Instructions / Assembly

Illustrated Parts
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
Single Function Body Spray Trim
MODEL SHAPE FINISH
TS1320 Square Chrome
TS1320BN Square Brushed Nickel
TS1320NL Square Polished Nickel
TS1320ORB Square Oil Rubbed Bronze
TS1322 Round Chrome
TS1322BN Round Brushed Nickel
TS1322NL Round Polished Nickel
TS1320ORB Round Oil Rubbed Bronze
Rev. 8/14
Set Screw Kit
155652
Square Trim Ring
155649 Chrome
155649BN Brushed Nickel
155649NL Polished Nickel
155649ORB Oil Rubbed Bronze
Round Trim Ring
155650 Chrome
155650BN Brushed Nickel
155650NL Polished Nickel
155650ORB Oil Rubbed Bronze
Order by Part Number Trim must be used with
S1300 Rough-in
1" Extension Kit
155656
O-Ring Kit
155654
Filter Screen Kit
155655
Housing Nut
(Includes hex wrench for spray engine screws)
155651
