EN MOTOROLA XT535 Jan. 12.
Jan. 12.
Congratulations MOTOROLA XT535 Your MOTOROLA XT535 helps you seamlessly manage your “Office” and “Outdoor” lifestyles. • Lifeproof: Your phone is water-resistant, dustproof, and has a scratch-resistant screen, because accidents happen. • Dashboard: Easy access to all your favorite Outdoor apps, like Camera, Compass, and a pedometer, see“Dashboard” on page 12. • MotoSwitch: MotoSwitch is a dynamic interface that gives you seamless access to content that is relevant to you. For details, see on page 13. Jan.
include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The highest SAR values measured for this device are listed in the regulatory information packaged with your product. Note: When using the product while worn on your body, either use an approved accessory such as a holster or maintain a distance of 2.5 cm (1 inch) from the body to ensure compliance with SAR requirements.
Your phone the important keys & connectors Power/ Sleep Key Press=sleep Hold=power 3.5mm HSJ Headset Jack Notification Light Flash=missed call, new message, or other notification. Volume Keys Front Camera Jan. 12. 2012 Micro USB Microphone Menu Open options. Home Touch= home screen Hold= recent apps Back Go back one screen.
Camera Jan. 12. 2012 Cover Lock Note: To help protect your phone, always make sure that the battery cover and any connector covers are closed and secure.
Contents Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Home screen & apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Let’s go let’s get you up and running Assemble & charge 1 Cover off 2 SIM in 3 2 1 3 microSD in (may already be inserted) 4 Battery in Jan. 12.
Caution: Please read “Battery Use & Safety” on page 43. Set up & go Note: This phone supports apps and services that use a lot of data, so make sure your data plan meets your needs. Contact your service provider for details. When you turn on your new phone, you can create or enter a Google™ account so that you can download apps, use Gmail™, and much more: 1 Press and hold Power on your phone. to turn Power Key 2 Touch the Android™ image to begin setup. 3 Touch a button to Create a Google Jan. 12.
If your phone cannot connect, touch Menu > WLAN settings to change mobile network settings. Rugged Your MOTOROLA XT535 stands up to water, dust and life. Now your investment is safe and protected from life’s little challenges, like that sudden rain shower and other everyday mishaps. Of course, your phone isn’t indestructible, so to avoid damage from natural elements, such as water, sand, and dust intrusion, always make sure that the battery door cover and connector covers are closed and secure.
sleep & wake up Your screen sleeps when you hold it to your ear during a call, or when it is inactive. To change the sleep delay, touch Menu > Settings > Display > Screen timeout. To unlock the screen, drag outer circle. to the Keys Use your phone’s keys to navigate and open options at any time. Press the volume keys to Jan. 12. 2012 change the ringer volume (in the home screen), or the earpiece volume (during a call). Volume Keys Touch Home to return to the home screen.
Home screen & apps a few essentials Quick start: Home screen You’ll see the home screen when you turn on the phone or touch Home from a menu: 11:19 Status Indicators Notifications Flick down for details. 11 12 Widgets Touch to open. Touch & hold to move or delete. 1 10 2 9 3 8 4 7 6 5 Drag or flick to open panels (or scroll in lists). Jan. 12. 2012 Shortcuts Open the app menu. • To open shortcuts or widgets, touch them. Touch Home to return to the home screen.
• To move or delete shortcuts or widgets, touch and hold them until you feel a vibration, then drag it to another spot, another panel, or at the top. In lists like Contacts, touch and hold list items for options. • To add shortcuts, widgets, or wallpaper, touch and hold an empty spot until you see the menu. You can also add a folder to organize your shortcuts. • To show more panels, drag or flick right or left. Touch Home to show panel thumbnails. In lists like Contacts, drag or flick to scroll.
