PROFESSIONAL DIGITAL TWO-WAY RADIO MOTOTRBO™ DP4400/DP4401 NON-DISPLAY PORTABLE USER GUIDE en de-DE fr-FR it-IT es-ES tr pl ru ar
Software Version..............................9 Identifying Radio Controls............ 18 Contents Contents Important Safety Information..........8 Charging the Battery......................................14 Attaching the Battery..................................... 14 Attaching the Antenna................................... 15 Attaching the Belt Clip................................... 15 Attaching the Universal Connector Cover (Dust Cover).............................................
LED Indicator........................... 23 Audio Tones............................. 25 Indicator Tones........................ 25 Switching Between Conventional Analog and Digital Mode................25 IP Site Connect ...............................26 Capacity Plus ..................................27 Linked Capacity Plus ...................... 27 Making and Receiving Calls in Non-Connect Plus Mode.................................... 29 Contents Selecting a Zone.................................
Reinitiating an Emergency Mode................................... 45 Exiting Emergency Mode After Sending the Emergency Alarm............... 46 Text Message Features ..................... 46 Sending a Quick Text Message with the One Touch Access Button.......... 46 Privacy ............................................46 Multi-Site Controls .......................... 47 Starting an Automatic Site Search.................................47 Stopping an Automatic Site Search.................................
Contents Switching Audio Route between Internal Radio Speaker and Bluetooth Device................................. 51 Permanent Bluetooth Discoverable Mode............. 51 Auto-Range Transponder System (ARTS) .......................................51 Over-the-Air-Programming (OTAP).... 51 Utilities................................................ 52 Setting the Power Level........... 52 Turning the Option Board Feature(s) On or Off............
Making and Receiving Calls in Connect Plus Mode........ 63 Selecting a Site................................... 63 Roam Request......................... 63 Site Lock On/Off.......................63 Selecting a Zone................................. 63 Using Multiple Networks..................... 64 Selecting a Call Type.......................... 64 Receiving and Responding to a Radio Call...................................... 64 Receiving and Responding to a Group Call....................
Contents Escalating Alarm Tone Volume................................ 73 Call Alert Operation.............................73 Receiving and Responding to a Call Alert...................... 74 Making a Call Alert with the One Touch Access Button..................................74 Emergency Operation......................... 74 Responding to an Emergency Call...................75 Initiating an Emergency Call.... 76 Initiating an Emergency Call with Voice to Follow............
Contents Turning the Acoustic Feedback Suppressor Feature On or Off................ 85 Turning the Global Positioning System (GPS) On or Off.................. 85 Batteries and Chargers Warranty........... 86 The Workmanship Warranty.......................... 86 The Capacity Warranty.................................. 86 Limited Warranty......................................87 MOTOROLA COMMUNICATION PRODUCTS............................................. 87 I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG:.....
Important Safety Information RF Energy Exposure and Product Safety Guide for Portable Two-Way Radios Important Safety Information ATTENTION! This radio is restricted to Occupational use only. Before using the radio, read the RF Energy Exposure and Product Safety Guide for Portable Two-Way Radios which contains important operating instructions for safe usage and RF energy awareness and control for Compliance with applicable standards and Regulations.
Software Version Software Version All the features described in the following sections are supported by the radio's software version R02.40.00 or later. Check with your dealer or system administrator for more details of all the features supported.
Computer Software Copyrights Computer Software Copyrights The Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program.
The MOTOTRBO Series Digital Portable radio meets IP57 specifications, allowing the radio to withstand adverse field conditions such as being submersed in water. • • • • If the radio has been submersed in water, shake the radio well to remove any water that may be trapped inside the speaker grille and microphone port. Trapped water could cause decreased audio performance.
Getting Started How to Use This Guide This User Guide covers the basic operation of the MOTOTRBO Portables. However, your dealer or system administrator may have customized your radio for your specific needs. Check with your dealer or system administrator for more information. Throughout this publication, the icons described next are used to indicate features supported in either the conventional Analog mode or conventional Digital mode: Getting Started Indicates a conventional Analog ModeOnly feature.
