Mr. Slim® Split-ductless Systems: Redefining Comfort Comfort is a concept many of us notice only when we’re either uncomfortable or very relaxed. But at Mitsubishi Electric HVAC Advanced Products Division, all we think about is comfort. Our industry-leading Mr. Slim split-ductless cooling and heating systems reflect this thinking. At home or at work our Mr. Slim systems are designed to make any space inviting and comfortable. Maybe your home has a room that’s always too hot or too cold.
Good for the environment and your bottom line. • Eco-friendly refrigerant: Environmentally-friendly R410A refrigerant offers zero Ozone Depletion Potential (ODP) and allows for higher heat transfer coefficient (COP). This innovative feature means a reduction in equipment size, a reduction in piping size and higher pressure for greater performance. Smaller equipment also means less impact on the environment at the end of the product’s life cycle.
Where Can Mr. Slim Products Be Used? Mr. Slim split-ductless systems are specifically designed to improve the comfort level in an uncomfortably hot or cold room of an existing building. Because Mr. Slim Systems do not require ductwork, they are the perfect cooling and heating systems for renovating older buildings – even those with plaster walls and brick facades that were constructed before air conditioning was available. The versatility and variety of applications for Mr.
G l o ss a r y INDEX Air conditioner: A mechanical device used to control temperature and air movement in a confined space. INVERTER TECHNOLOGY: Pages 06-07 M-Series: 9,000-36,000 Btu/h Btu/h (British Thermal Units per Hour): A measure of cooling or heating capacity. Residential and Select Commercial Applications Capacity or Load: A refrigeration rating system usually measured in Btu/h.
INVERTER INVERTER INVERTER-DRIVEN COMPRESSOR TECHNOLOGY Inverter Technology for Exceptional Year-round Comfort and Performance Certain straight-cool and all heat pump outdoor units use Mitsubishi Electric’s inverter-driven compressor technology (Variable Frequency Drive) to provide exceptional, high-speed cooling and heating performance. Thanks to high rotation speeds, desired temperatures are reached more quickly than with conventional systems so you can enjoy your ideal level of comfort without delay.
INVERTER Optimum Comfort Year-round Extra Energy Savings INVERTER-driven systems detect subtle changes in temperature and automatically adjust compressor speed unlike conventional units, which start and stop repetitively. Precise rotation speed efficiently maintains desired temperature, reducing temperature swings, and provides a more comfortable climate.
M-Series residential AND select commercial Comfort is a home that’s cool and dry in the summer and cozy and warm in the winter. This environment is what you get with the Mr. Slim system: perfect year-round comfort. The M-Series systems install easily. Mounted high on the wall, the indoor unit blends into most room environments without taking up any window space.
M -Seri es M SY(Z)-D30N A M o del Indoor U ni t Features Benefits INVERTER Technology Maximizes energy savings by making sure only the energy needed to cool or heat an area is used.
M-SERIES WALL-MOUNTED A/C LINEUP NEW Large Capacity (c ooling only ) M-S e ries Wireless Re m o te Con troller M S Non- INVER TER A ir Cond itione r s 9, 500 to 12, 000 B tu/ h [ p g. 12] Multiple Filters for Cleaner, Healthier Air Mr. Slim M-Series indoor units use a sophisticated multipart filter system to remove contaminants such as allergens, viruses and bacteria from the air as it circulates. The hybrid catechin filter absorbs odor-causing gases.
NEW Up to 23 SEER M-SERIES WALL-MOUNTED HEAT PUMP LINEUP (c ooling a n d h e a t i n g ) MSZ-FD 0 9 / 1 2 N A High- Ef f ic ie nc y INVERTER He a t P ump s 9,0 00 an d 12, 000 B tu/ h [pg. 14] M SZ I N V E RT E R H e a t Pu m p s 9, 00 0 t o 3 3 , 2 0 0 Bt u / h [pgs. 14 - 15] MX Z Mu l t i -Z o n e I N V E RT E R H e a t Pu m ps 2 0 , 0 0 0 t o 3 6 , 0 0 0 Bt u / h [pgs.
