Enhanced Single Band Mobile Radio Installation Manual APRIL 2020 © 2020 Motorola Solutions, Inc.
MN005720A01-AB Contents Contents List of Figures..............................................................................................................7 List of Tables............................................................................................................. 11 Foreword ...................................................................................................................12 Copyrights.......................................................................................
MN005720A01-AB Contents 2.2.2 Remote Mount with Trunnion...................................................................................52 2.2.2.1 Remote Mount Control Head Installation................................................... 52 2.2.2.2 Multiple Control Head Installation.............................................................. 55 2.2.2.3 Cable Installation........................................................................................56 2.2.2.
MN005720A01-AB Contents 4.2.1 Installing Emergency Pushbutton or Footswitch...................................................... 86 4.2.2 Horn (External Alarm) Relay Installation..................................................................87 4.2.3 Lights (External Alarm) Relay Installation................................................................ 87 4.2.4 Gunlock Installation..................................................................................................87 4.2.
MN005720A01-AB Contents 5.4.2 Fuel Tank Console Installation with Speaker and Control Head Mounted Together.....................................................................................................................105 5.4.3 Handlebar Installation with Speaker and Control Head Mounted Separately........ 106 5.4.3.1 Installing Handlebar with Speaker and Control Head Mounted Separately....................................................................................................... 107 5.4.
MN005720A01-AB Contents Appendix A: Replacement Parts Ordering........................................................... 132 A.1 Service Information............................................................................................................. 133 A.2 Service Information – APAC................................................................................................134 Glossary.............................................................................................................
MN005720A01-AB List of Figures List of Figures Figure 1: Front and Side View of O5 Control Head with Dash Mount Transceiver and Trunnion.......... 20 Figure 2: Front and Side View of E5 Control Head with Dash Mount Transceiver and Trunnion...........20 Figure 3: Front and Side View of O2 Control Head with Dash Mount Transceiver and Trunnion.......... 21 Figure 4: Front and Side View of O7 Control Head with Dash Mount Transceiver and Trunnion..........
MN005720A01-AB List of Figures Figure 30: Radio Installation (O5 Dash Mount)...................................................................................... 35 Figure 31: Radio Installation (E5 Dash Mount).......................................................................................36 Figure 32: Radio Installation (O7 Dash Mount)...................................................................................... 36 Figure 33: Radio Installation (O2 Remote Mount)............................
MN005720A01-AB List of Figures Figure 68: Mini-UHF Connector Tool......................................................................................................69 Figure 69: GPS/GLONASS and Wi-Fi Antenna Connector on the radio................................................ 70 Figure 70: Speaker Mounting................................................................................................................. 71 Figure 71: Removing the screws on the Control Head................................
MN005720A01-AB List of Figures Figure 107: Enhanced Single Band Mobile Radio Antenna Band Identification...................................111 Figure 108: Routing the Coaxial Cable for GPS/Wi-Fi......................................................................... 112 Figure 109: Routing the Coaxial Cable for Antenna............................................................................. 112 Figure 110: Cable Routing...................................................................................
MN005720A01-AB List of Tables List of Tables Table 1: Tools Required for Radio Installations......................................................................................30 Table 2: Dash O2, O3, O5, O7, or O9 Radio Operations Dependent Upon A+ and Ignition Connections.......................................................................................................................................
MN005720A01-AB Foreword Foreword This manual includes all the information necessary to maintain peak product performance and maximum working time, using levels 1 and 2 maintenance procedures. CAUTION: These servicing instructions are for the use of qualified personnel only. To reduce the risk of electric shock, do not service parts other than those contained in the Operating Instructions unless you are qualified to do so. Refer all servicing to qualified service personnel.
MN005720A01-AB Copyrights Copyrights The Motorola Solutions products described in this document may include copyrighted Motorola Solutions computer programs. Laws in the United States and other countries preserve for Motorola Solutions certain exclusive rights for copyrighted computer programs.
MN005720A01-AB Notations Used in This Manual Notations Used in This Manual Throughout the text in this publication, you will notice the use of warning, caution, and notice notations. These notations are used to emphasize that safety hazards exist, and due care must be taken and observed. WARNING: WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or injury.
MN005720A01-AB Related Publications Related Publications The following list contains part numbers and titles of related publications.
MN005720A01-AB Commercial Warranty Commercial Warranty Limited Warranty For information on warranty terms, see the Support page at https://www.motorolasolutions.com. I. What This Warranty Covers And For How Long Motorola Solutions Inc.