• What are the best radio usage practices for effective communication? What maintenance procedures will help promote longer radio life? Getting Started • 13 English
Preparing Your Radio for Use Charging the Battery Preparing Your Radio for Use For best performance, your radio is powered by a Motorola-approved Nickel Metal-Hydride (NiMH) or Lithium-Ion (Li-lon) battery. To avoid damage and to ensure compliance with warranty terms, charge the battery using a Motorola charger exactly as described in the charger user guide. It is recommended your radio remains powered off while charging. Charge a new battery 14 to 16 hours before initial use for best performance.
Caution: If antenna needs to be replaced, ensure that only MOTOTRBO antennas are used. Neglecting this will damage your radio. Preparing Your Radio for Use Attaching the Antenna Attaching the Belt Clip 1 To attach the belt clip, align the grooves on the clip with those on the battery and press downward until you hear a click. 1 With the radio turned off, set the antenna in its receptacle and turn clockwise. 2 To remove the antenna, turn the antenna counterclockwise.
Attaching the Universal Connector Cover (Dust Cover) The universal connector ( ) is located on the antenna side of the radio. It is used to connect MOTOTRBO accessories to the radio. To remove the universal connector cover, press down on the cover and turn the thumbscrew counterclockwise. Replace the dust cover when the universal connector is not in use. Powering Up the Radio Rotate the On/Off/Volume Control Knob clockwise until you hear a click. You see a welcome message or welcome image.
Preparing Your Radio for Use A brief tone sounds, indicating that the power up test is successful. Note: There is no power up tone if the radio tones/ alerts function is disabled (see Turning the Radio Tones/Alerts On or Off on page 53). If your radio does not power up, check your battery. Make sure that it is charged and properly attached. If your radio still does not power up, contact your dealer. To turn off the radio, rotate this knob counterclockwise until you hear a click.
Identifying Radio Controls Radio Controls 1 2 3 4 5 6 12 11 10 9 8 Identifying Radio Controls 7 1 2 3 4 5 18 1 Channel Selector Knob On/Off/Volume Control Knob LED Indicator Side Button 1[1] Push-to-Talk (PTT) Button These buttons are programmable.
Non-Connect Plus Operations Non-Connect Plus Operations 19 English
Additional Radio Controls in Non-Connect Plus Mode Additional Radio Controls in NonConnect Plus Mode Push-To-Talk (PTT) Button The PTT button on the side of the radio ( ) serves two basic purposes: A • The microphone is activated when the PTT button is pressed. While a call is not in progress, the PTT button is used to make a new call (see Making a Radio Call on page 33). If the Talk Permit Tone or the PTT Sidetone is enabled, wait until the short alert tone ends before talking.
• Short press – Pressing and releasing rapidly. Long press – Pressing and holding for the programmed duration. Hold down – Keeping the button pressed. Note: The programmed duration of a button press is applicable for all assignable radio/utility functions or settings. See Emergency Operation on page 42 for more information on the programmed duration of the Emergency button. Assignable Radio Functions Audio Toggle Toggles audio routing between the internal radio speaker and the speaker of wired accessory.
Additional Radio Controls in Non-Connect Plus Mode Nuisance Channel Delete[2] Temporarily removes an unwanted channel, except for the Selected Channel, from the scan list. The Selected Channel refers to the user’s selected zone/channel combination from which scan is initiated. Scan[2] Toggles scan on or off. Site Info Plays site announcement voice messages for the current site (this function is unavailable when Voice Announcement is disabled).
Voice Announcement On/Off Toggles voice announcement on or off. Voice Operating Transmission (VOX) Toggles VOX on or off. Zone Allows selection from a list of zones. LED Indicator Additional Radio Controls in Non-Connect Plus Mode unavailable when Voice Announcement is disabled. The LED indicator ( ) shows the operational status of your radio. A Assignable Settings or Utility Functions All Tones/ Alerts Toggles all tones and alerts on or off.
