OPERATING THE CAMERA3
Manual And Automatic Operation - Overview3.1
MOBOTIX cameras do not require any extra software. Thus, you can set up and operate the
MOBOTIX camera using a JavaScript-enabled browser on all common operating systems
(such as Windows, Linux, Macintosh, etc.). As an alternative, you can also use the MOBOTIX
applications MxControlCenter and MxEasy. Follow these steps to set up the camera:
Connect the camera to the network.1. Power is supplied directly via the network
cable (see section 2.11)
Set up the camera's network parameters:2.
Manually using a web browser• (see section 3.2.1, then section 3.2.2)
Automatically using MxControlCenter/MxEasy• (see sections 3.2.3 and 3.2.4)
or via DHCP (see section 3.2.5)
Congure the camera3. using the browser-based user interface.
Every MOBOTIX camera comes preconfigured with a fixed IP address in the 10.x.x.x range
(e.g. 10.8.0.99). However, local computer networks usually have IP addresses in the
172 or 192 ranges. In order to access a MOBOTIX camera via the network, the camera
needs to obtain an IP address in the same address range. You can set up the network
parameters of the MOBOTIX camera using one of the following methods: Manually,
using MxCC and MxEasy or by DHCP.
Camera software
in the browser
