MOBOTIX HEMISPHERIC TECHNOLOGY
Perfect Room Overview
With the innovative MOBOTIX Hemispheric Technology, an entire room can
be ideally monitored. or instance, one single, particularly elegant and
discreet, Q24M replaces the time-consuming and expensive installation
of several standard cameras. This world first demonstrates again the
innovative strength of MOBOTIX as a global leader for megapixel video
security systems.
High-Resolution 180° Panorama
When several cameras are monitoring a single room, it is difficult to understand the room
layout in its single view. This makes it hard to comprehend the overall setting. The new
panorama function of the Q24M delivers a widescreen image of a high-resolution 180°
allround view. High image quality is achieved through the use of a 3.1 megapixel sensor
and the new hemispheric lens.
Virtual PTZ (vPTZ) – Without Motor
The Q24M also zooms in on detail. The
image of the Hemispheric camera can
be continuously enlarged and any image
section examined using a joystick, for
example. Thus you have a mechanical
PTZ-camera without maintenance or wear
and tear. While zooming into a section
in the live image, a full image can be
stored in the recording for later analysis.
No PTZ-camera in the world that oper-
ates with a motor can do that!
High-resolution 180° Panorama
vPTZ
Q
2
4
M
w
i
t
h
i
n
-
c
e
i
l
i
n
g
m
o
u
n
t
Original Q24M image;
Wall mounted at a height
of 2.3 m in a bank
vPTZ control, also
using a USB joystick
