Specification Sheet
CRITICAL DIMENSIONS
(DO NOT SCALE)
Specifications
FOR MORE INFORMATION CALL: 1-800-465-6130
www.moen.com
Via™
Single-Handle Lavatory Faucet
Model: S8001
NOTE: THIS FAUCET IS DESIGNED TO BE
IN STALLED THRU 1 HOLE, 1-1/8” MIN. DIA.
Lift
Rod
2-1/2"
(80mm)
MAX.
23-1/4"
(593mm)
For lift rod operation
2-1/2" (63mm) min.
from blackspash
1-25/32"
(45mm)
6"
(152mm)
6-7/64"
(155mm)
2-59/64"
(47mm)
3-51/64"
(96mm)
3-15/32"
(88mm)
4-33/64"
(115mm)
2-25/32"
(71mm)
9 Degrees
2-3/64"
(52mm)
DESCRIPTION
• Metal construction with chrome finish
• Flexible supply lines with 3/8” compression fittings
• Includes metal pop-up waste assembly
OPERATION
• Lever style handle
• Temperature controlled by 100° arc of handle travel
• Includes hot & cold temperature indicators
FLOW
• Flow is limited to 1.2 gpm max (5.7L/min) at 60 psi
CARTRIDGE
• 1255™ Duralast™ cartridge for Single-Handle Faucets
STANDARDS
• Third party certified to ASME A112.18.1/CSA B125.1, NSF 61/9 & 372
and all applicable requirements referenced therein
• Third party certified to comply with WaterSense® High Efficiency
Bathroom Sink Faucet Specification
• Complies with California Proposition 65 and with
the Federal Safe Drinking Water Act
• ADA for lever handle
WARRANTY
• Lifetime limited warranty against leaks, drips and
finish defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
Rev. 10/15