MN005720A01-AB Commercial Warranty III. State Law Rights (Applicable Only in U.S.A.) Some states do not allow the exclusion or limitation of incidental or consequential damages or limitation on how long an implied warranty lasts, so the above limitation or exclusions may not apply. This warranty gives specific legal rights, and there may be other rights which may vary from state to state. IV.
MN005720A01-AB Commercial Warranty VI. Patent And Software Provisions Motorola Solutions will defend, at its own expense, any suit brought against the end user purchaser to the extent that it is based on a claim that the Product or parts infringe a United States patent, and Motorola Solutions will pay those costs and damages finally awarded against the end user purchaser in any such suit which are attributable to any such claim.
MN005720A01-AB Installation Requirements for Compliance with Radio Frequency (RF) Energy Exposure Safety Standards Notice Installation Requirements for Compliance with Radio Frequency (RF) Energy Exposure Safety Standards CAUTION: This radio is intended for use in occupational/controlled conditions, where users have full knowledge of their exposure and can exercise control over their exposure to meet FCC limits. This radio device is NOT authorized for general population, consumer, or any other use.
MN005720A01-AB Chapter 1: Introduction Chapter 1 Introduction This manual covers the installation procedures for ASTRO mobile and motorcycle radios with O2, O3, O5, E5, O7, and O9 control heads and accessories required to complete the radio system. The radio system consists of a control head, radio, antenna, microphone, speaker, cabling, Universal Relay Controller (URC), and accessories. 1.1 Mobile Radio Description This chapter covers the basic dimension of the mobile radio. 1.1.
MN005720A01-AB Chapter 1: Introduction Figure 3: Front and Side View of O2 Control Head with Dash Mount Transceiver and Trunnion 222 209 224 206 69 89 NOTICE: The rear accessory connector adds 0.75 in. to the overall length. The remote mount length is 194 mm.
MN005720A01-AB Chapter 1: Introduction Figure 6: Front and Side View of O2 Control Head with Remote Mount and Trunnion 209 123 97 99 Figure 7: Front and Side View of O5 Control Head with Remote Mount and Trunnion 75 180 51 Figure 8: Front and Side View of E5 Control Head with Remote Mount and Trunnion 180 82 51 Figure 9: Front and Side View of O7 Control Head with Remote Mount and Trunnion 209 108 178 82 91 22
MN005720A01-AB Chapter 1: Introduction Figure 10: Front and Side View of O9 Control Head with Trunnion 190 83 178 Figure 11: Top and Side View of O9 Universal Relay Controller (URC) with Trunnion (URC is an orderable accessory) 185 61.5 210 1.2 Standard Configurations This chapter covers the dash mount, remote mount, and multi-control head configurations. 1.2.1 Dash Mount Configuration There are two versions of the mobile dash mount.
MN005720A01-AB Chapter 1: Introduction Figure 12: Dash Mount Configuration for O2 Control Head 1 1 No. Description 1 ASTRO 25 Subscribers Enhanced Single Band Mobile Radio Figure 13: Dash Mount Configuration for O3 Control Head 1 1 No.
MN005720A01-AB Chapter 1: Introduction No. Description 1 ASTRO 25 Subscribers Enhanced Single Band Mobile Radio Figure 15: Dash Mount Configuration for E5 Control Head 1 No. Description 1 ASTRO 25 Subscribers Enhanced Single Band Mobile Radio Figure 16: Dash Mount Configuration for O7 Control Head 1 1 No. Description 1 ASTRO 25 Subscribers Enhanced Single Band Mobile Radio 1.2.
MN005720A01-AB Chapter 1: Introduction 1 Figure 17: Remote Mount Configuration with Mid Power Transceiver, Transceiver Interface Board, CHIB Rear Assembly, and O2 Control Head 1 2 2 2 2 No. Description 1 ASTRO 25 Subscribers Enhanced Single Band Mobile Radio 2 MMP Figure 18: Remote Mount Configuration with Mid Power Transceiver, Transceiver Interface Board, and O3 Control Head 2 1 No.
MN005720A01-AB Chapter 1: Introduction Figure 19: Remote Mount Configuration with Mid Power Transceiver, Transceiver Interface Board, CHIB Rear Assembly, and O5 Control Head 1 1 2 2 No. Description 1 ASTRO 25 Subscribers Enhanced Single Band Mobile Radio 2 MMP Figure 20: Remote Mount Configuration with Mid Power Transceiver, Transceiver Interface Board, CHIB Rear Assembly, and E5 Control Head 1 2 2 No.