Additional Radio Controls in Non-Connect Plus Mode with Auto-Range Transponder System. Solid yellow Blinking yellow Double blinking yellow 24 English Radio is monitoring a conventional channel or in Bluetooth Discoverable Mode. Also indicates fair battery charge when programmable button is pressed. Radio is scanning for activity or receiving a Call Alert, flexible receive list is enabled or all local Linked Capacity Plus channels are busy.
For Capacity Plus and Linked Capacity Plus, there is no LED indication when the radio is detecting activity over the air. Audio Tones High pitched tone Low pitched tone Positive Indicator Tone Negative Indicator Tone Audio tones provide you with audible indications of the status, or response to data received on the radio. Continuous Tone Indicator Tones Additional Radio Controls in Non-Connect Plus Mode this activity may or may not affect the radio's programmed channel. A monotone sound.
IP Site Connect Additional Radio Controls in Non-Connect Plus Mode A When switching from digital to analog mode, certain features are unavailable. Icons for the digital features (such as Messages) reflect this change by appearing ‘grayed out’. Disabled features are hidden in the menu. Your radio also has features available in both analog and digital mode. However, the minor differences in the way each feature works does not affect the performance of your radio.
A roam list supports a maximum of 16 channels (including the Selected Channel). Note: You cannot manually add or delete an entry to the roam list. Check with your dealer or system administrator for more information. Capacity Plus Capacity Plus is a single-site trunking configuration of the MOTOTRBO radio system, which uses a pool of channels to support hundreds of users and up to 254 Groups.
Additional Radio Controls in Non-Connect Plus Mode If the radio is set to do this automatically, it scans through all available sites when the signal from the current site is weak or when the radio is unable to detect any signal from the current site. It then locks on to the repeater with the strongest Received Signal Strength Indicator (RSSI) value.
Selecting a Zone channel may have been programmed differently to support different groups of users or supplied with different features. After selecting the relevant Zone, select the relevant channel you require to transmit or receive on. Making and Receiving Calls in Non-Connect Plus Mode Making and Receiving Calls in NonConnect Plus Mode A zone is a group of channels. Your radio supports up to 32 channels and 2 zones, with a maximum of 16 channels per zone. 1 Access the Zone feature.
Making and Receiving Calls in Non-Connect Plus Mode The LED lights up solid green while the radio is transmitting and blinks green when the radio is receiving. Note: The LED lights up solid green while the radio is transmitting and double blinks green when the radio is receiving a privacy-enabled call.
1 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from your mouth. • • If the Channel Free Indication feature is enabled, you hear a short alert tone the moment the transmitting radio releases the PTT button, indicating the channel is free for you to respond. Press the PTT button to respond. If the Voice Interrupt feature is enabled, press the PTT button to stop the current call from the transmitting radio and free the channel for you to talk/respond. The LED lights up solid green.
Making and Receiving Calls in Non-Connect Plus Mode Receiving and Responding to a Selective Call A Selective Call is a call from an individual radio to another individual radio. It is a Private Call on an analog system. When you receive a Selective Call, the LED blinks green. Your radio unmutes and the incoming call sounds through the radio's speaker. 1 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from your mouth. 2 Press the PTT button to respond to the call. The LED lights up solid green.
Making a Radio Call Making a Group Call To make a call to a group of users, your radio must be configured as part of that group. 1 Do one of the following. After selecting your channel, you can select a subscriber alias or ID, or group alias or ID by using: • • The Channel Selector Knob. A programmed One Touch Access button – The One Touch Access feature allows you to make a Group or Private Call to a predefined ID easily. This feature can be assigned to a short or long programmable button press.
Making and Receiving Calls in Non-Connect Plus Mode If there is no voice activity for a predetermined period of time, the call ends. • Making a Private Call While you can receive and/or respond to a Private Call initiated by an authorized individual radio, your radio must be programmed for you to initiate a Private Call. There are two types of Private Calls. The first type, where a radio presence check is performed prior to setting up the call, while the other sets up the call immediately.
Making an All Call This feature allows you to transmit to all users on the channel. Your radio must be programmed to allow you to use this feature. Users on the channel cannot respond to an All Call. 1 Select the channel with the active All Call group alias or ID. See Selecting a Channel on page 29. 2 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from your mouth. 3 Press the PTT button to make the call. The LED lights up solid green.
