LCSR Programming Model
http://www.motorola.com/computer/literature 2-29
2
VMEbus Slave Ending Address Register 2
This register is the ending address register for the second VMEbus-to-
local-bus map decoder.
VMEbus Slave Starting Address Register 2
This register is the starting address register for the second VMEbus-to-
local-bus map decoder.
VMEbus Slave Address Translation Address Offset Register 1
This register is the address translation address register for the first
VMEbus-to-local-bus map decoder. It should be programmed to the local
bus starting address. When the adder is engaged, this register is the offset
value.
ADR/SIZ $FFF40004 (16 bits of 32)
BIT 31 . . . 16
NAME Ending Address Register 2
OPER R/W
RESET 0 PS
ADR/SIZ $FFF40004 (16 bits of 32)
BIT 15 . . . 0
NAME Starting Address Register 2
OPER R/W
RESET 0 PS
ADR/SIZ $FFF40008 (16 bits of 32)
BIT 31 . . . 16
NAME Address Translation Address Offset Register 1
OPER R/W
RESET 0 PS
