Ww.
3 SPECIFICATIONS MELSEC-ST 3.2.3 I/O data used by head module This section explains the areas used for I/O data by the head module and their applications and information. REMARK For the applications of the areas assigned to each slice module, refer to the manual of each slice module. (1) Input data (a) Br Bit input area The following table describes the applications of the Br Bit input area used by the head module. The head module uses the first 4 bits ( Br.00 to Br.03 ) of the Br Bit input area. Br.
3 SPECIFICATIONS MELSEC-ST (b) Er Error information area The following table indicates the information of the Er Error information area used by the head module and the error codes corresponding to the error information. The head module uses the first 4 bits ( Er.00 to Er.03 ) of the Er Error information area. Read the error code from the head module by any of the following methods. (Refer to Section 9.2.
3 SPECIFICATIONS MELSEC-ST (2) Output data (a) Bw Bit output area The following table describes the applications of the Bw Bit output area used by the head module. The head module uses the first 4 bits ( Bw.00 to Bw.03 ) of the Bw Bit output area. Bw.n Bit output Bw.n Bit output status Application Bw.00 System area Bw.01 0 (Fixed) Use prohibited Bw.02 Command request Bw.03 The command sent from the master station is requested to be executed.
3 SPECIFICATIONS MELSEC-ST 3) Precautions for using the Ew.n error clear If an error cause has not yet been eliminated when the error clear request bit is turned off, the error information is set to the Er Error information area again. (While the Ew.n Error clear is on, the corresponding bits of the Er Error information area all turn off.) ON OFF Ew.
3 SPECIFICATIONS MELSEC-ST 3.3 Head Module Processing Time This section explains the processing time of the head module in the MELSEC-ST system. Communication processings between the master station and MELSEC-ST system are outlined below. (1) Input data processing outline How input data from an external device is sent to the master station is shown below. ON Class 1 master station PROFIBUS-DP Head module Refer to the manual of the master station for the master station processing time.
3 SPECIFICATIONS MELSEC-ST 3.3.1 ST bus cycle time ST bus cycle time is the time required for the head module to refresh input or output data for the slice modules. This section explains the ST bus cycle time expression and processing time example. (1) ST bus cycle time expression The expression for calculating the ST bus cycle time is given below.
3 SPECIFICATIONS MELSEC-ST (2) Processing time example The following system configuration example is used to explain a processing time example of ST bus cycle time. (The following table uses the maximum input/output points sheet provided in Appendix 2.1.) No.0 No.1 No.2 No.3 No.4 No.5 No.6 . No. Module name Number of Occupied I/O Points Start Slice No. (Number of occupied slices) 0 ST1H-PB 4 0(2) 1 ST1PSD 2 2(1) 2 ST1X2-DE1 2 3(1) 3 ST1Y2-TE2 2 4 ST1PDD 2 Wr.n Ww.
3 SPECIFICATIONS MELSEC-ST 3.3.2 Input transmission delay time This section explains the time required from when the slice module receives input data from the external device until it outputs that data onto the PROFIBUS-DP line. (1) Average delay time Average input transmission delay time is indicated below. Input transmission delay time = 1) + (1.5 ST bus cycle time) + (0.
3 SPECIFICATIONS MELSEC-ST 3.3.3 Output transmission delay time This section explains the time required from when the head module receives output data from the master station until the slice module outputs data to the external device. (1) Average delay time Average output transmission delay time is indicated below. Output transmission delay time = (1.0 ST bus cycle time) + 1) ST bus cycle time: Refer to Section 3.3.1.
4 FUNCTIONS MELSEC-ST 4 FUNCTIONS This chapter explains the head module functions. 4.1 Function List The head module functions are listed below. (1) Network functions The following table describes the head module functions used in the PROFIBUSDP network. To use the following functions, set the user parameters on the configuration software of the master station.
4 FUNCTIONS MELSEC-ST (2) Control functions The following table describes the functions used by the head module to control the slice modules. Function name 1) Setting of output Sets whether the refresh of data output to the other normally status at module operating output modules and intelligent function modules will be error stopped or continued when an error occurs in a slice module. Information Monitors various information of the head module and slice monitor modules.
4 FUNCTIONS MELSEC-ST 4.2 Network Functions This section explains the head module functions used in the PROFIBUS-DP network. 4.2.1 I/O data communication function (1) I/O data communication function I/O data can be communicated with the Class 1 master station (master station that makes cyclic data communication with slave stations) of PROFIBUS-DP.
4 FUNCTIONS MELSEC-ST (3) I/O status when the CPU stop error has occurred in master station If an error (PLC CPU stop error) has occurred in a master station, the I/O status of the master station varies with the master station used. The following table shows the I/O status when an error has occurred in a master station for each model.
4 FUNCTIONS MELSEC-ST 4.2.2 Global control function (1) Global control function The inputs/outputs of slave stations are controlled simultaneously for each specified group by multicasting (broadcasting) from the master station. The head module that executes the global control function belongs to one or more groups specified by the master station. Set the group number of the head module using the configuration software of the master station.
4 FUNCTIONS MELSEC-ST (3) Outline of service operations The following shows the outline of the SYNC and UNSYNC services and FREEZE and UNFREEZE services.
4 FUNCTIONS MELSEC-ST (b) When receiving FREEZE and UNFREEZE services 1) Before receiving FREEZE service Class 1 master station Head module Slice module Input data Input data Input status Output data Output data Output status Head module Slice module Input data Input data Input status Output data Output data Output status 2) After receiving FREEZE service FREEZE service Class 1 master station When receiving the FREEZE service, the head module enters the FREEZE mode, and stops refresh fro
4 FUNCTIONS MELSEC-ST 4.2.3 Extended diagnostic information notification function (1) Extended diagnostic information notification function When errors occur in the head module and/or slice modules, this function can notify the master station of the errors of up to 2 modules in chronological order. When the head module has notified the master station of extended diagnostic information, the DIA LED of the head module is on.
4 FUNCTIONS MELSEC-ST (3) Extended diagnostic information data (a) Data sent to master station When the extended diagnostic information notification function is set to "Enable (notified)", the head module sends the following data to the extended diagnostic information area of the master station. Refer to the manual of the master station for the extended diagnostic information area of the master station. Offset address Name (Unit: Word) + 0 Head module error code +1 Error slice No.
4 FUNCTIONS MELSEC-ST 2) Error slice module information area Stores the information of up to 2 error slice modules in chronological order. The details of the error slice module information area are described below. Name Description Stores the start slice No. of the slice module where an Error slice No. error occurred. (Stores 0000H when no error has occurred.) Detail error code 1 Detail error code 2 Stores the error code 1 2 of the slice module where an error occurred.
4 FUNCTIONS MELSEC-ST 4.2.4 Swap function (1) Swap function The high and low bytes are swapped in word units when input or output data are sent to or received from the master station or when extended diagnostic information is sent to the master station. When the relevant user parameter of the head module is set to "Enable (swapped)", the following processing is executed. I/O data ....The data stored in the input sending area are sent to the master station after their high and low bytes have been swapped.
4 FUNCTIONS MELSEC-ST (b) Swap function setting by master station type The swap function setting changes depending on the master station type as described below.
4 FUNCTIONS MELSEC-ST (3) Setting and operation outline for extended diagnostic information swapping The following describes the setting for extended diagnostic information swapping and the data construction of the extended diagnostic information. (a) Setting at master station To swap extended diagnostic information, swap setting must be made on the configuration software of the master station.
4 FUNCTIONS MELSEC-ST 4.2.5 I/O data consistency function (1) I/O data consistency function This function prevents data inconsistency between the communication data of PROFIBUS-DP and the I/O data of the head module. When using either or both of the following items in the MELSEC-ST system, make the data consistency function setting.