Making and Receiving Calls in Non-Connect Plus Mode the transmitting radio releases the PTT button, indicating the channel is free for you to respond. Press the PTT button to respond. If there is no voice activity for a predetermined period of time, the call ends. Making a Phone Call Note: When you attempt to make or end a Phone Call without the access and deaccess codes preconfigured, the attempt fails and a negative indicator tone sounds.
microphone” condition where the PTT button is inadvertently pressed by the user. 3 Press the PTT button to make the call. Your radio must be programmed to allow you to use this feature. The LED lights up solid green. 4 Wait for the Talk Permit Tone to finish (if enabled) and speak clearly into the microphone. 5 Release the PTT button to listen. When the target radio responds, the LED blinks green.
This is called “talkaround”. Making and Receiving Calls in Non-Connect Plus Mode Note: This feature is not applicable in Capacity Plus and Linked Capacity Plus. The Talkaround setting is retained even after powering down. Press the programmed Repeater/Talkaround button. You hear ... Indicating ... Positive Indicator Radio is in Talkaround mode. Tone Negative Indicator Tone Radio is in Repeater mode.
Scan Lists Scan lists are created and assigned to individual channels/groups. Your radio scans for voice activity by cycling through the channel/group sequence specified in the scan list for the current channel/ group. Your radio can support up to 250 scan lists, with a maximum of 16 members in a list. Each scan list supports a mixture of both analog and digital entries. Note: This feature is not applicable in Capacity Plus and Linked Capacity Plus.
The LED blinks yellow and you hear a positive indicator tone, when Scan is enabled. Advanced Features in Non-Connect Plus Mode The LED turns off and you hear a negative indicator tone, when Scan is disabled. Responding to a Transmission During a Scan During scanning, your radio stops on a channel/group where activity is detected. The radio stays on that channel for a programmed time period known as “hang time”. 1 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from your mouth.
Change the channel via the Channel Selector Knob. Vote Scan Vote Scan provides you with wide area coverage in areas where there are multiple base stations transmitting identical information on different analog channels. Your radio scans analog channels of multiple base stations and performs a voting process to select the strongest received signal. Once that is established, your radio unmutes to transmissions from that base station. The LED blinks yellow during the Vote Scan operation.
Emergency Operation Advanced Features in Non-Connect Plus Mode An Emergency Alarm is used to indicate a critical situation. You are able to initiate an Emergency at any time, in any state, even when there is activity on the current channel. Your dealer can set the duration of a button press for the programmed Emergency button, except for long press, which is similar with all other buttons: Short press Between 0.05 seconds and 0.75 seconds. Long press Between 1.00 second and 3.75 seconds.
• • • Press the PTT button to call the group of radios which received the Emergency Alarm. Press any programmable button. Exit Emergency mode. Note: Your radio automatically acknowledges the Emergency Alarm (if enabled). Exiting Emergency Mode After Receiving the Emergency Alarm Exit the Emergency mode by performing one of the following actions: • • • • Changing the channel. Powering down the radio. Pressing the Emergency Off button. Pressing the Emergency On button.
Advanced Features in Non-Connect Plus Mode If your radio is set to Silent, it does not display any audio or visual indicators during Emergency mode, or allow any received calls to sound through the radio’s speaker, until you press the PTT button to initiate the call. If your radio is set to Silent with Voice, it does not display any audio or visual indicators during Emergency mode, but allow incoming calls to sound through the radio’s speaker.
If you press the PTT button during the programmed receiving period, you hear a prohibit tone, indicating that you should release the PTT button. The radio ignores the PTT press and remains in Emergency mode. Note: If you press the PTT button during hot mic, and continue to press it after the hot mic duration expires, the radio continues to transmit until you release the PTT button.
There are two instances where this can happen: Advanced Features in Non-Connect Plus Mode • • You change the channel while the radio is in Emergency mode. This exits the Emergency mode. If Emergency Alarm is enabled on this new channel, the radio reinitiates Emergency. You press the programmed Emergency On button during an Emergency initiation/transmission state. This causes the radio to exit this state, and to reinitiate Emergency.