Dashboard You can access the outdoor apps on your phone, with DashBoard. the dashboard, just touch > 0 00:32 Call RUNTIME 00’00”00 PEDOMETER 0 CALORIE Steps 0.0 Cal Drag or flick to see other apps. Start/Stop/Save pedometer record. T Touch & Hold W E N Compass Camera To change app that is shown. Jan. 12. 2012 91 .8 FM Radio Shortcuts S Your dashboard shows apps, like Camera, Compass, and FM Radio.
motoswitch Jump right to your favorite apps from the lock screen! To set up your lock screen apps: 11:19 00:32 Your favorites. Touch & hold between the two rings to show your most used apps at the bottom. http:// http h ht htt ttp://ww t //www //ww www. Jan. 12.Drag 2012 to scroll. Calendar Camera Contacts Email Gmail Most used apps. Drag an app to the outer ring to add it to your favorites. To go to a favorite app from the lock screen, drag the app towards the lock icon .
Apps To show your app menu, touch . • To scroll, flick up or down. • To open an app, touch it. • To close the app menu, touch Back . Tip: To show the last eight apps you opened, touch and hold Home . To download new apps from Android Market™, touch Market. Touch Search to find an app, or > touch Downloads to show or reinstall the apps you downloaded. To download apps from websites, you need to change your security settings: Touch Menu > Settings > Applications > Unknown sources. Jan. 12.
On your computer, you can browse and manage apps for all your devices powered by Android™ at market.android.com. Choose carefully Apps are great. There's something for everyone. Play, communicate, work, or have fun. But remember, choose your apps carefully. Here are a few tips: • To help prevent spyware, phishing, or viruses from affecting your phone or privacy, use apps from trusted Market. sites, like • In Market, check the apps’ ratings and comments before installing.
• Certain apps may not provide completely accurate information. Take care, especially when it comes to personal health. Phone status & notifications In the status bar at the top of your screen, the right side shows phone status. The left side shows new messages or events (for details, flick the bar down). Notifications New voicemail Dial (Your Voicemail Number) 10:32 network strength battery strength new voicemail new text message Bluetooth™ on 16 11:19 Clear Bluetooth connected Jan. 12.
Personalize add your personal touch Quick start: Personalize From the home screen, touch Menu Sound or Display. > Settings > Sound settings General Silent mode Silence all sounds except media & alarms Choose separate volume settings for incoming calls, media, alarms, and notifications. Vibrate Only in Silent mode Volume Incoming calls Call & Message Notifications Display settings Jan. 12.
Calls it’s good to talk Quick start: Calls From the home screen, touch 11:19 00:32 11:19 Phone Phone Calllog log Call Contacts Contacts . Open a list, then touch an entry to call. Favorites Favorites Christine F... Shows matching numbers, flick down to see more. 222-333-4444 29 matches 11:19 00:32 11:19 01 Hold ABC DEF GHI JKL MNO PQRS TUV WXYZ Jan. 12. 2012 00:32 Christine Fanning + Home 222-333-4444 Hang up. Call. Start a conference call.
Conference calls To start a conference call, call the first number. After they answer, touch Add call and call the next number. When the next number answers, touch Merge calls. To remove individual callers, touch Manage. Call waiting If you are on a call and a new call arrives: • With call waiting on, you can drag to the right to answer the new call and put the old call on hold. Then, touch Swap to switch between calls, or Merge calls to combine them.
Emergency calls Note: Your service provider programs one or more emergency phone numbers that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues. 1 Touch (if your phone is locked, then touch Emergency Call). 2 Enter the emergency number. 3 Touch Call to call the emergency number.
Contacts contacts like you’ve never had before Quick start: Contacts From the home screen, touch Contacts. 11:19 00:32 11:19 Phone Phone Call log Contacts Contacts Call log Favorites Favorites Switch to the dialer, recent calls, favorites or groups. Displaying 456 contacts A Arthur Baudo B Drag or flick to scroll. Barry Smyth Jan. 12. 2012 C Cheyenne Medina Search New contact Display options Christine Fanning Accounts Import/Export Touch to search, create, and more.
individual contact: Touch and hold a blank spot on your home screen, then choose Shortcuts > Contact. Storage & transfer When you create a new contact, your phone asks if you want to store it in your Google™ account, phone memory, or SIM card. Contacts in all three places appear in your Contacts list, but if you change phones: • Contacts in your Google™ account can download when you log into your Google account on a new Android™ device. You can open these contacts from any computer at contacts.google.com.
