User's Guide SERIES TWO-WAY RADIO 1 *6864110W15* 6864110W15-D Models CLS1110 and CLS1410
Contents Introduction ...................................... 1 FCC Licensing Information ............. 3 RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use ........................ 5 Radio Controls ............................... 18 Getting Started ............................... 19 Installing the Swivel Belt Holster .. 19 Installing the Batteries .................. 20 Charging the Battery .................... 21 Turning Your Radio On and Off ....
ii Notes
Thank you for purchasing a Motorola _Series Radio. Your radio is a product of Motorola’s 85 plus years of experience as a world leader in designing and manufacturing communications equipment. The _Series radios provide costeffective communications for businesses such as retail stores, restaurants, hotels, and schools. Motorola professional two-way radios are the perfect communications solution for all of today’s fast-paced industries.
Introduction For product-related questions, please call: 1-800-448-6686 in the USA 1-888-390-6456 TTY (Text Telephone) On the Web: www.motorolasolutions.com/CLS 2 ATTENTION Before using this product, read the RF energy awareness information and operating instructions in the Safety and General Information section of this guide to ensure compliance with RF energy exposure limits.
Interference Information This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. _Series™ Business two-way radios operate on radio frequencies that are regulated by the Federal Communications Commission (FCC). To transmit on these frequencies, you are required to have a license issued by the FCC. Application is made available on FCC Form 601 and Schedules D, H, and Remittance Form 159.
FCC Licensing Information 4 Changes or modifications not expressly approved by Motorola may void the user’s authority granted by the FCC to operate this radio and should not be made. To comply with FCC requirements, transmitter adjustments should be made only by or under the supervision of a person certified as technically qualified to perform transmitter maintenance and repairs in the private land mobile and fixed services as certified by an organization representative of the user of those services.
NOTICE: This radio is intended for use in occupational/controlled conditions where users have full knowledge of their exposure and can exercise control over their exposure to meet the occupational limits in FCC and International standards. This radio device is NOT authorized for general population consumer use. This two-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance.
RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use 6 Please refer to the following websites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits: http://www.fcc.gov/oet/rfsafety/rf-faqs.html www.who.int/en/ www.motorolasolutions.
• United States Federal Communications Commission (FCC), Code of Federal Regulations; 47 CFR et seq. & FCC, OET Bulletin 65 • Institute of Electrical and Electronic Engineers (IEEE) C95.1 • International Commission on Non-Ionizing Radiation Protection (ICNIRP) • Ministry of Health (Canada) Safety Code 6 & Industry Canada RSS-102 • Australian Communications Authority Radiocommunications Standard et seq. • ANATEL ANNEX to Resolution No. 303 et seq.
RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use 8 • In front of the face. Hold the radio in a vertical position with the microphone (and other parts of the radio including the antenna) at least one inch (2.5 centimeters) away from the nose or lips. Keeping the radio at a proper distance is important to ensure compliance. NOTE: RF exposures decrease with increasing distance from the antenna. • Body Worn Operation.
When instructed to do so, turn off your radio when on board an aircraft. Any use of a radio must be in accordance with applicable regulations per airline crew instructions.
RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use 10 Use of Communication Devices While Driving Always check the laws and regulations on the use of radios in the areas where you drive. • Give full attention to driving and to the road. • Use hands-free operation, if available. • Pull off the road and park before making or answering a call, if driving conditions or regulations so require.
For Vehicle With Air Bags: WARNING Refer to vehicle manufacturer's manual prior to installation of electronic equipment to avoid interference with air bag wiring. DO NOT place a portable radio in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a portable radio is placed in the air bag deployment area and the air bag inflates, the radio may be propelled with great force and cause serious injury to occupants of the vehicle.
RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use 12 Operational Warnings (Continued) Potentially Explosive Atmospheres WARNING (Explosive atmospheres refers to hazard classified locations that may contain hazardous gas, vapors, or dusts.
Antennas Caution DO NOT use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result. Batteries All batteries can cause property damage and/or bodily injury, such as burns, if a conductive material such as jewelry, keys, or beaded chains touches exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot.
RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use 14 Operational Cautions for Intrinsic Safe Equipment • DO NOT operate radio communications equipment in a hazardous atmosphere unless it is a type especially qualified (for example, FM, UL, CSA, or CENELEC approved). An explosion or fire may result.