Your radio supports two types of privacy: • • Basic Privacy. Enhanced Privacy. Only one of the privacy types above can be assigned to the radio. To unscramble a privacy-enabled call or data transmission, your radio must be programmed to have the same Privacy Key (for Basic Privacy), or the same Key Value and Key ID (for Enhanced Privacy) as the transmitting radio.
If the current channel is a multi-site channel with an attached roam list and is out of range, the radio also performs an automatic site search (site is unlocked) during: Advanced Features in Non-Connect Plus Mode • • a PTT button press. data transmission. A tone sounds. The LED blinks yellow rapidly when the radio is actively searching for a new site, and turns off once the radio locks on to a site.
Password Lock Features If enabled, this feature only allows you access your radio if the correct password is entered upon powering up. Use the Channel Selector Knob and the three Side Buttons to enter password (see Radio Controls on page 18). • • Channel Selector Knob positions 1 to 9 represent numbers 1 to 9; position 10 represents the number 0. Side Buttons 1 to 3 represent numbers 1 to 3. Accessing the Radio from Password 1 Power up your radio. You hear a continuous tone.
2 Wait for 15 minutes. Your radio restarts the 15 minutes timer for locked state when you power up. Advanced Features in Non-Connect Plus Mode 3 Repeat Steps 1 and 2 in Accessing the Radio from Password on page 49. Bluetooth Operation Note: If disabled via the CPS, all Bluetooth-related features are disabled and the Bluetooth device database is erased. This feature allows you to use your radio with a Bluetooth-enabled device (accessory) via a wireless Bluetooth connection.
You can toggle audio routing between internal radio speaker and external Bluetooth-enabled accessory. Press the programmed Bluetooth Audio Switch button. ARTS-equipped radios transmit or receive signals periodically to confirm that they are within range of each other. Your dealer can program your radio to transmit or receive the ARTS signal. Your radio provides indications of states as follows: • • A tone sounds when the audio route has switched.
Turning the Voice Operating Transmission (VOX) Feature On or Off Utilities Setting the Power Level Advanced Features in Non-Connect Plus Mode You can customize your radio’s power setting to high or low for each channel. High enables communication with radios located at a considerable distance from you. Low enables communication with radios in closer proximity. Press the programmed Power Level button. Tone heard ... Radio transmitting at ...
You can enable and disable all radio tones and alerts (except for the incoming Emergency alert tone) if needed. Press the programmed All Tones/Alerts button. Tone heard ... Indication Positive Indicator tone All tones and alerts are ON. Negative Indicator tone All tones and alerts are OFF. Checking the Battery Strength You can check how much battery power you have left. Press the programmed Battery Strength button to view the battery strength via the LED indicator.
This feature enables the radio to audibly indicate the content of the most recent received text message. Press the programmed Text-to-Speech button to listen to the received text message. Advanced Features in Non-Connect Plus Mode Switching Audio Route between Internal Radio Speaker and Wired Accessory You can toggle audio routing between the internal radio speaker and the speaker of wired accessory provided that: • • The wired accessory with speaker is attached.
The LED turns off and you hear a negative indicator tone, when Flexible Receive List is disabled. Advanced Features in Non-Connect Plus Mode programmed Trill Enhancement On/Off button to toggle trill enhancement on or off. Turning the Global Positioning System (GPS) On or Off GPS is a satellite navigation system that determines the radio’s precise location. Note: Selected radio models may offer GPS and Global Navigation Satellite System (GNSS).
Connect Plus Operations Connect Plus Operations 56 English
Push-To-Talk (PTT) Button The PTT button on the side of the radio ( ) serves two basic purposes: • The microphone is activated when the PTT button is pressed. While a call is not in progress, the PTT button is used to make a new call (see Making a Radio Call on page 67). Additional Radio Controls in Connect Plus Mode Additional Radio Controls in Connect Plus Mode If the Talk Permit Tone is enabled, wait until the short alert tone ends before talking.
