User's Manual
Table Of Contents
- Contents
- Getting Started
- Features
- Using the system
- Using Motion Dashboard
- Using the pen
- Using Tablet PC Input Panel
- Configuring pen options
- Enabling personalized handwriting recognition
- Using personalized handwriting recognition
- Configuring front panel buttons
- Using the display
- Using the bar code scanner
- Using the RFID reader
- Using the camera
- Using the smart card reader (optional)
- Using the built-in microphones
- Using speech recognition
- Using the battery
- Using power management
- Using Wi-Fi (802.11a/b/g)
- Using Mobile Broadband
- Using Bluetooth
- Using Motion OmniPass and the fingerprint reader
- Using Windows Security Center
- Setting up users and passwords
- Finding additional software
- Care and Maintenance
- Troubleshooting and Support
- Index
Chapter 1 Getting Started 3
Right side
Top side
Power adapter
port and cover
Camera
button
Fingerprint
reader
Bar code scanner
lens
Windows Security
button
Power
button
RFID antenna
area
Power adapter port
and cover
Connect the power adapter (page 19).
RFID antenna area Scan area for reading RFID tags (page 16).
Camera button Use to trigger the built-in camera (page 14).
Windows Security
button
Use to log on to or lock the system. Equivalent to
Ctrl+Alt+Del on a keyboard (page 13).
Fingerprint reader Scan your fingerprints for added security. You can also
use the fingerprint reader as a navigation device
(page 13).
Power button Turns the system on and off.
Bar code scanner
lens
Reads codes from bar code labels (page 15).
Bar code
light
RFID button
scanner button
RFID status
Fan cover
RFID status light Shows the status of the RFID scanner.
RFID scanner
button
Use to trigger the RFID scanner (page 16).
Bar code scanner
button
Use to trigger the bar code reader (page 15).
Fan cover Protects the fan assembly.