Repair REPAIRS FOR MOTOROLA PRODUCTS WITH INTRINSICALLY SAFE APPROVAL ARE THE RESPONSIBILITY OF THE USER. WARNING Repairs to a Motorola FM approved radio product should only be done at a location that has been FM audited under the FM 3605 repairs and service standard. Contact Motorola for assistance regarding repairs and service of Motorola intrinsically safe equipment.
RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use 16 A repair constitutes something done internally to the unit that would bring it back to its original condition. Items not considered as repairs are those in which an action is performed on a unit which does not require the outer casing of the unit to be opened in a manner that exposes the internal electrical circuits of the unit.
RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use Notes 17
Radio Controls Microphone Radio Controls Use P to: Turn radio on/off Adjust radio volume Use B to: Transmit call tone Accessory Jack Use Push to Talk to: Talk Exit a menu Use [ and ] to: Change channels Use T to: Monitor the frequency Scan channels (CLS1410 only) (CLS1410 only) Change menu settings Speaker Use S to: Lock the keypad Scroll through menus 18 020976o
Getting Started 1-800-448-6686 to request replacement part number HCLN4013. HCLN4013 Swivel Belt Holster 0310 Getting Started Installing the Swivel Belt Holster 1. Slide the bottom of the radio into the holster until it snaps into place. 2. To remove, push the tab on the holster and pull the radio away from the holster.
Getting Started 20 Installing the Batteries Your radio uses a rechargeable Lithium Ion (Li Ion) battery. Li Ion Battery 1. If the battery door is already in place, push down on the recess on the door and slide it off the radio. 2. Insert the battery, printed arrows first, into the battery compartment and press down to secure firmly in place. 3. Slide and snap the battery door into place.
holster on. Getting Started Charging the Battery Use only the charger supplied with the radio, or other _Series power accessories. For optimum battery life, do not charge the battery for prolonged periods after it is fully charged. Charging the battery over the weekend is acceptable. Using the Drop-in Charger 1. Place the charger on a flat surface. 2. Insert the plug of the power cord into the jack on the charger. 3. Plug the cord into an AC outlet. 4. Turn the radio off.
Getting Started 22 Using the 56531 Multi-Unit Charger The Multi-Unit Charger (MUC) allows drop-in charging of up to 6 radios or batteries. Batteries can be charged inside the radios or removed and placed in the MUC separately. Each of the 6 charging pockets can hold a radio or battery, but not both. 1. Place the charger on a flat surface. 2. Insert the power cord plug into the jack on the MUC. 3. Plug the cord into an AC outlet. 4. Turn the radio off. 5.
Battery Type Li Ion 3 Bars 2 Bars 1 Bar Blinking d b c m 100% – 85% 85% – 25% 25% – 10% Final 10% Getting Started Charging Status LEDs On the drop-in charger, the radio and battery charging pockets have their own LEDs. On the MUC, each of the 6 charging pockets has an LED. The LEDs are grouped into pairs to show which charging pockets are paired (for cloning, see page 37). The LED is solid red when the battery is charging, and solid green when charging is complete.
Turning Your Radio On and Off See page 18 for a basic radio diagram. Turn P clockwise to turn the radio on, and counterclockwise to turn the radio off. When the radio is on, the transmit light on the top of the radio blinks every 3 seconds. Getting Started When you turn the radio on, the radio chirps and the display briefly shows all features and display segments.
Adjusting the Volume Turn P clockwise to increase the volume, and counterclockwise to decrease the volume. Note: Do not hold the radio too close to your ear when adjusting the volume.
Talking and Receiving Basic Radio Operation Talking and Receiving 1. Press and hold T to check for channel activity. If you hear static, the channel is clear to use. Do not transmit if someone is speaking on the channel. Press T again to stop monitoring. 2. To talk, press and hold Push to Talk and speak into the microphone. Hold the radio 2 to 3 inches away from your mouth. 3. To listen, release Push to Talk. The transmit LED on the top of the radio is red when transmitting.
Industrial Multi-Level Inside steel/concrete industrial buildings Inside multi-level buildings Up to 200,000 sq. ft. Up to 15 floors Handsfree Use (VOX) (CLS1410 only) The CLS1410 model radio can operate handsfree when used with compatible voice activation (VOX) accessories. A short delay occurs between the time when you start talking and when the radio transmits. With Compatible VOX Accessories 1. Turn the radio off. 2. Open the accessory cover. 3.