4 FUNCTIONS MELSEC-ST (4) Difference between operations depending on setting The following shows a difference between head module and intelligent function module operations depending on the setting. (a) Example of command execution Master station that cannot prevent inconsistency of whole output data 1) Bw.03 Command request 2) Command execution data ( Cw Command execution area) Class 1 master station 3) Command result data ( Cr Command result area) 4) Br.
4 FUNCTIONS MELSEC-ST (b) Example of communication with intelligent function module (digital-analog conversion module) Master station that cannot prevent inconsistency of whole output data Class 1 master station 1) CH output enable/disable flag ( Bw Bit output area) 2) CH digital value setting ( Ww Word output area) 3) Analog value output 2) MELSEC-ST 1) system slave station 3) External device When receiving the CH output enable/disable flag, the int
4 FUNCTIONS MELSEC-ST 4.3 Control Functions This section explains the functions used to control each slice module. 4.3.1 Setting of output status at module error (1) Setting of output status at module error This is set to determine whether the refresh of output data to the other normallyoperating output modules and intelligent function modules will be stopped or continued when an error occurs in a slice module (except the power distribution module).
4 FUNCTIONS MELSEC-ST (3) I/O status at error occurrence (a) When communication timeout occurs between head module and master station The following shows the I/O statuses of the normally operating slice modules when a communication timeout occurs between the head module and the master station. In order to detect a communication timeout with the master station, the communication watchdog timer must be preset using configuration software on the master station. For details, refer to Section 6.2.
4 FUNCTIONS MELSEC-ST 4.3.2 Status monitor (1) Status monitor Various information of the head module and slice modules can be monitored using input data, a command request from the master station or GX ConfiguratorST. (2) Items that can be monitored The following table indicates various information that can be monitored by the status monitor.
4 FUNCTIONS MELSEC-ST (3) When using GX Configurator-ST for monitoring When monitoring each module from GX Configurator-ST, activate the System Monitor screen. For details, refer to the GX Configurator-ST Manual. I/O data statuses can be confirmed. Each module operating status can be checked. Error code of current error is shown. Error history can be confirmed.
4 FUNCTIONS MELSEC-ST 4.3.3 Intelligent function module parameter read/write (1) Intelligent function module parameter read/write Parameters can be read from or written to the ROM or RAM of the intelligent function module. (2) Intelligent function module parameter read/write operation Read or write the intelligent function module parameters as described below. (a) User parameters 1) Reading the user parameters Read the user parameters in either of the following methods.
4 FUNCTIONS MELSEC-ST 4.4 Online module change (1) Online module change function The I/O modules and intelligent function modules can be replaced without stopping the MELSEC-ST system. An online module change can be executed by operation of the head module buttons or from GX Configurator-ST. 4.4.1 Precautions for the online module change The precautions for the online module change are given below.
4 FUNCTIONS MELSEC-ST (8) While the slice module is being replaced online (while the head module's REL. LED is on), change its user parameter setting from the master station after the online module change is completed. If the user parameter setting is changed from the master station during the online module change, the new setting is not validated since the user parameters saved in the head module are written over the new user parameter values when the online module change is finished.
4 FUNCTIONS MELSEC-ST 4.4.2 Procedures for online module change This section explains the procedures for the online module change. Replace a module online as shown below. Start Is the online module change executable in the system configuration? 1 No Yes Has the preparation been done for the online module change? 2 No Yes Is disconnection from the external device possible? No 3 Yes Online module change is not executable.
4 FUNCTIONS MELSEC-ST 4.4.3 Online module change using head module buttons This section explains the procedures for the replacing a module online by operating the buttons on the head module. Before replacing slice module 1) Specify the module to be replaced online. Press the "+" button of the head module. Then, the RUN LED of the bus refreshing module mounted next to the head module flickers at intervals of 0.25 seconds.
4 FUNCTIONS MELSEC-ST Hold down RELEASE button until REL. LED of head module turns off and RUN LED of module to be changed turns off. 2) Keep pressing the RELEASE button of the head module until its REL. LED lights up. When the REL. LED turns on, the head module saves the user parameters and command parameters from the target slice module into the head module. Since the following conditions means the online module change is available, release the RELEASE button. • The REL.
4 FUNCTIONS MELSEC-ST Connection to external device after replacement Switch RUN 6) After mounting a new slice module, connect it to the external device. For details, refer to "External device connection and disconnection procedures for online module change". ERR ON OFF External device Operations after external device connection Hold down RELEASE button until REL. LED of head module flickers and RUN LED of new module flickers (0.25s intervals).
4 FUNCTIONS MELSEC-ST 4.4.4 Online module change from GX Configurator-ST Here is an explanation of how to replace a module online from GX Configurator-ST. POINT If a slice module different from the target one is selected by mistake, restart the operation as instructed below. (1) To restart the operation at step 3) Click the Cancel button on the screen to terminate online module change.
4 FUNCTIONS MELSEC-ST (From the previous page.) 3) Confirm that the slice module displayed as "Target Module" is the slice module to be replaced and click the Next button. (a) Clicking the Next button validates the settings and the following will be performed. • Puts the head module into the online module change mode. • Transfers the user parameters and command parameters of the target slice module to the head module. (b) After clicking the Next button, confirm the following module statuses. • The REL.
4 FUNCTIONS MELSEC-ST (From the previous page.) Disconnection from external device 4) When the left screen appears, disconnect the external device from the slice module to be replaced online. For details, refer to "External device connection and disconnection procedures for online module change" in the corresponding slice module manual.
4 FUNCTIONS MELSEC-ST (From the previous page.) Connection to external device after replacement Switch RUN ERR ON OFF 7) After mounting a new slice module, connect it to the external device. For details, refer to "External device connection and disconnection procedures for online module change". External device Operations after external device connection 8) After connecting the external device, click the Next button on the screen in step 4). (a) Clicking the Next button performs the following.
4 FUNCTIONS MELSEC-ST (From the previous page.) 9) Clicking the Next button releases the head module from the online module change mode. (a) Clicking the Next button performs the following. • Releases the head module from the online module change mode. • Restarts refreshing the I/O data, etc. (b) After clicking the Next button, confirm the following module statuses. • The REL. LED of the head module is off. • The RUN LED of the newly mounted slice module is on.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST 5 PRE-OPERATION PROCEDURE AND SETTING This chapter explains the procedure and setting method for operating the head module in the MELSEC-ST system. 5.1 Mounting and Installation This section explains the handling precautions on procedures from product unpacking to mounting. For the mounting and installation of the MELSEC-ST system, refer to the MELSEC-ST System User's Manual. 5.1.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST 5.2 Pre-operation Procedure and Setting A rough pre-operation procedure is given below. Start MELSEC-ST system construction Mount each module and wire the external power supply and external device. Refer to the manual of each slice module. Set the FDL address of the MELSEC-ST system. Refer to Section 5.3.1. Connect the PROFIBUS cable. Refer to Section 5.5. Switch on the external power supply of the MELSEC-ST system.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST 5.3 Part Names and Settings This section explains the part names and settings of the head module. [Front (connector cover open)] 2) 10) ON 80 40 20 10 8 4 N 2 O. 1 S T SYN. A FRE. TI O N 1 2 3 4 5 6 7 8 3) M1 M0 9) ON 1) RUN ERR. REL. DIA BF [Right side view] RS-232 RELEASE 4) RESET 5) 6) PROFIBUS I/F 7) 11) 12) 8) Name 1) Operating status LED Description Indicates the operating status of the head module.
