Available Q24M Accessories - Overview2.3
On-Wall Set (MX-OPT-AP)
Consists of On-Wall Mount and mount-
ing supplies. Conforms to U.S. installation
standards. Reliably protects the cabling and
allows integrating additional modules within
the On-Wall Mount (patch cable/installation
cable connector, IO extensions, WLAN, bat-
tery, ...).
10° On-Wall Set (MX-OPT-AP-10DEG)
Consists of On-Wall mount and mounting sup-
plies for inclined installation (10°) of a camera.
Conforms to U.S. installation standards Reliably
protects the cabling and allows integrating
additional modules within the On-Wall Mount
(patch cable/installation cable connector, IO
extensions, WLAN, battery, ...).
Vandalism Set (MX-Q24-Sec-Vandal-ESPO)
Consists of polished stainless steel housing,
lens protector and security screws. Ideally
suited for surveillance at critical locations.
Vandalism Set (MX-Q24-Sec-Vandal-ESMA)
Alternative design featuring matt stainless
steel housing. As above incl. lens protector
and security screws.
The matt stainless
steel housing has a
thickness of 1.5 mm
The polished stain-
less steel housing has
a thickness of 1.5 mm
