Technical Specifications

Towel Ring
post is constructed of
zinc. Ring is aluminum.
q
YB5486CH
–
Towel Ring
Chrome Finish
q YB5486CP – Towel Ring
Chrome & Polished Brass Finish
q YB5486PB – Towel Ring
Polished Brass Finish
q YB5486WR – Towel Ring
Wrought Iron Finish
q YB5486BN – Towel Ring
Brushed Nickel Finish
q YB5486AN – Towel Ring
Antique Nickel Finish
q YB5486ORB – Towel Ring
Oil Rubbed Bronze Finish
Cleaning Instructions:
25300 AL MOEN DRIVE • NORTH OLMSTED, OH 44070 [phone] •
FAX: [phone] • INTERNATIONAL: (440) 962- 2000 •
FAX: (440) 962
-
2726 CUSTOMER SERVICE (USA): 800
-
882
-
0116
1.
Remove the mounting post from the body by loosening the setscrew.
2. Position the mounting post on the wall at desired location. Large slots
to be right and left. Small holes to be top and bottom.
3. One at a time, place each anchor screw through the mounting post,
centered in the large slot hole. Using a Phillips screwdriver, turn the
anchor screw while applying pressure. Screw will self drill and tap
into drywall. Do not over tighten.
4. Place assembly over the mounting post, setscrew facing down.
5. Tighten setscrew.
Stock Number:
______________________Towel Ring
By CSI Bath Furnishings
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
Towel Ring
YB5486
Kingsley Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.

Copyright CSI Bath Furnishing Division of Moen 02/22/01
Literature #BA1122
