Specification

5HS42RB: 42" Homeowner's Select II Fan - Roman Bronze

Collection:HomeownersSelectII


UPC #:026586969968

Finish:RomanBronze(RB)


Blade Finish:AmericanWalnut


Blade Finish 2:Undefined
Specification Images:
Dimensions:

Diameter: 42''
Weight: 12.57lbs.
Reverse Switch: Manual
Rev. Switch Location: SwitchHousing
Motor Size: 153.0X12.0
Diameter of Housing: 11.0
Capacitor Value: 4.25+5+6/350V/85C
Lead Wire Length: 78inches
Remote Included: None
Remote Group(s): CK250,CKF210,ESSWC-2/-3
Features:
Fixtureisoperatedwithapullchain
Material List:
Safety Listing:

SafetyListedforDryLocations
SafetyListedforDryLocations
Instruction Sheets:
English(5HS52_42XX-CUL-ENG)
French(5HS52_42XX-CUL-CF)
Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Canopy    51/8  
Blade Details:
Blade Group Diameter Included RPM
Hi
CFM
Hi
Watts
Hi
Amps
Hi
RPM
Med
CFM
Med
Watts
Med
Amps
Med
RPM
Low
CFM
Low
Watts
Low
Amps
Low
B-T 42 Yes 198.0 3900.43 56.5 0.471 142.0 2696.74 27.2 0.338 84.0 1576.87 10.5 0.21
Mounting Options:
MonteCarloreservestherighttorevisethedesignofcomponentsofanyproductduetopartsavailabilityorchangeinsafetylistingstandardswithoutassuminganyobligationorliabilitytomodifyany
productspreviouslymanufacturedandwithoutnotice.ThisliteraturedepictsaproductdesignthatisthesoleandexclusivepropertyofMonteCarlo.IncompliancewithU.Scopyrightandpatent
requirements,notificationisherebypresentedinthisformthatthisliterature,ortheproductitdepicts,isnottobecopied,alteredorusedinanymannerwithouttheexpresswrittenconsentof,or
contrarytothebestinterestsofMonteCarlo�AGenerationBrandsCompany.
Vistourwebsiteatwww.MonteCarloFans.com
5HS42RB-page1of2