Additional Radio Controls in Connect Plus Mode Assignable Radio Functions Beacon On/Off Toggles the Beacon feature on or off. Requires purchase of Connect Plus Man Down feature. Beacon Reset Resets (cancels) the Beacon tone, but it does not turn the Beacon feature off. Requires purchase of Connect Plus Man Down feature. Bluetooth® Audio Switch Toggles audio routing between internal radio speaker and external Bluetooth-enabled accessory.
Toggles the internal microphone automatic gain control (AGC) on or off. Voice Announcement On/Off Toggles voice announcement on or off. One Touch Access Directly initiates a predefined Private Call, a Call Alert or a Quick Text message. Zone Toggle Allows radio user to toggle between Zone 1 and Zone 2. Phone Exit Ends a Phone Call. Privacy Toggles privacy on or off. Roam Request Assignable Settings or Utility Functions AF Suppressor Toggles the Acoustic Feedback Suppressor feature on or off.
Unassigned Indicates that the button function has not yet been assigned. Additional Radio Controls in Connect Plus Mode Identifying Status Indicators in Connect Plus Mode LED Indicator transmission or has failed the selftest upon powering up, or has moved out of range if radio is configured with Auto-Range Transponder System.
Radio is powering up or transmitting. Also indicates full charge of the battery when the programmed Battery Strength button is pressed. Blinking green Radio is powering up, receiving a non-privacy- enabled call or data. Double blinking green Radio is receiving a privacy-enabled call. Continuous Tone A monotone sound. Sounds continuously until termination. Periodic Tone Sounds periodically depending on the duration set by the radio. Tone starts, stops, and repeats itself.
Additional Radio Controls in Connect Plus Mode what features are available while operating in nonConnect Plus zones.
Selecting a Site A site provides coverage for a specific area. A Connect Plus site has a site controller and a maximum of 15 repeaters. In a multi-site network, the Connect Plus radio will automatically search for a new site when the signal level from the current site drops to an unacceptable level. Site Lock On/Off When toggled on, the radio searches the current site only. When toggled off, the radio searches other sites in addition to the current site. Press the programmed Site Lock button.
Making and Receiving Calls in Connect Plus Mode • • • Multigroup Call Site All Call Private Call Access the Zone feature by performing one of the following actions:Press the programmed Zone button. the Registration Group ID that has been programmed for the new Channel Selector Knob position call type. If you select a position that has no call type assigned to it, your radio sounds a continuous tone.
Note: The LED lights up solid green while the radio is transmitting and double blinks green when the radio is receiving a privacy-enabled call. To unscramble a privacy-enabled call, your radio must have the same Privacy Key, OR the same Key Value and Key ID (programmed by your dealer), as the transmitting radio (the radio you are receiving the call from). Note: See Privacy on page 81 for more information. Receiving and Responding to a Group Call 3 Release the PTT button to listen.
If there is no voice activity for a predetermined period of time, the call ends. Making and Receiving Calls in Connect Plus Mode You hear a short tone. See Making a Private Call on page 67 for details on making a Private Call. Receiving a Site All Call A Site All Call is a call from an individual radio to every radio on the site. It is used to make important announcements requiring the user’s full attention. When you receive an Site All Call, a tone sounds and the LED blinks green.
Making a Radio Call After selecting your channel, you can select a subscriber alias or ID, or group alias or ID by using: • • The Channel Selector Knob. A programmed One Touch Access button – The One Touch Access feature allows you to make a Private Call to a predefined ID easily. This feature can be assigned to a short or long programmable button press. You can ONLY have one ID assigned to a One Touch Access button. Your radio can have multiple One Touch Access buttons programmed.
radio must be programmed for you to initiate a Private Call. Making and Receiving Calls in Connect Plus Mode You will hear a negative indicator tone, when you make a Private Call via the One Touch Access button, if this feature is not enabled. Use the Quick Text Message or Call Alert features to contact an individual radio. See Text Message Features on page 81 or Call Alert Operation on page 41 for more information. 1 Do one of the following.
