Specification

FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
CRITICAL DIMENSIONS
(DO NOT SCALE)
Spec i fi ca tions
Banbury®
Two-Handle 4" Centerset Lavatory Faucet
Models:
WS84912 series includes pop-up waste
3-5/8"
(92mm)
9-1/4"
(235mm)
2-3/8"
(60mm)
5-5/8"
(143mm)
3-3/4"
(95mm)
2-1/2"
(64mm)
4"
(102mm)
6-1/2"
(165mm)
5/16" (8mm) MIN. Deck Thickness
1-3/16" (30mm) MAX. Deck Thickness
Lift
Rod
2-9/16"
(65mm)
Rev. 10/17
There is more than one version of this model.
Page down to identify the version you have.
DESCRIPTION
• Metal construction with various finishes identified by suffix
• 1/2" IPS connections for exible hoses only; not for use with rigid or semi-rigid
supply risers (3/8" Copper or Pex) with coupling nuts
• Installation through 3 holes, 1" min. diameter, and 4" on center
• Includes pop-up waste assembly
OPERATION
• Lever handles
• Maximum handle rotation angle is 90° to full on
• Hot side counterclockwise to open (clockwise to close)
• Cold side clockwise to open (counterclockwise to close)
FLOW
• Water usage is limited to the maximum ow rates as indicated by the
corresponding product markings
º
1.2 gpm max (4.5 L/min) at 60 psi
CARTRIDGE
• 1224 cartridge
• Nonmetallic and stainless steel material
STANDARDS
• Third party certied at WaterSense®, ASME A112.18.1/CSA B125.1, and all
applicable requirements referenced therein including NSF 61/9 & 372
• Products marked with 1.2 gpm are compliant with California water
eciency regulations
• Complies with California Proposition 65 and with the Federal Safe
Drinking Water Act
• ADA for lever handles
WARRANTY
• Lifetime limited warranty against leaks, drips and nish defects to the
original homeowner
• 10 year limited warranty when used in a multifamily installation
• 5 year limited warranty when used in a commercial installation
Visit www.moen.com/support for complete details and limitations
OPTIONS (See Illustrated Parts page)
• Thin and thick deck mounting hardware kits available
