MISSION CRITICAL WIRELESS
89C85-B_Text.fm Page -1 Friday, September 17, 2010 7:42 PM MISSION CRITICAL WIRELESS TA B L E O F C O N T E N T S Foreword . . . . . . . . . . . . . . . . . . . . . . . ii Safety. . . . . . . . . . . . . . . . . . . . . . . . . .1 Introduction . . . . . . . . . . . . . . . . . . . . .4 What is in Your Package . . . . . . . . . . .5 Features. . . . . . . . . . . . . . . . . . . . . . . .7 Charging your Device . . . . . . . . . . . . .8 Powering On/Off Device . . . . . . . . . .10 Pairing Your Device . . .
89C85-B_Text.fm Page 0 Friday, September 17, 2010 7:42 PM FOREWORD Product Safety and RF Exposure Compliance ! Caution Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio. ATTENTION! The radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements.
89C85-B_Text.fm Page 1 Friday, September 17, 2010 7:42 PM Important information: • Do not recharge your accessory in temperatures below 0°C (32°F) or above 45°C (113°F)· Conditions inside a parked car can exceed this range. Do not store your accessory in a parked car. Do not store your accessory in direct sunlight. • Storing your fully charged accessory in high-temperature conditions may permanently reduce the life of the internal battery.
89C85-B_Text.fm Page 2 Friday, September 17, 2010 7:42 PM CAUTION This earpiece can be used in high noise environments. Before using the earpiece, please ensure that you have set the volume at the lowest level by holding the "VOLUME DOWN" button while the device is on. Do NOT set the device at the highest two volume levels unless needed for high noise environments. To avoid possible injury to your hearing, YOU MUST REDUCE the volume level to the lower six volume steps.
89C85-B_Text.fm Page 3 Friday, September 17, 2010 7:42 PM OTHER NOTES The minimum line-of-sight range for Secure Bluetooth Commport is 30 feet. However, the body tends to obstruct the signal, therefore the normal usage range is 6’ around your body. When the headset and adapter exceed the range of the wireless system, Mission Critical Device issues an alert sound, indicating that the wireless system is not operational. The link is automatically restored once the units are back within communication range.
89C85-B_Text.fm Page 4 Friday, September 17, 2010 7:42 PM INTRODUCTION We looked for a better way to enhance wireless security, and created a short range “out of band” system for exchanging device credentials. As a result, our proprietary Mission Critical Wireless Device pairs within an inch of the radio, and that exchange is virtually undetectable beyond a few inches. Because of the close pairing proximity, you can be confident your accessory is connecting with your radio.
9C85-B_Text.
89C85-B_Text.
89C85-B_Text.
89C85-B_Text.fm Page 8 Friday, September 17, 2010 7:42 PM CHARGING YOUR DEVICE Prior to using the device for the first time, it should be fully charged. Recommended charging time is three hours. You can charge your device using the charger cable connected to a wall power outlet. Connect the small end of the charger cable to the micro-USB port on the bottom of the device. Plug the other end of the cable into a wall outlet. The following chart provides battery and charging status.
89C85-B_Text.
89C85-B_Text.fm Page 10 Friday, September 17, 2010 7:42 PM POWERING ON/OFF DEVICE Press the power on/off button. Power LED Indication Tone Indication On Blue LED Flashes 3 times then OFF Power On Tone. Hold for 0.5 second. Off Blue LED Flashes 3 times then POWER OFF Power Off Tone. Hold for 3 seconds.
89C85-B_Text.fm Page 11 Friday, September 17, 2010 7:42 PM USING THE MISSION CRITICAL WIRELESS DEVICE PAIRING YOUR DEVICE 1. Ensure both the radio and the device are powered on. 2. Ensure the earpiece portion of the Secure Wireless Device is plugged into the pod portion Secure Wireless Device. 3. Confirm the Blue LED on the device is flashing. 4. Place the blue dot (secure pairing spot) on the device within one inch of the blue dot (secure pairing spot) on the radio. 5.
89C85-B_Text.
89C85-B_Text.fm Page 13 Friday, September 17, 2010 7:42 PM A device will not establish a connection with a previously paired radio automatically if the RE-PAIRING CYCLE parameter in the radio is set to “always re-pair”. In this case, the user must follow the procedure listed on page 11 to re-establish wireless connection. DARK MODE VOLUME INDICATORS The Mission Critical Wireless device has 8 loudness levels.
89C85-B_Text.
89C85-B_Text.fm Page 15 Friday, September 17, 2010 7:42 PM The device’s volume control buttons can also be used to stop repeating tone indications, such as low battery, critical battery, and link disconnections. ERROR INDICATOR Any product errors will be indicated by Amber Flashing or Solid light indicators. REPLACEMENT PARTS To order replacement parts, and for service and support, call 800-422-4210 The following parts are available : Maintenance Kit.........................
89C85-B_Text.fm Page 16 Friday, September 17, 2010 7:42 PM Wireless Accessory...................NTN2574 NTN2574 - Wireless Accessory, Near Field Pairing.
BackCover.fm Page 1 Thursday, September 16, 2010 7:26 PM m © 2010 by Motorola, Inc. b and Motorola are registered trademarks of Motorola Inc. All Rights Reserved.