5 PRE-OPERATION PROCEDURE AND SETTING Name MELSEC-ST Description 8) Display plate Write the FDL address, etc. of the head module. 9) Base module connector Connects the power distribution module base next to the right of the head module. 10) Lock lever Dismounts the head module from the DIN rail. 11) DIN rail mounting groove Mounts the module to the DIN rail. Grounding metal spring.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST (1) Operating status LED M1 M0 RUN ERR. REL. DIA BF LED indication LED status On RUN Flickering Off On ERR. Flickering Off On REL. Flickering Off On DIA BF Flickering SYN. FRE. 1 Description Normally operating Self-diagnostics or forced output test mode being executed Watchdog time error occurred or external power-off Error occurred in head module or slice module (Refer to Section 9.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST 5.3.1 Setting of FDL address setting switches This section explains the applications, setting ranges and setting method of the head module's FDL address setting switches. (1) Applications Use the FDL address setting switches of the head module for the following: Setting the FDL address as a PROFIBUS-DP slave station. Executing the self-diagnostics of the head module. (2) Setting range Set the FDL address setting switches within the following ranges.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST (3) Setting method The sum of the switch Nos. of the FDL address setting switches that are set to ON is registered as the FDL address of the head module. Set the tens place of the FDL address with any of the STATION NO. "10", "20", "40" and "80" switches. Set the units place of the FDL address with any of the STATION NO. "1", "2", "4" and "8" switches. STATION NO.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST REMARK Never set the switches as shown below (a sum of the switch Nos. in the units place is 10 or more). To do so will cause an error in the head module. STATION NO. FDL address 32 10s place 1s place 80 40 20 10 8 4 2 1 OFF OFF ON OFF ON ON OFF OFF ON ON 5-8 1 2 3 4 5 6 7 8 80 40 20 10 8 4 N 2 O.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST 5.3.2 Reset operation This section explains how to reset the head module using its RELEASE, + and buttons. (1) Reset method Reset the head module as described below. 1) Press the RELEASE, + and - buttons at the same time. M1 M0 ON 1 2 3 4 5 6 7 8 80 40 20 10 8 4 N 2 O. 1 S T SYN. A FRE. TI O N ON RUN ERR. REL. DIA BF RS-232 RELEASE RESET Press 3 buttons simultaneously. 2) When all LEDs turn off, reset processing is completed.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST 5.4 Self-diagnostics Self-diagnostics tests the head module singly. (1) Self-diagnostics execution procedure Execute the self-diagnostics in the following procedure. (a) When the external power supply of the MELSEC-ST system is on, switch it off. (b) Disconnect the PROFIBUS cable from the head module. (c) Set the FDL address of the head module to 150 as shown below. STATION NO.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST 5.5 Wiring This section explains PROFIBUS cable wiring and wiring precautions. 5.5.1 PROFIBUS cable wiring This section explains the PROFIBUS-DP interface connector pin-outs of the head module, the wiring specifications of the PROFIBUS cable, and the bus terminator. (1) PROFIBUS-DP interface connector pin-outs The PROFIBUS-DP interface connector (D-sub 9-pin female connector) pin-outs of the head module are indicated below. Pin No.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST (b) Wiring specifications Head module 1 SHIELD PROFIBUS cable 3 RxD/TxD-P 8 RxD/TxD-N (c) Connector Use a D-Sub 9-pin male connector for the PROFIBUS cable. The applicable screw size is #4-40 UNC. (3) Bus terminator The bus terminator is user-prepared.
5 PRE-OPERATION PROCEDURE AND SETTING MELSEC-ST 5.5.2 Wiring precautions As one of the conditions to make full use of the head module functions and configure a reliable system, the influence of noise must be minimized in the external wiring. The following gives the precautions for external wiring of the head module. (1) Do not install the PROFIBUS cable together with the main circuit and power cables or the load wires used for other than the MELSEC-ST system.
6 PARAMETER SETTING MELSEC-ST 6 PARAMETER SETTING This chapter explains the head module parameters. Each of the modules that comprise the MELSEC-ST system has the following parameters. Parameter Setting item Description 1) 2) 3) 4) Parameters for storing the mounting status (Module Configuration) Select Modules 1 of each module set by the configuration software of the master station. By setting this parameter, the user parameter setting of each Slave parameter module is enabled.
6 PARAMETER SETTING MELSEC-ST 6.1 Select Modules To set the "Select Modules" slave parameter, the configuration of the MELSEC-ST system and the maximum input/output points of the head module must be taken into consideration. (1) MELSEC-ST system construction Construct the MELSEC-ST systems within the ranges where the head module and slice modules satisfy the following conditions 1) to 4).
6 PARAMETER SETTING MELSEC-ST 6.1.1 Selection and setting of maximum input/output points To use the head module, the maximum input/output points must be set in consideration of the following items.
6 PARAMETER SETTING MELSEC-ST (4) Setting of maximum input/output points After the maximum input/output points used in the MELSEC-ST system are selected, they must be set to the head module. The maximum input/output points determine the I/O data size. (Refer to Section 3.2.) Set the maximum input/output points using the slave parameter (Select Modules) of the master station. The setting item of Select Modules is determined by the maximum input/output points and master station's consistency function.
6 PARAMETER SETTING MELSEC-ST 6.1.3 Parameter setting example The following system configuration example is used to explain a parameter setting example and I/O data assignment. (1) System configuration example The following system configuration example is used to make explanation in this section. No.0 6-5 No.1 No.2 No.3 No.4 No.5 No.
6 PARAMETER SETTING MELSEC-ST (2) Setting of maximum input/output points In the system configuration example in (1) of this section, the "[A] Sum total of occupied I/O points" and "[D] Maximum word input/output points" are as listed below. (The following table uses the maximum input/output points setting sheet provided in Appendix 2.1.) Number of No. Module Name Occupied I/O Points Start Slice No. (Number of occupied slices) Wr.n Ww.
6 PARAMETER SETTING MELSEC-ST (3) I/O data assignment The following shows the I/O data assignment result in the system configuration example in (1) of this section. (a) Input data Offset address b15 Br.0F Br.0E Br.1F Br.1E Er.0F Er.0E Er.1F Er.1E Mr.15 Mr.14 Br.0D Br.0C Br.0B Br.0A Br.1D Br.1C Br.1B Br.1A Er.0D Er.0C Er.0B Er.0A Er.1D Er.1C Er.1B Er.1A Mr.13 Mr.12 Mr.11 Mr.10 Br.09 b8 b7 Br.08 Br.07 b0 Br.06 Br.05 Br.04 Br.03 Br.02 Br.01 Br.00 +0 No.5 No.4 No.
6 PARAMETER SETTING MELSEC-ST (b) Output data Offset address b15 b8 Bw.0F Bw.0E Bw.0D Bw.0C Bw.0B Bw.0A Bw.09 b7 b0 Bw.08 Bw.07 Bw.06 Bw.05 Bw.04 Bw.03 Bw.02 Bw.01 Bw.00 +0 No.5 No.3 No.4 Bw.1F Bw.1E Bw.1D Bw.1C Bw.1B Bw.1A Bw.19 No.2 No.1 No.0 Bw.18 Bw.17 Bw.16 Bw.15 Bw.14 Bw.13 Bw.12 Ew.08 Ew.07 Ew.06 Ew.05 Ew.04 Ew.03 Ew.02 Bw.11 Bw.10 Bw Bit output area +1 0 No.6 Ew.0F Ew.0E Ew.0D Ew.0C Ew.0B Ew.0A Ew.09 Ew.01 Ew.00 +2 No.5 No.4 No.3 Ew.1F Ew.1E Ew.1D Ew.1C Ew.
6 PARAMETER SETTING MELSEC-ST 6.1.4 Word input/output points of intelligent function modules To the intelligent function module, both the Wr Word input area and Ww Word output area are assigned in the standard setting. To make effective use of these two areas, only the Wr.n Word inputs or Ww.n Word outputs can be assigned. (1) Changing the word input/output points of intelligent function module (a) Intelligent function module not using Ww.
