Printer Quick Reference Manual

06/08 Rev. AA QUICK REFERENCE Getting Started
9864
4
y For more detailed descriptions of the button functions, see “Creating a print
job” or refer to Info-Printouts and Parameters section on the CD-Rom.
Remote operator
panel
The printer can be equipped with a remote operator panel. The printer must
provide the appropriate optional connector. Refer to the Operator’s
Handbook for more information.
The button functions are the same as those on the standard operator panel.
Exception: The on/off switch is not available at the remote control panel.
With the remote control panel connected, both panels are active and show
the same information.
[3] Remote operator panel (article number 160005)
CAUTION!
Using both operator panels at the same time can cause malfunctions.
« Use only one operator panel at a time to operate the printer.
CAUTION!
If the connection cable is longer than 2.5 m, EMC-caused disturbances can
occur.
« Only use the factory-installed cable.
« Do not extend the cable.
