10 Chapter 2 Features
Pen
An important difference between traditional PCs and tablet PCs is that you frequently use a
pen instead of a mouse and keyboard to interact with the computer. The pen includes a
pressure-sensitive tip, a function button, and an eraser. The pen contains no batteries and
requires no external power.
For information about using the pen, see “Using the pen” on page 21.
Status lights
You can use the indicator lights on the front of the unit to monitor the status of the system.
The following illustration shows the status lights.
Light Status Description
Wi-Fi Steady green The Wi-Fi (802.11 a/b/g) adapter is enabled
Battery Steady amber The battery is charging
Steady green The battery is fully charged
Flashing amber (slow) 10% charge remaining
Flashing amber (fast) Less than 5% charge remaining
Bluetooth Steady green The Bluetooth adapter is enabled
Tip
Function button
Eraser
A
B
Battery
Wi-Fi
Bluetooth