6. To transmit, speak into the accessory microphone. To receive, stop talking. To disable VOX operation, press Push to Talk or remove the audio accessory. Note: To order accessories, visit www.motorolasolutions.com/CLS, call Talking and Receiving 1-800-448-6686, or contact your point of purchase. 28 Setting the VOX Sensitivity You can adjust the sensitivity of your radio’s accessory or microphone during VOX operation to suit different operating environments.
Scanning (CLS1410 Only) You can scan up to 4 channels and frequencies. When the radio detects activity, it stops scanning and locks in on the active channel. This allows you to talk and listen to the person transmitting without changing channels. 1. To start scanning, briefly press T. The scan icon h displays and the radio begins to scan the channels. When the radio detects activity, it stops on that channel and displays w and the channel number. 2.
Talking and Receiving 30 Skipping and Removing Channels While Scanning Scan has two temporary features to make it easier to use. • Scan advance If the radio stops scanning on a channel you do not want to listen to, press ] to resume scanning for the next active channel. • Nuisance delete Press and hold [ to temporarily remove a channel from the scan list. The channel return the next time you use the scan feature.
Programming mode allows you to change the following settings on your radio: • Channel • Configure the operating frequency from a pre-programmed frequency list • Interference eliminator code • Call tones • Microphone gain • Scan list (CLS1410 only) • Available channels (CLS1410 only) Note: • To talk with someone on your two-way radio, the channel (CLS1410 only), frequency, and • interference eliminator code must be the same on both radios.
Factory Default Settings Your radio is programmed at the factory to the following settings: Programming Mode Frequency Channel CLS1110 CLS1410 1 2 2 2 3 Not available 4 Code Call Tone/ VibraCall® VOX Microphone Gain 32 8 5 6 1 Off (0) Not available Off (0) 2 (medium sensitivity) To restore the factory settings, turn the radio on while holding Push to Talk and S for 3 seconds.
Entering Programming Mode Press and hold Push to Talk and T for 3 seconds while turning the radio on. The radio beeps and displays k , the channel number blinks, and the frequency (indicated by l) and code (indicated by y) display alternately. Note: If you press and release the Push to Talk button when programming CSL1410 radios. If you are matching your _ Series radio to an existing Spirit GT radio, see page 50. Programming Mode models, you will return to the front of the Programming Mode.
Programming Mode 34 Programming the Interference Eliminator Code The interference eliminator code helps minimize interference by providing code combinations that filter out static, noise, and unwanted messages. 1. In programming mode, press S until y displays and the code number blinks. 2. Press [or ] to select the code (see page 47). 3. Press and hold Push to Talk to exit programming mode, or press S to continue programming.
3. Press and hold Push to Talk to exit programming mode, or press S to continue programming. To transmit your call tone, press B on the side of the radio. Programming Mode Programming Call Tones and VibraCall® (CLS1410 only) Your radio can transmit call tones to other radios in your group so you can alert them that you are about to talk. Your radio is programmed at the factory with call tones turned off (set to 0), but you can change this setting to choose a distinctive call tone.
Programming Mode Programming Microphone Gain You can adjust the microphone sensitivity to suit different users or operating environments. 1. In programming mode, press S until g and ? display. 2. Press [ or ] to select the sensitivity level: 3 = High sensitivity, for quiet environments 2= Medium sensitivity (default) 1= Low sensitivity, for loud environments 3. Press and hold Push to Talk to exit programming mode, or press S to continue programming.
You can copy _ Series radio settings from one radio (the source) to a second radio using the 56531 Multi-Unit Charger (MUC) optional accessory. See the MUC User's Guide for more information. You can clone only one radio at a time. A multi-channel radio can clone to a singlechannel radio, but only the first channel is cloned. The MUC does not have to be plugged in for cloning, but both radios require charged batteries. 1.
Advanced Features You can set the following features by pressing and holding additional buttons while turning the radio on. Advanced Features To Do This 38 Press This Button Default While Turning Setting the Radio On Turn Keypad Tones On/Off Turns keypad beeps off for silent keypad operation. [ On Turn End-of-Transmission Tone On/Off If enabled, your two-way radio transmits a tone when you finish transmitting (like saying Roger or Over).
Press This Button Default While Turning Setting the Radio On Turn Battery Save Mode On/Off Decreases attack time, which is the brief period of time between when the radio receives a Push to Talk T [ transmission on its frequency and broadcasts audio. Turning battery save mode off decreases battery life by approximately 20%. On Restore Factory Defaults Returns radio to its original factory settings.