Messaging sometimes it’s best to text or email... Quick start: Text messaging From the home screen, touch Messaging. 11:19 00:32 11:19 Messaging New message Compose new message 12254558787 You had 1 missed call from 122545458787 ... 17 Aug 14447772222 Wanna catch something to eat tonight? How about ... 12223334545 17 Aug Drag or flick to scroll. 16 Aug Ha! Thanks. Jan. 12. 2012 Traditional mode Compose Delete threads Search Touch and more.
Email • To set up Google or Corporate (Microsoft™ Exchange server) accounts, touch Menu > Settings > Accounts & sync > Add account. For details, contact the account provider. To set up standard email accounts (not Gmail™ or Email and Microsoft™ Exchange), touch > follow the wizard. To add more standard accounts, Email and touch Menu > Accounts > open Menu > Add account. For details, contact the account provider. Email or • To open email, touch > Touch a message to open it. Tip: Touch Menu Search. Gmail.
Voicemail When you have a new voicemail, shows in the status bar at the top of your screen. To hear voicemails, touch then touch and hold 1. If you need to change your voicemail number, in the home screen touch Menu > Settings > Call settings > Voicemail settings. For your voicemail number or other details, contact your service provider. Jan. 12.
Text entry keys when you need them Quick start: Text entry To change the keyboard, touch and hold a blank spot in a text box. A menu opens, where you can choose Input Method > Android keyboard or Swype. Note: Swype is not available in all regions. Your keyboard might change depending on what you’re entering. Swype lets you drag your finger over the letters of a word, in one continuous motion. Anne EN @ 1 # 2 q w e r & a $ 26 4 s d z :-) To enter a word, just Send trace a path through Jan.
Android keyboard lets you enter letters by touching them one at a time. Type to compose T Q W E A R T Y U S D F G H Z EN Send I O P J K L X C V B N M 56 #@ Touch and hold an empty spot to open a menu. DEL x Delete ., Symbols/Numbers Text entry dictionary Jan. 12. 2012 Your phone’s dictionary stores special words or names to recognize when you enter them. To open your dictionary, from the home screen touch Menu > Settings > Language & keyboard > User dictionary.
Schedule helping you stay in control Quick start: Schedule From the home screen, touch > Calendar. June 2012 Mon Tue Wed Thu Fri Sat Sun 28 29 30 31 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 25 26 27 1 2 Agenda 28 29 30 Week Day 3 4 Today Drag or flick to scroll. 24 Jan. 12. 2012 31 Month 5 Color indicates events. 6 7 More Touch to choose the calendar view. Choose More to create an event or change settings.
• To set a snooze period, in the Alarm Clock list touch Menu > Settings > Snooze duration. When an alarm sounds, touch Dismiss to turn it off or Snooze to delay it. To cancel a snoozed alarm, drag down the status bar and touch the alarm name. Date & time To set the date, time, time zone, and formats, touch Menu > Settings > Date & time. Jan. 12.
Web surf the web with your phone Quick start: Web From the home screen, touch 11:19 http://www.google.co.uk/ > h ttp: //w w w . Browser. Connection Mobile Network: Wi-Fi: Enter a web page URL. Drag or flick to scroll. Jan. 12. 2012 New window Bookmarks Windows Refresh Exit More Touch to open bookmarks, windows, and more. Note: Your phone automatically uses your mobile phone network to connect to the web. Your service provider may charge to surf the web or download data.
Downloads To download files in your browser, touch a file link or touch and hold a picture to choose Save image. To show the files you downloaded, touch > Downloads. Touch and hold an item to open it, see details, or remove it from the list. You can download “Apps” on page 14. Jan. 12.
