Specification Sheet

Weymouth
®
Technical Specication
Towel Ring YB8486
Stock Numbers: Dimensions:
Cleaning Instructions:
YB8486BN – Paper Holder
Brushed Nickel Finish
YB8486CH – Paper Holder
Chrome Finish
YB8486ORB – Paper Holder
Oil Rubbed Bronze Finish
YB8486NL – Paper Holder
Polished Nickel Finish
YB8486BG – Paper Holder
Brushed Gold Finish
Installation Instructions:
1. Remove the mounting bracket from the body by loosening the setscrew.
2. Position the assembled unit on the wall where desired.
3. Lightly mark the outline of each base.
4. Center a mounting bracket within each base outline with “UP” facing you .
5. Mark the 2 large hole locations of each mounting bracket.
6. Attach each mounting bracket to the wall, using the wall anchors provided
7. Mount each base on the corresponding mounting bracket. Check and make sure that
the base set screw hole(s) are facing down. Assemble a set screw to each base. Use
the allen wrench included in hardware kit to tighten each set screw and secure the
assembly to the mounting bracket(s).
To preserve the ne nish of this product, clean only with a soft damp cloth.
Dry well. Do not use commercial or abrasive cleaners.
Materials:
Towel Ring base and ring are constructed
of zinc.
Stock Number: _____________________ Towel Ring
By Moen Incorporated
25300 AL MOEN DRIVE • NORTH OLMSTED, OH 44070
CORPORATE HEADQUARTERS: [phone] • FAX: [phone]
INTERNATIONAL: (440 ) 962-2000 • FAX: [phone]
CUSTOMER SERVICE (USA): 800-882-0116 • FAX: [phone]
WWW.MOEN.COM
©
2017 Moen Incorporated. Moen is a registered trademark and Weymouth is a trademark
of Moen Incorporated. All rights reserved.
6.50"
16.51cm
7.29"
18.52cm
3.15"
8.00cm