(MS-A12WA Model Shown) ms/msy COOLING-ONLY m-Series Specifications INVERTER Non-inverter Indoor Unit Outdoor Unit Model Name Cooling *1 Power Supply Voltage Indoor Unit MS-A09WA MU-A09WA MS-A12WA MU-A12WA Btu/h 9,500 12,000 15,000 16,200 Capacity Range Btu/h - - 3,100-15,000 3,100-16,200 1,070 1,690 (210-1,690) Total Input W Energy Efficiency SEER Moisture Removal Pints/h Sensible Heat Factor Phase, Cycle, Voltage Indoor - Outdoor L1 N / S1-S2 Indoor - Outdoor L2 / S2-S3 Indoor - Remo
INVERTER (MS-A12WA Model Shown) msy COOLING-ONLY (cont.) m-Series Specifications Indoor Unit Outdoor Unit Model Name Cooling *1 Power Supply Voltage Btu/h 22,000 30,700 34,600 Btu/h W SEER Pints/h 4,400-22,000 2,880 (290-2,880) 9,800-30,700 3,380 (620-3,380) 9,800-34,600 4,240 (620-4,240) 15.1 11.9 0.62 Sound Pressure Level (Lo-Med-Hi) *1 External Finish Color A F.L.A. DRY (CFM) WET (CFM) 16 7.3 0.63 9.9 0.
INVERTER (MSZ-FD12NA Model Shown) MSZ heat pump m-Series Specifications Indoor Unit Model Name Cooling *1 Heating at 47º F *2 Heating at 17º F *3 Power Supply Voltage Indoor Unit Outdoor Unit Rated Capacity Capacity Range Total Input Energy Efficiency Moisture Removal Sensible Heat Factor Rated Capacity Btu/h Btu/h W SEER Pints/h Capacity Range Btu/h Total Input HSPF (Region IV) Capacity Total Input Phase, Cycle, Voltage Indoor - Outdoor S1-S2 Indoor - Outdoor S2-S3 Indoor - Remote Controller M
INVERTER (MSY(Z)-D30NA Model Shown) MSZ heat pump (cont.) m-Series Specifications Indoor Unit Model Name Cooling *1 Heating at 47º F *2 Heating at 17º F *3 Power Supply Voltage Indoor Unit Outdoor Unit Refrigerant Pipe Connection Method MSZ-D30NA MUZ-D30NA MSZ-D36NA MUZ-D36NA 15,000 3,100-15,000 1,690 (210-1,690) 16,200 3,100-16,200 2,070 (210-2,070) 22,000 4,400-22,000 2,880 (290-2,880) 16 7.3 0.
MXZ-Multi INVERTER heat pump m-Series Specifications INVERTER (MSZ-A12NA Model Shown) Model Name Outdoor Unit Btu/h Btu/h W Btu/h Heating at 47º F *2 Capacity Range Total Input Capacity Heating at 17º F *3 Total Input Phase,Cycle,Voltage Indoor - Outdoor S1-S2 Indoor - Outdoor S2-S3 MCA MOCP Fan Motor Cooling *1 Indoor Unit Power Supply Voltage MXZ-2A20NA *5 MXZ-3A30NA *6 Rated Capacity Capacity Range Total Input Rated Capacity Airflow (Cooling/Heating) *1/*2 Refrigerant Control Outdoor Unit *4
MXZ-3A30 NA ( 3 : 1 , 2 : 1 ) Outdoor Uni t MXZ-2A20 NA (2:1) Outdoor Unit MXZ-2A20NA Combinations Current Indoor Unit Cooling Capacity (Btu/h) Power Energy (A) (Unit A + Unit B) Heating Capacity (Btu/h) Usage Efficiency Combinations Unit A Unit B Total (W) SEER HSPF 208V 230V MSZ-A09NA + MSZ-A09NA 9,000 10,900 9,000 10,900 18,000 21,800 1,740 1,820 MSZ-A09NA + MSZ-A12NA 8,500 11,500 20,000 2,150 9,500 12,500 22,000 1,780 MSZ-A09NA + MSZ-A15NA* 7,500 12,500 20,000 2,150 8,250 13,750 2
P-Series Commercial, institutional AND large residential The Mr. Slim P-Series delivers flexible and convenient cooling and heating solutions to almost any commercial, institutional or large residential application. Choose from small, quiet indoor and outdoor units that operate with the increased efficiency you need.
Features Benefits INVERTER Technology You can enjoy high-speed cooling and heating and consistent delivery of comfort year-round. Quiet operation You can hold a board meeting or teach a class in quiet comfort. No Ductwork There’s no need to shut down for major construction because installation is quick and easy. zone control ou can cool and heat only those spaces Y desired for maximum control and energy efficiency.