Location where you are, and where you’re going Quick start: Location From the home screen, touch E Ontario St Show layers on the map. E Ohio St Dr N Co l u m b u s N Micigan Ave A E Wacker Pl N Park St N Clark St N Dearborn D e a r b o r n St St 44 West Street Wacker Dr Find nearby places. E Grand Ave N New St N Rush St M N Wabash Ave Grand Red Drag or flick to scroll.
Photos & videos see it, capture it, share it! Quick start: Photos & videos From the home screen, touch > Camera. 8MO2109 Capture. Touch the screen to open options. Open your last photo or video. Jan. 12. 2012 Zoom in/out. Tip: For the clearest photos and videos, clean the lens with a soft, dry cloth. View & share photos & videos From the home screen, touch > My Gallery. Flick left and right to show folders.
• To zoom in, touch the screen with two fingers and then drag them apart. To zoom out, drag your fingers together. • To send or post the photo or video, touch Menu > Share. To use a Bluetooth or cable connection, see “Bluetooth™, Wi-Fi, & cable connections” on page 38. • To delete the photo or video, touch Menu > Delete. • To set a photo as your wallpaper or a contact photo, touch Menu > More > Set as. Jan. 12. 2012 • To crop or rotate a photo, touch Menu > More. • To play a video, touch .
Music when music is what you need... Quick start: Music From the home screen, touch choose a song to play it: > Music, then Patience | Take That Progress Bar Jan. 12. 2012 0:26 1:35 Total Song Time Music Controls Open Playlist Shuffle On/Off Repeat Off/All/Current • To adjust volume, use the volume keys.
• When a song is playing, you touch Menu to a playlist or use it as a ringtone. to add it To edit, delete, or rename playlists, touch > Music touch the Playlists tab, then touch and hold the playlist name. • To hide the player and use other apps, touch Home . Your music keeps playing. To return to the player, flick down the status bar and touch . • To stop the player, touch .
Media view and share... Quick start: Media From the home screen, touch Local > Connecting netw... MediaSee. Show Media Server List Photo Touch to open. Video Music Jan. 12. 2012 Touch to select category (Photo, Video, or Music). to Select a Media Player or the Upload/Download Manager. • Touch Menu • Touch and hold a thumbnail, then touch Push to, Upload or Information to send to an online media server or display details.
Bluetooth™, Wi-Fi, & cable connections home, office, or hotspot Quick start: connections Note: Due to French regulatory restrictions regarding possible interference, do not use Bluetooth in France when outdoors. From the home screen, touch Menu > Settings > Wireless & networks, then Bluetooth settings or WLAN settings. Bluetooth settings Bluetooth Device name Turn Bluetooth power on & scan, or turn off. Jan. 12. 2012 (Your Phone) Change your phone’s Bluetooth device name. Discoverable Re-scan.
• To connect Bluetooth devices, touch Menu > Settings > Wireless & networks > Bluetooth settings > Scan for devices (or Bluetooth, if it is off). Touch a device that your phone found, to connect it. • To connect Wi-Fi networks, touch Menu > Settings > Wireless & networks > WLAN settings (then touch WLAN, if it is off). Touch a network that your phone found, to connect it.
Wi-Fi modes For those who like to get a bit more technical, your phone supports the following Wi-Fi modes: 802.11b, g, n. Jan. 12.
Security help keep your phone safe Quick start: Security From the home screen, touch Menu Location & security. Location & security settings Turn off ephemeris auto download > Settings > Set a lock pattern, PIN, or password required to wake up the screen. Screen unlock Set up screen lock Lock screen with a pattern, PIN, or password SIM card lock Set up SIM card lock Choose a number code required to turn on your phone. Passwords Visible passwords Show password as you type Jan. 12.
Troubleshooting we’re here to help Crash recovery In the unlikely event that your phone stops responding to touches and key presses, try a quick reset. Press and hold Power , then touch Restart, or remove the back cover and battery (“Assemble & charge” on page 6), then replace and turn on your phone as usual. Service & repairs If you have questions or need assistance, we're here to help. Go to www.motorola.com/support, where you can 12. 2012 care options. You can select from a number Jan.