Troubleshooting Symptom Try This: No Power Recharge or replace Li Ion battery. Make sure Push to Talk is completely pressed while transmitting. Recharge, replace, and/or reposition batteries. Verify the transmit light is illuminated while speaking. Verify Channel, Frequency, and Code settings are correct. Troubleshooting Message not transmitted 40 Hearing other Frequency may be in use. Change on all radios if possible (see noises or conversation on page 33 and 34). a channel Bandwidth does not match.
Message not received Heavy static or interference Keypad locked Low batteries Charger light does not come on Try This: Confirm radios have the same channel, frequency, and interference eliminator code settings (see page 31). Recharge, replace, and/or reposition batteries. Move to another location. Obstructions and operating indoors or in vehicles may decrease range. Verify radio is not in scan mode (CLS1410 only, see page 29). Radios are too close. They must be at least 5 feet apart.
Symptom Troubleshooting Low battery meter reading although new batteries are installed 42 Try This: Verify radio is set to the correct battery type (see page 20). Cannot activate Feature not set and on (see page 27). VOX (CLS1410 Sensitivity set to 0 (see page 28). only) Verify that accessory allows VOX operation. Cannot enter Unplug audio accessories and retry.
Use and Care Use a soft damp cloth to clean the exterior. Do not immerse in water. Do not use alcohol or cleaning solutions. If the radio is submerged in water... Turn radio off and remove batteries. Dry with soft cloth. Use and Care XXX Do not use radio until completely dry.
Frequencies and Bandwidths Frequencies and Bandwidths 44 These charts provide frequency information and are useful when using Motorola _Series radios with other business radios. Frequency Display Number is identical to Spirit M, GT, and S-Series frequency position (where applicable), but bandwidth may be different. UHF Frequencies Display Number Frequency (MHz) Bandwidth Display Number Frequency (MHz) Bandwidth 1 464.5000 12.5 8 467.9250 12.5 2 464.5500 12.5 9 461.0375 12.5 3 467.
UHF Frequencies (Continued) Frequency (MHz) Bandwidth Display Number Frequency (MHz) Bandwidth 15 461.1875 12.5 26 462.8375 12.5 16 461.2125 12.5 27 462.8625 12.5 17 461.2375 12.5 28 462.8875 12.5 18 461.2625 12.5 29 462.9125 12.5 19 461.2875 12.5 30 464.4875 12.5 20 461.3125 12.5 31 464.5125 12.5 21 461.3375 12.5 32 464.5375 12.5 22 461.3625 12.5 33 464.5625 12.5 23 462.7625 12.5 34 466.0375 12.5 24 462.7875 12.5 35 466.0625 12.5 25 462.
UHF Frequencies (Continued) Frequencies and Bandwidths Display Number 46 Frequency (MHz) Bandwidth Display Number Frequency (MHz) Bandwidth 37 466.1125 12.5 47 466.3625 12.5 38 466.1375 12.5 48 467.7875 12.5 39 466.1625 12.5 49 467.8375 12.5 40 466.1875 12.5 50 467.8625 12.5 41 466.2125 12.5 51 467.8875 12.5 42 466.2375 12.5 52 467.9125 12.5 43 466.2625 12.5 53 469.4875 12.5 44 466.2875 12.5 54 469.5125 12.5 45 466.3125 12.5 55 469.5375 12.
Display Number Code (Hz) Display Number Code (Hz) Display Number Code (Hz) 1 67.0 14 107.2 27 167.9 2 71.9 15 110.9 28 173.8 3 74.4 16 114.8 29 179.9 4 77.0 17 118.8 30 186.2 5 79.7 18 123.0 31 192.8 6 82.5 19 127.3 32 203.5 7 85.4 20 131.8 33 210.7 8 88.5 21 136.5 34 218.1 9 91.5 22 141.3 35 225.7 10 94.8 23 146.2 36 233.6 11 97.4 24 151.4 37 241.8 12 100.0 25 156.7 38 250.3 13 103.5 26 162.