6 PARAMETER SETTING (a) MELSEC-ST Example where the used word input/output points exceed 32 words though it is desired to set the maximum input/output points to the 256-point mode.
6 PARAMETER SETTING (b) MELSEC-ST Example of changing the word input/output points in system configuration example in (a) 1) System configuration example ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1DA2-V(without Wr) ST1PSD ST1AD2-V(without Ww) ST1AD2-V(without Ww) ST1AD2-V(without W
6 PARAMETER SETTING MELSEC-ST 6.2 User Parameters The following table describes the user parameters to be set by the configuration software of the master station. For the user parameters of each slice module, refer to the relevant manual. Item Description Reference section Enter the FDL address of the head module. FDL address Section 5.3.1 [Setting range] 0 to 99 Set the watchdog time.
7 PROGRAMMING MELSEC-ST 7 PROGRAMMING This chapter explains program examples available when the QJ71PB92D and AJ71PB92D/A1SJ71PB92D are used as the master station. REMARK Refer to the following manuals for details of the QJ71PB92D and AJ71PB92D/A1SJ71PB92D. PROFIBUS-DP Interface Module User's Manual SH-080127 (13JR22) PROFIBUS-DP Interface Module type AJ71PB92D/A1SJ71PB92D User's Manual IB-66773 (13JL20) 7.
7 PROGRAMMING MELSEC-ST (2) System configuration of MELSEC-ST system The following system configuration is used as the MELSEC-ST system for explanation. (a) System configuration of slave station (MELSEC-ST system) 1) FDL address: 1 ON 1 2 3 4 5 6 7 8 ON 80 40 20 10 8 4 N 2 O. 1 S T A T I O N : ON : OFF 2) Maximum input/output points: 32-point mode No.0 No.1 No.2 No.3 No.4 No.5 No.6 7 The following table uses the maximum input/output points setting sheet given in Appendix 2.1.
7 PROGRAMMING MELSEC-ST (b) GX Configurator-DP setting (3) I/O data assignment The following shows the I/O data assignment result in the system configuration example given in (2) in this section. (a) Input data Buffer memory address Decimal (Hexadecimal) b15 Br.0F Br.0E Br.1F Br.1E Er.0F Er.0E Er.1F Er.1E Mr.15 Mr.14 Br.0D Br.0C Br.0B Br.0A Br.1D Br.1C Br.1B Br.1A Er.0D Er.0C Er.0B Er.0A Er.1D Er.1C Er.1B Er.1A Mr.13 Mr.12 Mr.11 Mr.10 Br.09 b8 b7 Br.08 Br.07 b0 Br.
7 PROGRAMMING MELSEC-ST (b) Output data Buffer memory address Decimal (Hexadecimal) b15 b8 Bw.0F Bw.0E Bw.0D Bw.0C Bw.0B Bw.0A Bw.09 b7 b0 Bw.08 Bw.07 Bw.06 Bw.05 Bw.04 Bw.03 Bw.02 Bw.01 Bw.00 960(3C0H) No.5 No.3 No.4 Bw.1F Bw.1E Bw.1D Bw.1C Bw.1B Bw.1A Bw.19 No.2 No.1 No.0 Bw.18 Bw.17 Bw.16 Bw.15 Bw.14 Bw.13 Bw.12 Ew.08 Ew.07 Ew.06 Ew.05 Ew.04 Ew.03 Ew.02 Bw.11 Bw.10 Bw Bit output area 961(3C1H) 0 No.6 Ew.0F Ew.0E Ew.0D Ew.0C Ew.0B Ew.0A Ew.09 Ew.01 Ew.
7 PROGRAMMING MELSEC-ST (4) Device assignment in program examples The program examples in Section 7.1.1 and 7.1.2 use the following device assignment.
7 PROGRAMMING MELSEC-ST (c) Devices used by I/O data 1) Br Bit Input Area Br.n Bit Input Information Master Station Side Device Br.00 Module READY D0.0 Br.01 Forced output test mode D0.1 Br.02 Module being changed online D0.2 Br.03 Command execution D0.3 Br.04 Br.05 D0.4 External power supply status D0.5 Br.06 Input status (first point) D0.6 Br.07 Input status (second point) D0.7 Br.08 System Area (0 fixed) D0.8 Br.09 System Area (0 fixed) D0.9 Br.0A Br.0B D0.
7 PROGRAMMING MELSEC-ST 2) Er.n Error Information Er Error Information Area Information Master Station Side Device Er.00 D2.0 Er.01 D2.1 Er.02 Head module error information D2.2 Er.03 Bus refreshing module error D2.4 Er.05 information D2.5 Er.07 Er.08 Er.09 D2.6 Module error information D2.8 Module error information D2.9 Power feeding module error D2.A Er.0B information D2.B Er.0D Er.0E Er.0F Er.10 Er.11 Er.12 Er.
7 PROGRAMMING MELSEC-ST 3) Mr.n Module Status Mr.0 Mr.1 Mr Module Status Area Information Master Station Side Device Slice No. D4.0 0 D4.1 1 Head module status Module Name ST1H-PB Mr.2 Bus refreshing module status D4.2 2 ST1PSD Mr.3 ST1X2-DE1 module status D4.3 3 ST1X2-DE1 Mr.4 ST1Y2-TE2 module status D4.4 4 ST1Y2-TE2 Mr.5 Power feeding module status D4.5 5 ST1PDD D4.6 6 D4.7 7 D4.8 8 D4.9 9 Mr.6 Mr.7 Mr.8 Mr.9 ST1AD2-V module status ST1DA2-V module status Mr.
7 PROGRAMMING MELSEC-ST 6) Bw.n Bit Output Bw Bit Output Area Information Master Station Side Device Bw.00 System Area (0 fixed) D1000.0 Bw.01 System Area (0 fixed) D1000.1 Bw.02 System Area (0 fixed) D1000.2 Bw.03 Command request D1000.3 Bw.04 System Area (0 fixed) D1000.4 Bw.05 System Area (0 fixed) D1000.5 Bw.06 System Area (0 fixed) D1000.6 Bw.07 System Area (0 fixed) D1000.7 Bw.08 Output status (first point) D1000.8 Bw.09 Output status (second point) D1000.9 Bw.
7 PROGRAMMING MELSEC-ST 7) Ew.n Error Clear Ew Error Clear Area Information Master Station Side Device Ew.00 Error Clear Request D1002.0 Ew.01 System Area (0 fixed) D1002.1 Ew.02 System Area (0 fixed) D1002.2 Ew.03 System Area (0 fixed) D1002.3 Ew.04 Error Clear Request D1002.4 Ew.05 System Area (0 fixed) D1002.5 Ew.06 Error Clear Request D1002.6 Ew.07 System Area (0 fixed) D1002.7 Ew.08 Error Clear Request D1002.8 Ew.09 System Area (0 fixed) D1002.9 Ew.
7 PROGRAMMING MELSEC-ST 10) Ww.n Word Output Ww Word Output Area Information Master Station Side Device Ww.00 System Area (0 fixed) D1009 Ww.01 System Area (0 fixed) D1010 Ww.02 Ww.03 7 - 11 CH1 digital value setting ( Ww.n ) CH2 digital value setting ( Ww.n+1 ) Slice No.
7 PROGRAMMING MELSEC-ST 7.1.1 Program example available when auto refresh is used in QJ71PB92D This section explains a program example available when auto refresh is used in the QJ71PB92D to communicate with the MELSEC-ST system. The program example in this section is based on the system configuration in Section 7.1. The command parameters of the ST1AD2-V and ST1DA2-V are assumed to have already been written. (1) Auto refresh setting To use auto refresh, setting must be made on GX Configurator-DP.