Making a Multi-group Call This feature allows you to transmit to all users on multiple groups. Your radio must be programmed to allow you to use this feature. Note: Users on the groups cannot respond to a Multigroup Call. You can ONLY have one alias or ID assigned to a One Touch Call button. Your radio can have multiple One Touch Call buttons programmed. 1 Press the programmed One Touch Call button to make a Private Call to the pre-defined Private Call alias or ID.
Advanced Features in Connect Plus Mode Auto Fallback Advanced Features in Connect Plus Mode Auto Fallback is a system feature that allows you to continue to make and receive non-emergency calls on the selected Group Contact in the event of certain types of Connect Plus system failures. If one of these failures occurs, your radio attempts to roam to a different Connect Plus site.
Making calls in Fallback mode is similar to normal functioning. Simply select the group contact you wish to use (using the radio’s normal channel selection method), and then press the PTT to start your call. It is possible that the channel may be in use already by another group. If the channel is in use, you receive a busy tone. You may select Group, Multi-group or Site All Call contacts using your radio’s normal channel selection method.
Responding to a Transmission During a Scan During scanning, your radio stops on a group where activity is detected. The radio continuously listens for any member in the scan list when idle on the control channel. Advanced Features in Connect Plus Mode 1 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from your mouth. 2 Press the PTT button during hang time. The LED lights up solid green. 3 Wait for the Talk Permit Tone to finish (if enabled), and speak clearly into the microphone.
No member of the scanned group is registered at your site (Multisite systems only). Scan Talkback If your radio scans into a call from the selectable group scan list, and if the PTT button is pressed during the scanned call, the operation of the radio depends on whether Scan Talkback was enabled or disabled during radio programming. For more information on how your radio is programmed, contact your radio dealer (or your radio system administrator).
Receiving and Responding to a Call Alert When you receive a Call Alert page, you hear a repetitive tone and the LED blinks yellow. Making a Call Alert with the One Touch Access Button Advanced Features in Connect Plus Mode Press the programmed One Touch Access button to make a Call Alert to the predefined alias. The LED lights up solid green when your radio is sending the Call Alert. If the Call Alert acknowledgement is received, a positive indicator tone sounds.
• • If the short press for the Emergency button is assigned to turn on the Emergency mode, then the long press for the Emergency button is assigned to exit the Emergency mode. If the long press for the Emergency button is assigned to turn on the Emergency mode, then the short press for the Emergency button is assigned to exit the Emergency mode.
Initiating an Emergency Call Note: If your radio is set to Silent, it does not display any audio or visual indicators during Emergency mode until you press the PTT button to initiate a voice transmission. Advanced Features in Connect Plus Mode If your radio is set to Silent with Voice, it does not initially display any audio or visual indicators that the radio is in Emergency mode. However, your radio unmutes for the transmissions of radios responding to your emergency.
4 Press and hold the PTT button to talk longer than the programmed duration. Initiating an Emergency Alert Note: If your radio is programmed for “Silent” or “Silent with Voice”, it will not provide any audio or visual indications that it is sending an Emergency Alert. If programmed for “Silent”, the silent operation continues indefinitely until you press PTT or the button configured for “Emergency Off”.
discontinued after the Emergency Call Hang Time expires. Man Down Alarms Advanced Features in Connect Plus Mode Note: Man Down Alarms are not supported when operating in Fallback mode. For more information see the Auto Fallback on page 70. This section describes the Connect Plus Man Down Feature. This is a purchasable feature that may or may not apply to your radio. Your Connect Plus portable radio can be enabled and programmed for one or more of the Man Down Alarms.
Your dealer or radio system administrator can tell you which of the above alarms (if any) has been enabled through radio programming. It is possible to enable both the Tilt and Anti- Movement Alarms. In that case, the Alert Tone plays when the radio detects the first movement violation. Instead of taking the corrective actions discussed above, you can also prevent the radio from starting the Emergency call or Emergency Alert by using a programmable button, if your radio has been configured in this manner.