Frequencies and Bandwidths Digital Interference Eliminator Codes 48 Display Number Digital Code Display Number Digital Code Display Number Digital Code 39 023 54 115 69 223 40 025 55 116 70 226 41 026 56 125 71 243 42 031 57 131 72 244 43 032 58 132 73 245 44 043 59 134 74 251 45 047 60 143 75 261 46 051 61 152 76 263 47 054 62 155 77 265 48 065 63 156 78 271 49 071 64 162 79 306 50 072 65 165 80 311 51 073 66 172 81 315
Display Number Digital Code Display Number Digital Code Display Number Digital Code 84 346 97 465 110 632 85 351 98 466 111 654 86 364 99 503 112 662 87 365 100 506 113 664 88 371 101 516 114 703 89 411 102 532 115 712 90 412 103 546 116 723 91 413 104 565 117 731 92 423 105 606 118 732 93 431 106 612 119 734 94 432 107 624 120 743 95 445 108 627 121 754 96 464 109 631 Frequencies and Bandwidths Digital Interference Eliminato
Spirit GT Series Programming Spirit GT Series Programming 50 The _Series platform is designed to replace the Spirit GT Series radio. The first eight frequencies and 38 interference eliminator codes of _Series are compatible with Spirit GT Series. To program your _Series radio to talk with a Spirit GT Series, verify or change your Spirit GT settings as follows. To verify the frequency and code: 1. Press the Menu button 3 times. The channel number and frequency display. 2. Press Menu again.
Warranty Limited Warranty for Motorola Personal Communications Products Purchased in the United States and Canada Warranty What This Warranty Covers • Products. Defects in materials and workmanship in wireless cellular telephones, pagers, and/or two-way radios, and certain accessories that are sold with them, such as the battery, battery charger, and holster manufactured and/or sold by Motorola (Products). • Batteries.
• Repairs/Replacements. The warranty is for the balance of the original warranty or for 90 days from the date you receive it, whichever is longer. III. Who is Covered This warranty extends to the first end-user purchaser only. Warranty IV. What We Will Do to Correct Warranty Problems At no charge to you, we have the option to repair or replace the Products or software that do not conform to the warranty, or to refund the Products; purchase price.
VI. What This Warranty Does Not Cover • Products that are operated in combination with ancillary or peripheral equipment or software not furnished by Motorola for use with the Products (“ancillary equipment”), or any damage to the Products or ancillary equipment as a result of such use. Among other things, “ancillary equipment” includes batteries, chargers, adaptors, and power supplies not manufactured or supplied by Motorola. Any of these voids the warranty.
Warranty 54 • Rechargeable batteries that: (a) are charged by other than the Motorola-approved battery charger specified for charging such batteries; (b) have any broken seals or show evidence of tampering; (c) are used in equipment other than the Product for which they are specified; or (d) are charged and stored at temperatures greater than 60 degrees centigrade. Any of these voids the warranty.
Flat-rate repair rates may apply to Products not covered by this warranty. To obtain information about Products needing repairs that are not covered by this warranty, please call the telephone number previously listed. We will provide information on repair availability, rates, methods of payment, where to send the Products, etc. This is Motorola’s complete warranty for the Products, and states your exclusive remedies. This warranty is given in lieu of all other express warranties.
Warranty VIII. Patent and Software Provisions 56 At Motorola’s expense, we will defend you, and pay costs and damages that may be finally awarded against you, to the extent that a lawsuit is based on a claim that the Products directly infringe a United States patent.
Warranty Laws in the United States and other countries preserve for Motorola and other third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to reproduce in copies and distribute copies of such software. The software may be copied into, used in and redistributed with only those Products that are associated with such software.
_Series Programming Quick Reference To enter programming mode, press and hold Push to Talk and T for 3 seconds while turning the radio on. The radio beeps and displays k, the channel number blinks, and the frequency (indicated by l) and code (indicated by y) display alternately. Set the Channel* Press [ or ]. Set the Frequency Press S until l displays. Press [ or ] to change the frequency. Set the Interference Eliminator Code Press S until ydisplays. Press [ or ] to change the code.
_Series Programming Quick Reference Press S until E displays. Set a Call Tone Press [ or ] to select 1 , 2 , or 3 for audible call tones, 4 for VibraCall, or 0 for off (default). Press S until g and ? display. Set the Microphone Gain Press [ or ] to select: 1 Low sensitivity 2 Medium sensitivity 3 High sensitivity Press S until h displays and the channel number and Y or n blink.
Notes
M Motorola Solutions, Inc. 1303 E. Algonquin Rd. Schaumburg, IL 60196-1078 U.S.A. MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. © 2003 – 2010, 2014 Motorola Solutions, Inc. All rights reserved. Printed in Malaysia.