7 PROGRAMMING MELSEC-ST (a) Control program examples for slice modules 1) Program example for input module (ST1X2-DE1) and output module (ST1Y2-TE2) Br.00 Er.04 Mr.3 Er.06 Er.07 Br.06 Br.07 Mr.4 Er.08 Er.09 Input processing from ST1X2DE1 first input point Input processing from ST1X2DE1 second input point Bw.08 Output processing to ST1Y2-TE2 first output point Bw.
7 PROGRAMMING MELSEC-ST (b) Program example used when modules result in errors Error handling Br.00 ST1H-PB error handling start Er.00 Er.01 Er.02 Er.03 Er.04 ST1PSD external AUX. power supply error handling start Er.06 ST1X2-DE1 error handling start Er.07 ST1Y2-TE2 error handling start Er.08 Er.09 ST1PDD external AUX. power supply error handling start Er.0A Br.0C ST1AD2-V error handling start Er.0D Er.0F ST1AD2-V CH1 warning handling Er.0D Er.
7 PROGRAMMING MELSEC-ST Error code read Execution of command (error code read request) Br.00 Bw.03 Executes command to ST1H-PB. Br.03 Executes command to ST1PSD. Executes command to ST1X2-DE1. Executes command to ST1Y2-TE2. Cw.1 Command No. to be Executed (0101H) Cw.2 Argument 1 Cw.3 Argument 2 Bw.03 Turns ON Bw.03 Command Execution Request. Executes command to ST1PDD. Executes command to ST1AD2-V. Executes command to ST1DA2-V.
7 PROGRAMMING MELSEC-ST Br.03 Processing performed when command execution result is abnormally terminated Bw.03 Turns off Bw.03 Command request. Ends command execution.
7 PROGRAMMING MELSEC-ST (c) Error clear program for modules ST1H-PB error clear request ST1H-PB error clear request start Er.00 Ew.00 Turns ON ST1H-PB Ew.00 Error Clear Request. Er.01 Er.02 Er.03 Er.00 Er.01 Er.02 ST1H-PB error clear request end Er.03 ST1PSD error clear request ST1PSD error clear request start Er.04 Ew.04 Turns ON ST1PSD Ew.04 Error Clear Request. Er.05 Er.04 ST1PSD error clear request end Er.05 ST1X2-DE1 error clear request ST1X2-DE1 error clear request start Er.
7 PROGRAMMING MELSEC-ST ST1AD2-V error clear request ST1AD2-V error clear request start Er.0D Ew.0C Turns ON ST1AD2-V Ew.0C Error Clear Request. Er.0F Er.0D ST1AD2-V error clear request end Er.0F ST1DA2-V error clear request ST1DA2-V error clear request start Er.11 Ew.10 Turns ON ST1DA2-V Ew.10 Error Clear Request. Er.13 Er.11 7 - 18 Er.
7 PROGRAMMING MELSEC-ST 7.1.2 Program example available when auto refresh is not used in QJ71PB92D This section explains a program example available when auto refresh is not used in the QJ71PB92D to communicate with the MELSEC-ST system. The program example in this section is based on the system configuration in Section 7.1. The command parameters of the ST1AD2-V and ST1DA2-V are assumed to have already been written. Writes initial output data of FDL address 1.
7 PROGRAMMING MELSEC-ST 7.2 When Using AJ71PB92D/A1SJ71PB92D as Master Station This section explains a program example available when the AJ71PB92D/A1SJ71PB92D is used as the master station. This section provides the program example available when the A1SJ71PB92D is used as the master station. The command parameters of the ST1AD2-V and ST1DA2-V are assumed to have already been written.
7 PROGRAMMING MELSEC-ST (4) Device assignment in program example The program example in this section uses the following device assignment.
7 PROGRAMMING MELSEC-ST (c) Devices used by I/O data 1) Br Bit Input Area Br.n Bit Input Information Master Station Side Device Br.00 Module READY B0 Br.01 Forced output test mode B1 Br.02 Module being changed online B2 Br.03 Command execution B3 Br.04 Br.05 B4 External power supply status B5 Br.06 Input status (first point) B6 Br.07 Input status (second point) B7 Br.08 System Area (0 fixed) B8 Br.09 System Area (0 fixed) B9 Br.0A Br.0B BA External AUX.
7 PROGRAMMING MELSEC-ST 2) Er.n Error Information Er Error Information Area Information Master Station Side Device Er.00 B20 Er.01 B21 Er.02 Head module error information B22 Er.03 Bus refreshing module error B24 Er.05 information B25 Er.07 Er.08 Er.09 B26 Module error information B28 Module error information B29 Power feeding module error B2A Er.0B information B2B Er.0D Er.0E Er.0F Er.10 Er.11 Er.12 Er.13 0 ST1H-PB 1 2 ST1PSD 3 ST1X2-DE1 4 ST1Y2-TE2 5 ST1PDD B27 Er.
7 PROGRAMMING MELSEC-ST 3) Mr.n Module Status Mr.0 Mr.1 Mr Module Status Area Information Master Station Side Device Slice No. B40 0 B41 1 Head module status Module Name ST1H-PB Mr.2 Bus refreshing module status B42 2 ST1PSD Mr.3 ST1X2-DE1 module status B43 3 ST1X2-DE1 Mr.4 ST1Y2-TE2 module status B44 4 ST1Y2-TE2 Mr.5 Power feeding module status B45 5 ST1PDD B46 6 B47 7 B48 8 B49 9 Mr.6 Mr.7 Mr.8 Mr.9 ST1AD2-V module status ST1DA2-V module status Mr.
7 PROGRAMMING MELSEC-ST 6) Bw.n Bit Output Bw Bit Output Area Information Master Station Side Device Bw.00 System Area (0 fixed) B1000 Bw.01 System Area (0 fixed) B1001 Bw.02 System Area (0 fixed) B1002 Bw.03 Command request B1003 Bw.04 System Area (0 fixed) B1004 Bw.05 System Area (0 fixed) B1005 Bw.06 System Area (0 fixed) B1006 Bw.07 System Area (0 fixed) B1007 Bw.08 Output status (first point) B1008 Bw.09 Output status (second point) B1009 Bw.
7 PROGRAMMING MELSEC-ST 7) Ew.n Error Clear Ew Error Clear Area Information Master Station Side Device Ew.00 Error Clear Request B1020 Ew.01 System Area (0 fixed) B1021 Ew.02 System Area (0 fixed) B1022 Ew.03 System Area (0 fixed) B1023 Ew.04 Error Clear Request B1024 Ew.05 System Area (0 fixed) B1025 Ew.06 Error Clear Request B1026 Ew.07 System Area (0 fixed) B1027 Ew.08 Error Clear Request B1028 Ew.09 System Area (0 fixed) B1029 Ew.0A Error Clear Request B102A Ew.
7 PROGRAMMING MELSEC-ST 10) Ww.n Word Output Ww Word Output Area Information Master Station Side Device Ww.00 System Area (0 fixed) W1004 Ww.01 System Area (0 fixed) W1005 Ww.02 Ww.03 CH1 digital value setting ( Ww.n ) CH2 digital value setting ( Ww.n+1 ) Slice No. Module Name 6 ST1AD2-V 8 ST1DA2-V W1006 W1007 (5) Program example Writes initial output data of FDL address 1.
7 PROGRAMMING MELSEC-ST (a) Control program examples for slice modules 1) Program example for input module (ST1X2-DE1) and output module (ST1Y2-TE2) Br.00 Er.04 Mr.3 Er.06 Er.07 Br.06 Br.07 Mr.4 Er.08 Input processing from ST1X2-DE1 first input point Input processing from ST1X2-DE1 second input point Bw.08 Er.09 Bw.
