Specification

Specifications
FAUCET DESCRIPTION
• Reex™ pulldown system oers smooth operation, easy movement and secure docking
• Metal construction with various nishes identied by sux
• Quick connect installation
• Pullout spray with 68" braided hose
• Flexible supply lines with 3/8" compression ttings
• High arc spout provides height and reach to ll or clean large pots while pull out wand
provides the maneuverability for cleaning or rinsing
• 360˚ rotating spout
OPERATION
• Lever style handle
• Temperature controlled by 100˚ arc of handle travel
• Operates with less than 5 lbs. of force
• Operates in stream or spray mode in the pullout or retracted position
• When lling a vessel outside the sink, the pause feature conveniently stops the ow of
water as the wand passes over the counter top
FLOW
• Flow is limited to 1.5 gpm (5.7 L/min) at 60 psi max
CARTRIDGE
• 1255™ Duralast™ cartridge for Single-Handle Faucets
STANDARDS
• Third party certied to IAPMO Green, ASME A112.18.1/CSA B125.1 and all applicable
requirements referenced therein including NSF 61/9 & 372
• Meets CalGreen and Georgia SB370 requirements
• Complies with California Proposition 65 and with the Federal Safe Drinking Water Act
• The backow protection system in the device consists of two independently operating
check valves, a primary and a secondary which prevent backow
• ADA
for lever handles
WARRANTY
• Limited lifetime warranty against leaks, drips and
nish defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
Notch
Single Handle High Arc
Pulldown Kitchen Faucet
Models: 9124 series
NOTE
: this faucet is designed to be in-
stalled thru 1 hole, 1-1/2" (38mm) min.
dia.
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
8-5/8"
(21.91cm)
16-1/4"
(41.28cm
)
8"
(20.32cm)
7-13/16"
(19.84cm)
6-5/8"
(16.83cm)
Rev. 9/14
CRITICAL DIMENSIONS
(DO NOT SCALE)
