Use and Care Guide

25300 AL MOEN DRIVE
•
NORTH OLMSTED, OH 44070
CORPORATE HEADQUARTERS: (800) 321- 8809 • FAX: [phone]
INTERNATIONAL: (440) 962- 2000 • FAX: [phone]
CUSTOMER SERVICE (USA): 800-882-0116 • FAX: [phone]
WWW.CSI.MOEN.COM
Copyright Creative Specialties International 2006
Paper Holder is constructed of zinc.
q
YB2208BN
–
Paper
Holder
Brushed Nickel Finish
q YB2208CH – Paper Holder
Chrome Finish
q YB2208ORB – Paper Holder
Oil Rubbed Bronze Finish
Cleaning Instructions:
Directions below are for installation into drywall. If installing product
into a stud, use the wood screws only.
1.The center to center measurement for this product is 6 ¼”.
2.Mark this distance on the wall where you want to install the product.
3.Use a level to ensure that the pilot holes will be perfectly level.
4.Using ¼” drill bit, drill one pilot hole for each post.
5.Position mounting posts to wall by inserting wall anchors into pilot
holes and pressing firmly. (Make sure that locking tab on mounting
post is facing down.)
6.Tighten wall anchor screw while holding mounting post firmly in
place. Tighten anchor until resistance increases. DO NOT over
tighten.
7.Using tip of screw bit press wall spikes (metal pieces on outer edge
of mounting post) into drywall.
8.Towel bar must be attached to mounting posts as a unit – insert
towel bar into each post.
9.Attach posts by pressing firmly to mounting posts until it clicks. (The
square opening at the base of the post must be facing down to
match-up with locking tab).
Stock Number:
______________________Paper Holder
By Creative Specialties
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
Paper Holder
YB2208
Brantford™ Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
Literature #BA1395