7 PROGRAMMING MELSEC-ST (b) Program example used when modules result in errors Error handling Br.00 ST1H-PB error handling start Er.00 Er.01 Er.02 Er.03 ST1PSD external AUX. power supply error handling start Er.04 ST1X2-DE1 error handling start Er.06 Er.07 ST1Y2-TE2 error handling start Er.08 Er.09 ST1PDD external AUX. power supply error handling start ST1AD2-V error handling start Er.0A Br.0C Er.0D Er.0F ST1AD2-V CH1 warning handling Er.0D Er.
7 PROGRAMMING MELSEC-ST Error code read Execution of command (error code read request) Br.00 Bw.03 Executes command to ST1H-PB. Br.03 Executes command to ST1PSD. Executes command to ST1X2-DE1. Executes command to ST1Y2-TE2. Cw.1 Command No. to be Executed (0101H) Cw.2 Argument 1 Cw.3 Argument 2 Bw.03 Turns ON Bw.03 Command Execution Request. Executes command to ST1PDD. Executes command to ST1AD2-V. Executes command to ST1DA2-V.
7 PROGRAMMING MELSEC-ST Br.03 Processing performed when command execution result is abnormally terminated Bw.03 Turns off Bw.03 Command request. Ends command execution.
7 PROGRAMMING MELSEC-ST (c) Error clear program for modules ST1H-PB error clear request ST1H-PB error clear request start Er.00 Ew.00 Turns ON ST1H-PB Ew.00 Error Clear Request. Er.01 Er.02 Er.03 Er.00 Er.01 Er.02 ST1H-PB error clear request end Er.03 ST1PSD error clear request ST1PSD error clear request start Er.04 Ew.04 Turns ON ST1PSD Ew.04 Error Clear Request. Er.05 Er.04 ST1PSD error clear request end Er.05 ST1X2-DE1 error clear request ST1X2-DE1 error clear request start Er.
7 PROGRAMMING MELSEC-ST ST1PDD error clear request ST1PDD error clear request start Ew.0A Er.0A Turns ON ST1PDD Ew.0A Error Clear Request. Er.0B Er.0A ST1PDD error clear request end Er.0B ST1AD2-V error clear request ST1AD2-V error clear request start Ew.0C Er.0D Turns ON ST1AD2-V Ew.0C Error Clear Request. Er.0F Er.0D ST1AD2-V error clear request end Er.0F ST1DA2-V error clear request ST1DA2-V error clear request start Er.11 Ew.10 Turns ON ST1DA2-V Ew.10 Error Clear Request. Er.
8 COMMANDS MELSEC-ST 8 COMMANDS This chapter explains the commands executed in the head module and slice modules. 8.1 Command Overview By sending a command from the master station to the head module, the operating status or error code of the head module can be read and the command parameters of the intelligent function module can be set. (1) Procedure for using command Use a command in the following procedure. 1) Before executing a command, check that the Br.
8 COMMANDS MELSEC-ST ON Br.00 Module READY 1) Check whether Br.00 Module READY of head module is on. OFF 1) Check whether Br.n Module READY of execution ON target slice module is on. Confirmation of Br.n OFF Operating status of execution target slice module Cw Command execution area 2) Set command information. 7) After confirming command result, turn off Bw.03 OFF Command request. ON Bw.03 Command request OFF 3) Turn on Bw.03 Command request. 6) Read command result. 4) Command is executed.
8 COMMANDS MELSEC-ST (2) Precautions for command execution (a) (b) (c) When the head module is in the self-diagnostics operation mode, the command cannot be executed for the corresponding module. When a slice module is being replaced online (when the REL. LED is on), the command cannot be executed for the slice module. While a command is being executed, other command is not executable. Also, a command can be executed for only one module.
8 COMMANDS MELSEC-ST 8.2 Commands This section explains the commands for the head module, power distribution module and I/O modules. (1) Command list The following table lists the commands that can be sent from the master station. Command No. Command name/classification Operating status read request 0100H Description Target module Reference section Head module Bus refreshing module Power feeding module Reads the operating status of the head module and each slice module.
8 COMMANDS MELSEC-ST (2) How to use the manual The following shows how to use the manual between Section 8.2.1 and Section 8.2.3. (1) Values set to Cw Command execution area Explains the values set to the Cw Command execution area for executing command. (2) Execution result of Cr Command result area Explains the values stored into the Cr Command result area after execution of the command.
8 COMMANDS MELSEC-ST 8.2.1 Operating status read request (Command No.: 0100H) Reads the operating status of the head module, power distribution module or I/O module. (1) Values set to Cw Command execution area The same values must be writhen for the head module, power distribution module or I/O module except for Cw.0 . Cw Command execution area Set value Cw.0 Set the start slice No. of the module for which the command will be executed. (Hexadecimal) Cw.1 0100H Cw.2 Cw.
8 COMMANDS MELSEC-ST (2) Execution result of Cr Command result area The command result area status differs depending on the result (normally terminated or abnormally terminated) in the Cr.0(15-8) Command Execution Result. (a) When the command is executed for the head module 1) When the command is normally terminated (When Cr.0(15-8) Command execution result is 00H) Cr Command result area Result Stores the command execution result into the high byte, and the start slice No.
8 COMMANDS MELSEC-ST (b) When the command is executed for the power distribution module or I/O module 1) When the command is normally terminated (When Cr.0(15-8) Command execution result is 00H) Cr Command result area Result Stores the command execution result into the high byte, and the start slice No. of execution target into the low byte in hexadecimal as shown below. b15 Cr.0 to b8 b7 to b0 Cr.0(15-8) Command execution result Cr.0(7-0) Start slice No.
8 COMMANDS MELSEC-ST Cr Command result area Result Stores the user parameter settings of the slice module for which the command was executed. b15 to b3 b2 0 to b0 1) 1) Filter constant 0H: 1.5ms 1H: 0.5ms Cr.3 b15 to b4 0 b3 b2 b1 b0 1) 1 1 1 1) Output status Clear/Hold setting 0: CLEAR 1: HOLD b15 to b0 0 2) When the command is abnormally terminated (When Cr.
8 COMMANDS MELSEC-ST 8.2.2 Error code read request (Command No.: 0101H) Reads the error code of the head module, power distribution module or I/O module. (1) Values set to Cw Command execution area The same values must be written for the head module, power distribution module or I/O module except for Cw.0 . Cw Command execution area Set value Cw.0 Set the start slice No. of the module for which the command will be executed. (Hexadecimal) Cw.1 0101H Cw.2 Cw.
8 COMMANDS MELSEC-ST (2) Execution result of Cr Command result area The command result area status differs depending on the result (normally terminated or abnormally terminated) in the Cr.0(15-8) Command Execution Result. (a) When the command is executed for the head module 1) When the command is normally terminated (When Cr.0(15-8) Command execution result is 00H) Cr Command result area Result Stores the command execution result into the high byte, and the start slice No.
8 COMMANDS MELSEC-ST (b) When the command is executed for the power distribution module or I/O module 1) When the command is normally terminated (When Cr.0(15-8) Command execution result is 00H) Cr Command result area Result Stores the command execution result into the high byte, and the start slice No. of execution target into the low byte in hexadecimal as shown below. b15 Cr.0 to b8 b7 to b0 Cr.0(15-8) Command execution result Cr.0(7-0) Start slice No.
8 COMMANDS MELSEC-ST 2) When the command is abnormally terminated (When Cr.0(15-8) Command execution result is other than 00H) Cr Command result area Result Stores the command execution result into the high byte, and the start slice No. of execution target into the low byte in hexadecimal as shown below. b15 Cr.0 to b8 b7 Cr.0(15-8) Command execution result to b0 Cr.0(7-0) Start slice No. of execution target 1 Other than 00H : Abnormally terminated (Refer to Section 8.
8 COMMANDS MELSEC-ST 8.2.3 Error history read request (Command No.: 0102H) Reads the error history of the head module. (1) Values set to Cw Command execution area Cw Command execution area Set value Cw.0 Set the start slice No. (0000H) of the head module. (Hexadecimal) Cw.1 0102H Cw.2 0000 H fixed (Entry of any other value will result in an error.) Cw.