H2i TM HYPER-HEATING INVERTER P-Series HEAT PUMP SYSTEM 30,000 to 36,000 Btu/h Capacity Unequaled Year-round Comfort The cooling and heating success of Mitsubishi Electric’s INVERTER heat pump systems is well-documented. Our Hyper-Heating INVERTER (H2i) technology advances the process a step further with the added benefit of yearround comfort with a single system even on the coldest days of the year in most places.
(Figure 1) Sometimes cooling spaces such as computer or mechanical rooms and kitchens is necessary even when the temperature is below freezing. Air conditioning down to 0˚ F outdoor ambient temperature is possible with the addition of a wind baffle. Whether cooling or heating the H2i P-Series gives you the flexibility to temper extreme outdoor temperatures. Warm Air Quickly! At startup a special circuit quickly delivers refrigerant to the air-conditioning cycle.
Two in One If you have a large space such as a long room or hallway which would be considered one zone, two indoor units can be connected to the outdoor unit to cool or heat the space and provide the maximum amount of comfort. The process in which two indoor units act as one to spread the outdoor unit’s capacity over a large area is called Twinning.
INVERTER H2i Heat pump TM P-Series Specifications FA = Wired Controller; FAL = Wireless Controller Indoor Unit Model Name Outdoor Unit Rated Capacity Cooling *1 Heating at 47° F *2 Heating at 17° F *3 Heating at 5° F *4 Power Supply Voltage Btu/h PKA-A30FA(L) PUZ-HA30NHA 30,000 Capacity Range Total Input Btu/h W 18,000-30,000 2,730 Energy Efficiency Moisture Removal Sensible Heat Factor Rated Capacity Capacity Range Total Input HSPF (IV) Capacity Total Input Capacity Total Input Phase, Cycle, Vol
pkA (GA/GAL,fA/FAl) Wall-mounted series 12,000 to 34,200 Btu/h Capacity P K A Ind oor Unit (The same indoor unit is used for both cooling and heat pump systems.) The PKA-Series fills small, critical and larger spaces with substantial cooling and heating from a compact, wall-mounted package. Walk into any room where a PKA system is installed, and all you’ll notice is the perfectly comfortable climate. What you may not notice is the unit itself, which mounts high on the wall and blends into most spaces.
(PKA-A30FA Model Shown) INVERTER PKA COOLING-ONLY P-Series Specifications GA/FA = Wired controller GAL/FAL = Wireless controller BS = Seacoast Protection Indoor Unit Model Name Outdoor Unit Cooling *1 Power Supply Voltage Indoor Unit Rated Capacity Capacity Range Total Input Energy Efficiency Moisture Removal Sensible Heat Factor Phase, Cycle, Voltage Indoor - Outdoor S1-S2 Indoor - Outdoor S2-S3 Indoor - Remote Controller Indoor - Remote Controller MCA Fan Motor Fan Motor Output Airflow (Lo-M1-M2-Hi
(PKA-A30FA Model Shown) INVERTER PKA HEAT PUMP GA/FA = Wired controller GAL/FAL = Wireless controller BS = Seacoast Protection P-Series Specifications Indoor Unit Model Name Outdoor Unit Cooling *1 Heating at 47º F *2 Heating at 17º F *3 Power Supply Voltage Indoor Unit Rated Capacity Capacity Range Total Input Energy Efficiency Moisture Removal Sensible Heat Factor Rated Capacity Capacity Range Total Input HSPF (Region IV) Capacity Total Input Phase, Cycle, Voltage Indoor - Outdoor S1-S2 Indoor -
PLA PL A I n d o o r U n i t (Same indoor unit is used for both cooling and heat pump systems) ceiling-recessed series 12,000 to 42,000 Btu/h Capacity If there’s at least a foot of space above your ceiling, the PLA-Series is for you. These models combine powerful cooling and heating in an elegant cassette design that recesses into the ceiling. When installed, the attractive, low-profile grille is all you see.
