Installation Manual

ASSEMBLY INSTRUCTIONS
STEP 2
B
2
STEP 1
A
1
3
STEP 3
Secure the support board by using JCBB Bolt [1]
& flat washer [2]. Tighten with supplied allen key
[3]. Repeat the same procedure to secure the
other side.
Align support board fixing holes over headboard
fixing holes according to your desired height.
Your headboard assembly is complete.
Note: Hardware may loosen over time. Periodically
check that all connections are tight.
FURNITURE PART LIST
ITEM DESCRIPTION
QTY
A
HEADBOARD 1 PC
B
SUPPORT BOARD 2 PCS
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
HARDWARE PART LIST
ITEM DESCRIPTION
QTY
1
JCBB BOLT M8 x 40mm 4 PCS
2
M8 FLAT WASHER 4 PCS
3
M5 ALLEN KEY 1 PC
MOD - 5172
Read this instruction carefully. See furniture and hardware part lists,
on the right, for guidance.
Have all parts ready before assembly. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the steps below to start assembling.
CAUTION : 1. Do not FULLY - TIGHTEN the nut or bolt until all nuts and bolts are assembled.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