8 COMMANDS MELSEC-ST 8.3 Program Examples Program examples for commands are shown here. The program example in this section is based on the system configuration in Section 7.1. In this program example, the operation status read request (command No.: 0100H) is executed for the head module (start slice No.: 0) without use of auto refresh in the QJ71PB92D. (1) Device assignment in program example The program example in this section uses the following device assignment.
8 COMMANDS MELSEC-ST (2) Program example PROFIBUS-DP exchange start processing (Refer to Section 7.1.2) Read from input area (Refer to Section 7.1.2) Command execution start Br.00 Bw.03 Cw.0 Start Slice No. of Execution Target Br.03 Cw.1 Command No. to be Executed Cw.2 Argument 1 Cw.3 Argument 2 Bw.03 Br .03 Bw.03 Command Execution Request ON Processing performed when command execution result is Normally terminated Processing performed when command execution result is Abnormally terminated Bw.
8 COMMANDS MELSEC-ST 8.4 Values Stored into Command Execution Result The following table describes the values stored into the Cr.0(15-8) Command execution result of the Cr Command result area. Cr.0(15-8) Command Description execution result 00H Normally terminated 01H The requested command is not available for the specified module. 02H 03H The value set in Cw.2 Argument 1 or Cw.3 Argument 2 is outside the range. The Cw.0 Start Slice No. of Execution Target is wrong.
8 COMMANDS MELSEC-ST MEMO 8 - 18 8 - 18
9 TROUBLESHOOTING MELSEC-ST 9 TROUBLESHOOTING This chapter explains corrective actions to be taken and the error codes displayed when problems occur in the head module. Before starting the troubleshooting in any of Section 9.1 to 9.3, check whether the MELSEC-ST system is configured correctly. The following provides the items for checking whether the MELSEC-ST system is configured correctly. (1) Check that a proper number of slice modules are mounted.
9 TROUBLESHOOTING MELSEC-ST 9.1 When I/O data cannot be communicated When I/O data cannot be communicated between the master station and MELSEC-ST system, troubleshoot the problem according to the following flowchart. I/O data cannot be communicated Is the MELSEC-ST system configured correctly? No Refer to Chapter 9. Yes Are the SYS. LEDs and AUX. LEDs of all power distribution modules on? No Switch on the external power supplies of all power distribution modules.
9 TROUBLESHOOTING MELSEC-ST 1) Is the ERR. LED of the head module off? No Refer to Section 9.2. Yes Are correct input data sent to the master station? No Refer to Section 9.1.3. No Refer to Section 9.1.4.
9 TROUBLESHOOTING MELSEC-ST 9.1.1 When RUN LED is off When the RUN LED of the head module is off, troubleshoot the problem according to the following flowchart. RUN LED is off Are the FDL address setting switches set to the FDL address (0 to 99) of the slave station? No Set the FDL address setting switches to the FDL address (0 to 99) of the slave station. Yes Are the SYS. LEDs and AUX.
9 TROUBLESHOOTING MELSEC-ST 9.1.2 When BF LED is on When the BF LED of the head module is on, troubleshoot the problem according to the following flowchart. BF LED is on Are the slave parameter and FDL address setting switches set to the same FDL address? No Set the slave parameter and FDL address setting switches to the same FDL address. (Refer to Section 5.3 and Section 6.2.
9 TROUBLESHOOTING MELSEC-ST 9.1.3 When input data is erroneous When the input data sent from the head module is erroneous, troubleshoot the problem according to the following flowchart. Input data is erroneous Is the slice module operating normally? No Refer to the manual of the corresponding slice module. Yes Is the FRE. LED of the head module off? No Cancel (UNFREEZE) the FREEZE service of the global control function. (Refer to Section 4.2.2.
9 TROUBLESHOOTING MELSEC-ST 9.1.4 When output data is erroneous When the output data received by the head module is erroneous, troubleshoot the problem according to the following flowchart. Output data is erroneous Is the slice module operating normally? No Refer to the manual of the corresponding slice module. Yes Is the SYN. LED of the head module off? No Cancel (UNSYNC) the SYNC service of the global control function. (Refer to Section 4.2.2.
9 TROUBLESHOOTING MELSEC-ST 9.2 When ERR. LED is on or flickering When an error occurs in the head module, the ERR. LED turns on or flickers. This section explains the read operation of the error code of the head module and lists the error codes. 9.2.1 Error code reading operation This section explains the operation to read the error code. Refer to Section 9.2.2 for details of the error code.
9 TROUBLESHOOTING MELSEC-ST (d) Using GX Configurator-ST for checking Connect the personal computer to the head module, and confirm the operating status and error code of each module from GX Configurator-ST. Check the operating status and error code of each module on the "System Monitor" and "Module Detail Information" screens of GX Configurator-ST. Refer to the GX Configurator-ST Manual for the operation on the "System Monitor" and "Module Detail Information" screens.
9 TROUBLESHOOTING MELSEC-ST 9.2.2 Error code list The following gives the error code list of the head module. Refer to Section 9.2.1 for the error code reading operation. (1) Error code list (a) Error codes for PROFIBUS-DP communication If any of the following errors occurs during online module change, the ERR. LED status change and error code are not recorded. Error code (Hexadecimal) B100H Error Level Warning Error name ERR.
9 TROUBLESHOOTING Error code (Hexadecimal) MELSEC-ST Reading operation 1) 2) 3) 4) Corrective action B100H Check whether the FDL address setting switches are set within the range 0 to 99. (Refer to Section 5.3.1.) B101H Hardware fault. Replace the head module. Please consult your local Mitsubishi representative, explaining a detailed description of the problem. B200H Check the watchdog time setting. (Refer to Section 6.2.) B300H Check the slave parameters of the head module. (Refer to Chapter 6.
9 TROUBLESHOOTING MELSEC-ST (b) Operating status code and error codes for online module change Error/Operating status code (Hexadecimal) Error Level C001H to C03FH 1 C101H to C13FH System 1 error C201H to C23FH System 1 error Error name ERR. LED status (Normal) Online module change error Online module change error On 2 On Detection timing Description When online module change starts (when REL.
9 TROUBLESHOOTING Error/Operating status code (Hexadecimal) C001H to C03FH C101H to C13FH C201H to C23FH MELSEC-ST Reading operation Corrective action 1 1) 2) 3) 4) Complete online module change. (Refer to Section 4.4.) 1 After online module change, write the parameters to the intelligent function module using a command or GX Configurator-ST, with the RUN LED of the currently mounted module flickering or on.
9 TROUBLESHOOTING MELSEC-ST (2) When multiple errors are detected simultaneously When the head module detects multiple errors simultaneously, error information is stored with the following priority.
9 TROUBLESHOOTING MELSEC-ST 9.3 When command cannot be executed When the command from the master station cannot be executed, troubleshoot the problem according to the following flowchart. Command cannot be executed Is I/O data communication executed? No Refer to Section 9.1. Yes Is the RUN LED of the execution target slice module on? No Take corrective action for the case where the RUN LED is off. Refer to the manual of the slice module. Yes Is Bw.03 Command request on? No Turn on Bw.
9 TROUBLESHOOTING MELSEC-ST 1) Does the master station support the consistency of the whole output data? No Set the consistency function of the head module to "Enable", and execute the command. No Please consult your local Mitsubishi representative, explaining a detailed description of the problem. Yes After the command is executed, is Br.
APPENDICES MELSEC-ST APPENDICES Appendix 1 External Dimensions 69.0(2.72) 2.5(0.10) 26.5(1.04) 31.0(1.22) (1) Head module (ST1H-PB) RELEASE 114.5(4.51) RESET 7.0 (0.28) PROFIBUS I/F App 14.5 (0.57) 50.5(1.99) App - 1 67.5(2.66) 74.5(2.93) (Unit: mm(in.