Beacon Feature Advanced Features in Connect Plus Mode This section describes the Beacon feature. The Beacon feature is part of Connect Plus Man Down, a purchasable feature. Your dealer or Radio System Administrator can tell you if the Beacon feature applies to your radio. If your radio has been enabled and programmed for one or more of the Man Down Alarms, it can also be enabled for the Beacon feature.
Text Message Features Sending a Quick Text Message with the One Touch Access Button Press the programmed One Touch Access button to send a predefined Quick Text message to a predefined alias. The green LED lights up. If the message is sent, a tone sounds. If the message cannot be sent, a low tone sounds. Privacy If enabled, this feature helps to prevent eavesdropping by unauthorized users on a channel by the use of a software-based scrambling solution.
Making a Privacy-Enabled (Scrambled) Call Advanced Features in Connect Plus Mode Toggle privacy on using the programmed privacy button. Your radio must have the Privacy feature enabled for the currently selected channel position to send a privacy-enabled transmission. When privacy is enabled for the currently selected channel position, all voice transmissions made by your radio will be scrambled.
Do not turn off your Bluetooth-enabled device during the finding and connecting operation as this cancels the operation. The radio connects to the Bluetooth-enabled device within range with either the strongest signal strength, or to one which it has connected to before in a prior session. 1 Turn on your Bluetooth-enabled device and place it in pairing mode. Refer to respective Bluetoothenabled device’s user manual. 2 On your radio, press the programmed Bluetooth Connect button.
Other Bluetooth-enabled devices can locate your radio, but the devices cannot connect to the radio. It enables dedicated devices to use your radio position in the process of Bluetooth-based location. Press the programmed Power Level button. Advanced Features in Connect Plus Mode Utilities Turning the Radio Tones/Alerts On or Off You can enable and disable all radio tones and alerts (except for the incoming Emergency alert tone) if needed. Press the programmed All Tones/Alerts button. Tone heard ...
LED indicator Indication Solid Yellow Radio has a fair battery charge. Solid Green Radio has a full battery charge. Intelligent Audio Your radio can automatically adjust its audio volume to overcome background noise in the environment, inclusive of all stationary and non-stationary noise sources. This feature is a Receive-only feature and does not affect Transmit audio. Press the programmed Acoustic Feedback Suppressor button.
Batteries and Chargers Warranty The Workmanship Warranty Batteries and Chargers Warranty The workmanship warranty guarantees against defects in workmanship under normal use and service. All MOTOTRBO Batteries 24 Months IMPRES Chargers (Single-Unit and MultiUnit, Non-Display) 24 Months IMPRES Chargers (MultiUnit with Display) 12 Months The Capacity Warranty The capacity warranty guarantees 80% of the rated capacity for the warranty duration.
MOTOROLA COMMUNICATION PRODUCTS I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG: MOTOROLA SOLUTIONS, INC.
operation of the system as a whole under this warranty. II. GENERAL PROVISIONS: Limited Warranty This warranty sets forth the full extent of MOTOROLA'S responsibilities regarding the Product. Repair, replacement or refund of the purchase price, at MOTOROLA’s option, is the exclusive remedy. THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES.
1 Defects or damage resulting from use of the Product in other than its normal and customary manner. 2 Defects or damage from misuse, accident, water, or neglect. 3 Defects or damage from improper testing, operation, maintenance, installation, alteration, modification, or adjustment. 4 Breakage or damage to antennas unless caused directly by defects in material workmanship.
the end user purchaser in any such suit which are attributable to any such claim, but such defense and payments are conditioned on the following: Limited Warranty 1 that MOTOROLA will be notified promptly in writing by such purchaser of any notice of such claim, 2 that MOTOROLA will have sole control of the defense of such suit and all negotiations for its settlement or compromise, and 3 should the Product or parts become, or in MOTOROLA’s opinion be likely to become, the subject of a claim of infringemen
Limited Warranty VII. GOVERNING LAW: This Warranty is governed by the laws of the State of Illinois, U.S.A.
Motorola Solutions, Inc. MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. © 2012–2014 Motorola Solutions, Inc. All rights reserved. December 2014. www.motorolasolutions.
