Specification

6-13/16"
(170mm)
7-7/8"
(200mm)
29-1/2"
(749mm)
16-7/8"
(429mm)
9-9/16"
(243mm)
8-3/4"
(222mm)
2-1/2”
( 63mm)
Ma x. Deck
Thickne s s
WOODMERE®
Single Handle Single Hole Mount
High Arc Pulldown Kitchen Faucet
Models: S7208 series
NOTE: THIS FAUCET IS DESIGNED TO BE INSTALLED THRU
1 HOLE, 1-1/2" (38MM) MIN. DIA.
Rev. 1/15
DESCRIPTION
• Reflex™ pulldown system offers smooth operation, easy movement
and secure docking
• Metal construction with various finishes identified by suffix
• High arc spout provides the height and reach to fill or clean large pots
while the pulldown feature provides infinite maneuverability for
cleaning or rinsing
• Single hole mounting
• Wand with Quick connect installation
• Pulldown spray with 68" braided hose
• Flexible supply lines with 3/8” compression fittings
OPERATION
• Single handle lever
• Temperature controlled by 100˚ arc of handle travel
• Convenient single-button actuation provides flexibility to switch from
stream to spray mode
FLOW
• Flow is limited to 1.5 gpm (5.7 L/min) at 60 psi
CARTRIDGE
• 1255™ Duralast™ cartridge for Single-Handle Faucets
STANDARDS
• Third party certified to IAPMO Green, ASME A112.18.1/CSA B125.1
and all applicable requirements therein including NSF 61/9
• Meets CalGreen and Georgia SB370 requirements
• Contains no more than 0.25% weighted average lead content
• Complies with California Proposition 65 and with the Federal Safe
Drinking Water Act
• ADA for lever handle
WARRANTY
• Lifetime limited warranty against leaks, drips and finish defects
to the original consumer purchaser
• 5 year warranty if used in commercial installations
CRITICAL DIMENSIONS
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
S p e c i f i c a t i o n s
There is more than 1 version of this model.
Page down to identify the version you have.