APPENDICES MELSEC-ST (2) End plate (ST1A-EPL) 1 48.5(1.91) 9.0 (0.35) 114.5(4.51) 69.0(2.72) 41.5(1.63) (Unit: mm(in.)) 4.5(0.18) 1. In the above drawing, the end bracket is mounted on the end plate. 28.0(1.10) 56.0(2.20) 28.0(1.10) (3) End bracket (ST1A-EBR) 8.0 (0.31) 46.5(1.83) (Unit: mm(in.
APPENDICES MELSEC-ST Appendix 2 MELSEC-ST System Setting Sheet Appendix 2.1 Maximum input/output points setting sheet No. Module Name Number of Start Slice No. Occupied I/O (Number of Points occupied slices) 0 ST1H-PB 4 0(2) 1 ST1PSD 2 2(1) 2 ( ) 3 ( ) 4 ( ) 5 ( ) 6 ( ) 7 ( ) 8 ( ) 9 ( ) 10 ( ) 11 ( ) 12 ( ) 13 ( ) 14 ( ) 15 ( ) 16 ( ) 17 ( ) 18 ( ) 19 ( ) 20 ( ) 21 ( ) 22 ( ) 23 ( ) 24 ( ) Total 1 Ww.n Wr.
APPENDICES MELSEC-ST Appendix 2.2 Input data assignment sheet (1) Br.n Bit input Br Bit input area Information Br.00 Module READY Br.01 Forced output test mode Br.02 Module being changed online Br.03 Command execution Br.04 Br.05 Br.06 Br.07 Br.08 Br.09 Br.0A Br.0B Br.0C Br.0D Br.0E Br.0F External power supply status Master station side device Slice No.
APPENDICES Br.n Bit input Br. 0 Br. 1 Br. 2 Br. 3 Br. 4 Br. 5 Br. 6 Br. 7 Br. 8 Br. 9 Br. A Br. B Br. C Br. D Br. E Br. F App - 5 MELSEC-ST Information Master station side device Slice No.
APPENDICES MELSEC-ST (2) Er.n Error information Er Error information area Information Er.00 Head module error Er.02 information Er.04 Bus refreshing module error Er.05 information Er.08 Er.09 Er.0A Er.0B Er.0C Er.0D Er.0E Er.0F Module name ST1H-PB 1 Er.03 Er.07 Slice No. 0 Er.01 Er.
APPENDICES Er.n Error information Er. 0 Er. 1 Er. 2 Er. 3 Er. 4 Er. 5 Er. 6 Er. 7 Er. 8 Er. 9 Er. A Er. B Er. C Er. D Er. E Er. F App - 7 MELSEC-ST Information Master station side device Slice No.
APPENDICES MELSEC-ST (3) Mr.n Module status Mr. 0 Mr Module status area Information Master station side device 0 Head module status Mr. 1 Slice No. ST1H-PB 1 Mr. 2 Bus refreshing module status 2 Mr. 3 3 Mr. 4 4 Mr. 5 5 Mr. 6 6 Mr. 7 7 Mr. 8 8 Mr. 9 9 Mr.10 10 Mr.11 11 Mr.12 12 Mr.13 13 Mr.14 14 Mr.15 15 Mr.n Module status Mr. 0 Mr. 1 Mr. 2 Mr. 3 Mr. 4 Mr. 5 Mr. 6 Mr. 7 Mr. 8 Mr.
APPENDICES MELSEC-ST (4) Wr.n Word input Wr. 0 Wr. 1 Wr. 2 Wr. 3 Wr. 4 Wr. 5 Wr. 6 Wr. 7 Wr. 8 Wr. 9 Wr. A Wr. B Wr. C Wr. D Wr. E Wr. F App - 9 Wr Word input area Information Master station side device Slice No.
APPENDICES MELSEC-ST Appendix 2.3 Output data assignment sheet (1) Bw.n Bit output Bw Bit output area Information Bw.00 System area (0 fixed) Bw.01 System area (0 fixed) Bw.02 System area (0 fixed) Bw.03 Command request Bw.04 System area (0 fixed) Bw.05 System area (0 fixed) Bw.06 Bw.07 Bw.08 Bw.09 Bw.0A Bw.0B Bw.0C Bw.0D Bw.0E Bw.0F Master station side device Slice No.
APPENDICES Bw.n Bit output Bw. 0 Bw. 1 Bw. 2 Bw. 3 Bw. 4 Bw. 5 Bw. 6 Bw. 7 Bw. 8 Bw. 9 Bw. A Bw. B Bw. C Bw. D Bw. E Bw. F App - 11 MELSEC-ST Information Master station side device Slice No.
APPENDICES MELSEC-ST (2) Ew.n Error clear Ew Error clear area Information Ew. 00 Error clear request Ew. 01 System area (0 fixed) Ew. 02 System area (0 fixed) Ew. 03 System area (0 fixed) Ew. 04 Error clear request Ew. 05 System area (0 fixed) Ew. 06 Ew. 07 Ew. 08 Ew. 09 Ew.0A Ew.0B Ew.0C Ew.0D Ew.0E Ew.0F Master station side device Slice No.
APPENDICES Ew.n Error clear Ew. 0 Ew. 1 Ew. 2 Ew. 3 Ew. 4 Ew. 5 Ew. 6 Ew. 7 Ew. 8 Ew. 9 Ew. A Ew. B Ew. C Ew. D Ew. E Ew. F App - 13 MELSEC-ST Information Master station side device Slice No.
APPENDICES MELSEC-ST (3) Ww.n Word output Ww. 0 Ww. 1 Ww. 2 Ww. 3 Ww. 4 Ww. 5 Ww. 6 Ww. 7 Ww. 8 Ww. 9 Ww. A Ww. B Ww. C Ww. D Ww. E Ww. F App - 14 Ww Word output area Information Master station side device Slice No.
APPENDICES MELSEC-ST MEMO App - 15 App - 15
INDEX Ind [B] Bit Input Area......................................... 3- 8, 3-23 Bit Output Area..................................... 3-17, 3-25 Br ......................................................... 3- 8, 3-23 Bus terminator ............................................... 5-12 Bw ....................................................... 3-17, 3-25 [I] Input data ........................................................3- 5 Input transmission delay time........................
[U] UNFREEZE .................................................... 4- 5 UNSYNC ........................................................ 4- 5 Used word input/output points ....................... 6- 9 User parameter ............................................. 6-12 User parameter size....................................... 6- 4 Ind [W] Watchdog time .............................................. 6-12 Word Input Area ............................................ 3-11 Word Output Area ........................
WARRANTY Please confirm the following product warranty details before starting use. 1. Gratis Warranty Term and Gratis Warranty Range If any faults or defects (hereinafter "Failure") found to be the responsibility of Mitsubishi occurs during use of the product within the gratis warranty term, the product shall be repaired at no cost via the dealer or Mitsubishi Service Company.
MITSUBISHI ELECTRIC HEADQUARTERS EUROPEAN REPRESENTATIVES EUROPEAN REPRESENTATIVES EUROPEAN REPRESENTATIVES MITSUBISHI ELECTRIC EUROPE EUROPE B.V. German Branch Gothaer Straße 8 D-40880 Ratingen Phone: +49 (0)2102 486-0 Fax: +49 (0)2102 486-1120 e mail: megfamail@meg.mee.com MITSUBISHI ELECTRIC FRANCE EUROPE B.V. French Branch 25, Boulevard des Bouvets F-92741 Nanterre Cedex Phone: +33 1 55 68 55 68 Fax: +33 1 55 68 56 85 e mail: factory.automation@fra.mee.com MITSUBISHI ELECTRIC IRELAND EUROPE B.V.