INVERTER PLA COOLING-ONLY P-Series Specifications (PLA-A36BA Model Shown with optional I-SEE™ sensor) BS = Seacoast Protection Model Name Cooling *1 Power Supply Voltage Indoor Unit PLA-A12BA Outdoor Unit PUY-A12NHA PUY-A12NHA-BS Rated Capacity Capacity Range Total Input Energy Efficiency Moisture Removal Sensible Heat Factor Phase, Cycle, Voltage Indoor - Outdoor S1-S2 Indoor - Outdoor S2-S3 Indoor - Remote Controller MCA Fan Motor Fan Motor Output Airflow (Lo-M1-M2-Hi) External Pressure Indoor
INVERTER PLA heat pump (PLA-A36BA Model Shown with optional I-SEE™ sensor) P-Series Specifications BS = Seacoast Protection Indoor Unit Model Name Cooling *1 Heating at 47º F *2 Heating at 17º F *3 Power Supply Voltage Outdoor Unit Rated Capacity Capacity Range Total Input Energy Efficiency Moisture Removal Sensible Heat Factor Rated Capacity Capacity Range Total Input HSPF (Region IV) Capacity Total Input Phase, Cycle, Voltage Indoor - Outdoor S1-S2 Indoor - Outdoor S2-S3 Indoor - Remote Controller
PCA CEILING-SUSPENDED series 24,000 to 42,000 Btu/h Capacity PCA Ind oor Unit (The same indoor unit is used for both cooling and heat pump systems.) The PCA-Series is all about providing powerful cooling and heating performance. This ceiling-suspended unit delivers enough cold or hot air to make any space more comfortable. Manually-adjusted, over-sized swing louvers direct the airflow left or right, quietly covering the entire space.
(PCA-A36GA Model Shown) INVERTER PCA COOLING-ONLY P-Series Specifications BS = Seacoast Protection Indoor Unit Model Name Cooling *1 Power Supply Voltage Outdoor Unit Rated Capacity Capacity Range Total Input Energy Efficiency Moisture Removal Sensible Heat Factor Phase, Cycle, Voltage Indoor - Outdoor S1-S2 Indoor - Outdoor S2-S3 Indoor - Remote Controller MCA Fan Motor Fan Motor Output Airflow (Lo-M1-M2-Hi) Indoor Unit Sound Pressure Level (Lo-M1-M2-Hi) Btu/h Btu/h W SEER Pints/h PCA-A24GA PCA-A
(PCA-A36GA Model Shown) INVERTER PCA Heat Pump P-Series Specifications BS = Seacoast Protection Model Name Cooling *1 Heating at 47º F *2 Heating at 17º F *3 Power Supply Voltage Indoor Unit PCA-A24GA PCA-A30GA PCA-A36GA PCA-A42GA Outdoor Unit PUZ-A24NHA PUZ-A24NHA-BS PUZ-A30NHA PUZ-A30NHA-BS PUZ-A36NHA PUZ-A36NHA-BS PUZ-A42NHA PUZ-A42NHA-BS 24,000 12,000-24,000 2,500 13.4 5.4 0.75 26,000 12,000-28,000 2,570 30,000 12,000-30,000 4,100 13 8.3 0.
MS/MU,MSY/MUY,MSZ/MUZ/MXZ RATING CONDITIONS MAXIMUM COOLING INDOOR INTAKE AIR TEMPERATURE OUTDOOR INTAKE AIR TEMPERATURE 95º F D.B. (MS/MSY/MSZ), 90º F D.B. (MSY/MSZ-D/FD), 71º F W.B. (MS/MSY/MSZ), 73º F W.B. (MSY/MSZ-D/FD) 115º F D.B. MINIMUM HEATING REFRIGERANT LINE LENGTH FLARE/FLARE 67º F D.B., 57º F W.B. 67º F D.B. (MU), 14º F D.B. (MUY(Z), MXZ) MAXIMUM 80º F D.B., 67º F W.B. 75º F D.B., 65º F W.B. MINIMUM 70º F D.B., 60º F W.B. 14º F D.B., 13º F W.B. (MUZ), 12º F W.B.
OPTIONAL ACCESSORIES PART NUMBER USE WITH DESCRIPTION Controls Options MAC-397IF-E M-Series Inverter Units MA and contact terminal interface MAC-399IF-E M-Series Inverter Units M-NET control adapter for Mr.
LLineset ine - Hide Cover System TM Put a professional finish on air conditioning installations with an easy-to-install modular system that beautifies exteriors and protects linesets, drainlines, and wiring. • Available in four sizes: 2-1/4”, 3”, 4”, and 6” tubes. • Snap-on covers and a full selection of couplings, elbows, T-joints, caps, and more for any application, complex or simple. • High-quality PVC with UV inhibitors for outdoor service in all weather conditions.
Provides personalized comfort control for every room. Mitsubishi Electric Shizuoka Works acquired ISO 9001 certification under Series 9000 of the International Standard Organization (ISO), based on a review of quality warranties for the production of air-conditioning equipment. The plant also acquired environmental management system standard ISO 14001 certification.
